7.5.5 Control setting mode (SET 04) (2/4)
Setting data
Character
Setting (monitor) value
Initial value
Unit
Setting
value
Blind
PID control type
tYP
0: Type A (normal PID)
1: Type B (overshoot
suppression)
2: Type C (disturbance
suppression)
1
None
Type B mode
(overshoot
suppression)
bMd
0: Moderate
1: Intermediate
2: Intense
1
None
Forward
operation/reverse
operation
dIR
0: Reverse operation
1: Forward operation
0
None
Primary control
operating amount
MV1
MLL1 to MLH1
0.0
%
Primary control
output gain
MV1G
0.0 to 1000.0
100.0
%
Tuning type
tUN
1: Primary auto-tuning
2: Primary self-tuning
3: Secondary auto-tuning
(at primary PID/secondary PID)
4: Secondary self-tuning
(at primary PID/secondary PID)
5: Primary/secondary auto-tuning
(at primary PID/secondary PID)
1
None
Auto-tuning
coefficient
AtG
0.1 to 10.0
1.0
Times
Auto-tuning
sensitivity
AtC
Temperature: 0.0 to 999.9
0 to 999
Analog: 0 to 9999
2
C
Digit
Auto-tuning start
At
Start/stop with the ▲/▼ key
PV/SV displayed during AT
OFF
None
Proportional band
P1
0.1 to 200.0
3.0
%
Integral time
I
0 to 3600
0
Second
Derivative time
d
0 to 3600
0
Second
Primary control
proportional cycle
t1
0.1 to 120.0
20.0 (relay)
1.0 (SSR)
Second
Anti-reset windup
ARW
0.0 to 110.0
(Function turned off at 110.0)
110.0
%
Primary control
operating amount
limiter upper limit
MLH1
Digital output: MLL to 100.0
Analog output: MLL to 110.0
100.0
%
Primary control
operating amount
limiter lower limit
MLL1
Digital output: 0.0 to MLH1
Analog output: -10.0 to MLH1
0.0
%
