12 Setup
11
⃝
S/PDIF Dolby Digital output socket for the au-
dio system.
12
⃝
RS-232 Serial port for firmware update and data
transfer.
13
⃝
USB USB port for firmware update and data
transfer.
14
⃝
WLAN ANT Antenna for wireless local area network.
15
⃝
AC INPUT Connection socket for the power cord
supplied.
Table 2.3: Connectors specification
TV CVBS /S-Video/ RGB / YUV video output
Left & right audio output
VCR CVBS video output
Left & right audio output
CVBS / S-Video / RGB / YUV video input for bypass
Left & right audio input for bypass
YPbPr Component video (YUV) output
S-VIDEO Super video (S-Video) output
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
S/PDIF Dolby Digital audio output
RS-232 115.2 kbps at maximum
USB 2.0 Device
2.4 Connecting the digital receiver
There are several ways to set up the digital receiver as de-
scribed below. Set up the digital receiver suitably to your tele-
vision and other appliances. If you have any problem with
your setup or need a help, contact your dealer or service provider.
You should configure audio and video settings after setup. For
detailed descriptions about audio and video settings, refer to
§ 3.2.
