FormNo.3377-292RevD

BasketKit

27-inchDPAReelMowerforReelmaster

3100-DSeriesTraction

Unit

ModelNo.03185

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescription

Qty.

Use

Nopartsrequired

–

Preparethemachine.

Rollerbumper1

Flange-headscrews(8x16mm)

Mounttherollerbumper.

Hydroguard1

Bolt(5/16x1inch)

Mountthehydroguard.

Guideassembly

Bracketassembly2

Carriagebolt(5/16x1inch)

Flangenut(5/16inch)

Basketbracketwithguideassembly

(right)

Basketbracketwithbracketassembly

(left)

Bolt(5/16x2-1/4inch)

Flangenut(5/16inch)

Installthebasketmountingassemblies.

Cut-offbar

Bolt(1/4x1-3/4inches)

Locknut(1/4inch)

Installthecut-offbar.

Nopartsrequired

–

Installthenewgrassdeector.

Flangelocknut(3/8inch)

2Removethesupporttube.

Nopartsrequired

–

Assemblethereargrassbasket.

Basket3Mountthebasketstothecuttingunits.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.

OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

*3377-292*D

Summary of content (12 pages)

PAGE 1
Form No. 3377-292 Rev D Basket Kit 27-inch DPA Reel Mower for Reelmaster® 3100-D Series Traction Unit Model No. 03185 Installation Instructions WARNING CALIFORNIA Proposition 65 Warning This product contains a chemical or chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure 1 2 3 4 5 6 7 8 9 Description Qty.
PAGE 2
Procedure 10 11 12 13 14 Description Use Qty. No parts required – Adjust the front basket position. No parts required – Adjust the rear basket position. No parts required – Adjust the rear basket lip bracket. No parts required – Adjust the rear grass shield. No parts required – Adjust the roller bumper. Note: The 27 inch rear roller brush kit (Model 03186), will not work with the rear grass basket on the Reelmaster 3100 Grass Basket Kit (Model 03185).
PAGE 3
4 Installing the Basket Mounting Assemblies Parts needed for this procedure: 2 Guide assembly 2 Bracket assembly 4 Carriage bolt (5/16 x 1 inch) 4 Flange nut (5/16 inch) 1 Basket bracket with guide assembly (right) 1 Basket bracket with bracket assembly (left) g026365 Figure 2 1. Bolt (2) 4. Bolt 2 Bolt (5/16 x 2-1/4 inch) 2. Hydro guard 5. Cable support bracket 2 Flange nut (5/16 inch) 3. Nut 6. Pump plate Procedure 2.
PAGE 4
Note: The carriage bolts and flange bolts are shipped installed on the guide assembly. Note: The bolt must be threaded through the far wall of the tube. Rear Cutting Unit 7. Insert the left basket bracket with bracket assembly onto the left end of the cutting unit carrier frame tube (Figure 5). Important: Use the red colored rear stop-basket when operating in rugged terrain to help retain the rear basket.
PAGE 5
g012217 Figure 5 1. Bolt (5/16 x 2-1/4 inch) 3. Flange nut (5/16 inch) 2. Right basket bracket with guide 4. Carrier frame 5. Left basket bracket with bracket 5 Installing the Cut-off Bar Parts needed for this procedure: 1 Cut-off bar 4 Bolt (1/4 x 1-3/4 inches) 4 Locknut (1/4 inch) g012218 Figure 6 Procedure 1. Grass shield 1. Remove the 4 flange-head bolts securing the front grass shield and deflectors to the cutting unit frame (Figure 6). 2. Deflectors 2. Remove the grass shield. 3.
PAGE 6
Installing the New Grass Deflector (Front Cutting Units Only) No Parts Required Procedure g012219 1. Remove the 2 center deflectors and the deflector from each end of the shield, leaving only the 2 shown in Figure 9. Figure 7 1. Cut-off bar 3. Locknut (1/4 inch) 2. Bolt (1/4 x 1-3/4 inches) 4. Insert a 1.5 mm (0.060 inch) feeler gauge between the top of the reel and the bottom of the cut-off bar to check clearance (Figure 8).
PAGE 7
2. Using the cable ties on straps as handles, stretch each strap until it can be secured to top of basket with 2 washers and a locknut (Figure 12). Position a washer on each side of the basket top. 3. Install the grass shield and remaining deflectors. 7 Note: Cut off the cable ties after the straps are installed. Removing the Support Tube Note: To ease the installation of straps, place an 8 inch x 4 inch wood block (Figure 12) inside the basket to raise and support the top of the basket.
PAGE 8
• Position the basket so it is parallel to the cutting unit with 9 a minimum clearance of 6 mm (0.250 inch) between the lip of the basket and the reel (Figure 15). • On each end of the basket, adjust the basket stop brackets Mounting the Baskets to the Cutting Units so they each contact a side plate. • Tighten the carriage bolt nuts to secure the basket position.
PAGE 9
12 Adjusting the Rear Basket Lip Bracket No Parts Required Procedure Check to make sure that the top of the rear basket lip bracket is flush to 6 mm (0.250 inches) with the roller (Figure 18). If the bracket is not flush with the roller, loosen the mounting cap screws and adjust the bracket as required. g195002 Figure 16 1. Spacer 3. Grass shield wear strip 2. Roller 2. Adjust the basket so that the rear of the basket is slightly raised, as follows: A.
PAGE 10
14 Adjusting the Roller Bumper No Parts Required Procedure Adjust the roller bumper (Figure 19) so that the roller is parallel with the top shield on center basket on contact. If the basket is not parallel, the rear of the basket may contact the engine when it is raised. g012214 Figure 19 1. Roller bumper 2.
PAGE 11
Notes:
