Installation Instructions

FormNo.3360-606RevB

FoldingWindshieldKit

forWorkman®MD,MDX,MDEUtilityVehicle

ModelNo.07326

InstallationInstructions

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

Note:ToattachtheFoldingWindshieldKit,youmusthaveaCanopyKit(07324)installedonyourvehicle.

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

Description

Qty.

Use

Windshield,folding

Snaponclip,windshield(10inch)

Snaponclip,windshield(2inch)

Windshieldtube1

Bolt(1/4x1-1/4inch)

Flatwasher(1/4inch)

Cappednut(1/4inch)

Installthefoldingwindshieldkit.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.

OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved

PAGE 1
Form No. 3360-606 Rev B Folding Windshield Kit for Workman® MD, MDX, MDE Utility Vehicle Model No. 07326 Installation Instructions Note: Determine the left and right sides of the machine from the normal operating position. Note: To attach the Folding Windshield Kit, you must have a Canopy Kit (07324) installed on your vehicle. Installation Loose Parts Use the chart below to verify that all parts have been shipped.
PAGE 2
G009294 2 1 3 9 8 7 4 6 5 Figure 1 1. Folding Windshield 2. Rubber clip 3. Snap-on clip (2 inch) 4. Receiver clip 5. Snap-on clip (10 inch) 6. Capped nut 7. Canopy frame 8. Windshield tube 9. Bolt and flat washer Maintenance 1. Position the machine on a level surface. Set the parking brake, turn the ignition off, and remove the key. Remove the folding windshield before transporting the vehicle on a trailer.
