Installation Instructions

ManualsBrandsToro ManualsAttachmentsEngine Cover Kit, Workman HDX/HDX-D Utility Vehicle

FormNo.3361-851RevA

EngineCoverKit

forWorkmanHDX/HDX-DUtilityVehicle

ModelNo.117–4867

InstallationInstructions

Installation

1.Raisethebedandinstallthesafetysupportonthe

fullyextendedliftcylinderrod(ifsoequipped).

2.Stoptheengine,settheparkingbrake,andremove

thekey.

3.Loosentheboltonthefrontandthenutontheside

oftheengine(Figure1).

Figure1

1.Enginecover3.Removethisbolt

2.Loosenthisboltandthis

nut

4.Removetheboltsecuringthealternatortothe

adjustingbracket(Figure1).

5.Positiontheslottedenginecovermountingbrackets

ontotheloosenedboltsandlooselysecurethem.

6.Aligntheslottedenginecoverbracketwiththe

alternatorbracketslotandlooselysecuretheengine

covertothealternatorandadjustingbracketwiththe

boltremovedpreviously.

7.Adjustthebelttension.Refertoyouroperator’s

manualforthetensioningprocedure.

8.Tightenalltheboltsandnut.

©2009—TheToro®Company

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.

OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved
