Form No. 3429-987 Rev B U-Blade TXL 2000 Tool Carrier Model No. 22572—Serial No. 318000001 and Up Register at www.Toro.com.
WARNING CALIFORNIA Proposition 65 Warning Use of this product may cause exposure to chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. g267837 Figure 1 Introduction 1. Model and serial number location This U-blade attachment is intended to be used on a Toro compact tool carrier. It is designed primarily for digging, moving rock, and transplanting small trees and shrubs.
Slope Safety Safety • Operate the machine up and down slopes with the heavy end of the machine uphill. Weight distribution changes with attachments. An empty load-bearing attachment makes the rear of the machine the heavy end, and a full load-bearing attachment makes the front of the machine the heavy end. Most other attachments make the front of machine the heavy end. DANGER There may be buried utility lines in the work area. Digging into them may cause a shock or an explosion.
U-Blade Safety a safe distance between the machine and any hazard. • After striking a foreign object, shut off the engine, • Do not remove or add attachments on a slope. remove the key, thoroughly inspect the attachment for any damage, and repair the damage before starting and operating the attachment. • Do not park the machine on a hillside or slope. • Always lower the attachment each time you shut off the machine or leave the operating position.
Product Overview Specifications Note: Specifications and design are subject to change without notice. decal139-2803 139-2803 1. Warning—read the Operator’s Manual. 2. Warning—keep bystanders away.
Operation Determine the left and right sides of the machine from the normal operating position. Installing and Removing the Attachment Refer to the Operator’s Manual for the traction unit for the installation and removal procedure. Important: Before installing the attachment, position the machine on a level surface, ensure that the mount plates are free of any dirt or debris, and ensure that the pins rotate freely. If the pins do not rotate freely, grease them.
Transport Position Storage When transporting a load, keep the attachment as close to the ground as possible, no more than 15 cm (6 inches) above the lowest position. Tilt it rearward to keep the load level. 1. Before long-term storage, wash the attachment with mild detergent and water to remove dirt and grime. 2. Paint all scratched or bare metal surfaces. Note: Paint is available from your Authorized Service Dealer. 3. g267179 Figure 5 1. No more than 15 cm (6 inches) above the lowest position 2.
California Proposition 65 Warning Information What is this warning? You may see a product for sale that has a warning label like the following: WARNING: Cancer and Reproductive Harm—www.p65Warnings.ca.gov. What is Prop 65? Prop 65 applies to any company operating in California, selling products in California, or manufacturing products that may be sold in or brought into California.
