Form No. 3356-435 Rev A Debris Blower for Groundsmaster® 7200/7210 Traction Unit Model No. 30393—Serial No. 270000001 and Up Register at www.Toro.com.
Introduction Figure 2 1. Safety alert symbol Read this information carefully to learn how to operate and maintain your product properly and to avoid injury and product damage. You are responsible for operating the product properly and safely. This manual uses 2 other words to highlight information. Important calls attention to special mechanical information and Note emphasizes general information worthy of special attention. You may contact Toro directly at www.Toro.
Safety recommended for prolonged exposure to reduce the potential of permanent hearing damage. Hazard control and accident prevention are dependent upon the awareness, concern, and proper training of the personnel involved in the operation, transport, maintenance, and storage of the machine. Improper use or maintenance of the machine can result in injury or death. To reduce the potential for injury or death, comply with the following safety instructions. • Using the machine demands attention.
• Be sure that the machine is in safe operating condition by keeping nuts, bolts, and screws tight. Check the fan shaft bearing mounting bolts and nuts frequently to be sure that they are tightened to specification. • Make sure that all hydraulic line connectors are tight and all hydraulic hoses and lines are in good condition before applying pressure to the system. • Keep your body and hands away from pin hole leaks in hydraulic lines that eject high pressure hydraulic fluid.
114-4054 1. Warning—read the Operator’s Manual, do not operate the machine without the cross pin in place. 105-4593 1. Entanglement hazard, shaft—do not remove cover while parts are moving, keep all guards in place.
Setup Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Use Qty. 1 Castor wheel assembly 1 Mount the castor wheel to the debris blower 2 Debris blower assembly Locking pin Hair pin cotter 1 1 1 Mount the debris blower to the traction unit No parts required – Adjust the link assembly No parts required – Grease the blower 3 4 Media and Additional Parts Description Parts Catalog Operator’s Manual Use Qty. 1 1 Read before operating.
5. Insert the locking pin through the adapters and secure with a hairpin cotter (Figure 5). 2 Mounting the Debris Blower to the Traction Unit Parts needed for this procedure: 1 Debris blower assembly 1 Locking pin 1 Hair pin cotter 1 Procedure 1. Remove any attachment from the rear of the machine. G006618 2. Back the traction unit into position behind the attachment adapter. Figure 5 1.
3 4 Adjusting the Link Assembly Grease the Blower No Parts Required No Parts Required Procedure Procedure 1. With the debris blower mounted and secured on the traction unit, raise the attachment. 2. Measure the gap between the top washer and the spacer in the link assembly on the attachment adapter as shown in Figure 6. Before the Debris Blower is operated, it must be greased to assure proper lubrication. Refer to Lubrication section of manual.
72" width of cut GM7200 & GM7210 with NO Hard Canopy (model 30359) Models 30360, 30361, 30363, & 30364 Rear QAS and no attachment (Model 30377) QAS Finish Grader (Box Rake) (Model 08754) Steel Drag Mat (Model 08757) Tooth Rake (Model 08751) Tooth Rake With Spring Rake (Model 08752) Coco Drag Mat (Model 08758) QAS Nail Drag (Model 08761) QAS Debris Blower (Model 08759) Rahn Groomer (Allied Product) 72" width of cut GM7200 & GM7210 with Hard Canopy (model 30359) Models 30360, 30361, 30363, & 30364 Rear QAS an
62" width of cut GM7200 & GM7210 with NO Hard Canopy (model 30359) Models 30362 & 30365 Rear QAS and no attachment (Model 30377) QAS Finish Grader (Box Rake) (Model 08754) Steel Drag Mat (Model 08757) Tooth Rake (Model 08751) Tooth Rake With Spring Rake (Model 08752) Coco Drag Mat (Model 08758) QAS Nail Drag (Model 08761) QAS Debris Blower (Model 08759) Rahn Groomer (Allied Product) 62" width of cut GM7200 & GM7210 with Hard Canopy (model 30359) Models 30362 & 30365 Rear QAS and no attachment (Model 30377)
Operation Adjust Discharge Opening The discharge opening (Figure 9) is adjustable to direct the air flow from the blower. 1. Loosen discharge opening deflector mounting screws (Figure 9). Figure 10 1. Float 2. Power down 3. Lift/Lower Operating Tips Discharged air has considerable force and could cause injury or loss of footing. • Stay away from discharge opening when machine is operating. 1 2 • Keep bystanders away from discharge opening when machine is running. G003812 Figure 9 1.
1 G003783 Figure 11 1.
Maintenance Greasing the Attachment Adapter Lubrication If the locking lever on the attachment adapter does not pivot freely and easily, apply a light coat of grease to the area shown in Figure 14. The debris blower has bearings and bushings that must be lubricated regularly.. If the machine is operated under normal conditions, lubricate bearings with No. 2 general purpose lithium base grease after every 8 hours of operation or daily, whichever comes first.
3 2 4 G003815 1 G003816 Figure 16 1. Motor coupler 2. Fan coupler 1 Figure 17 3. Set screw (2 each) 4. Coupler spider 1. Set screw • The fan mounting nut (Figure 18) must be torqued to 500 ft–lb. 3. Tighten the capscrews and nuts securing the mounting brackets together and to the blower housing. 4. Remove the alignment tool and finish assembly. Torquing Fasteners If the blower is ever disassembled, the following fasteners must be torqued as specified.
1. Raise the debris blower so that the wheels are off of the floor. Block the blower so that it cannot accidentally fall. 2. Remove the tensioning cap, spacer, and thrust washer from the top of the castor spindle. 3. Pull the castor spindle out of the mounting tube. Allow the thrust washer and spacer to remain on the bottom of the spindle. 4. Insert a pin punch into the top or bottom of the mounting tube and drive the bushing out of the tube (Figure 19). Also drive the other bushing out of the tube.
The Toro General Commercial Products Warranty A Two-Year Limited Warranty Conditions and Products Covered The Toro Company and its affiliate, Toro Warranty Company, pursuant to an agreement between them, jointly warrant your Toro Commercial Product (“Product”) to be free from defects in materials or workmanship for two years or 1500 operational hours*, whichever occurs first.
