INSTALL REAR WEIGHT
GROUNDSMASTER 300 Series Traction Units comply with ANSI B71.4-1999 Standard when equipped with rear
weight. Use chart below to determine combinations of weight required. Order parts from your local Authorized Toro
Distributor.
Rear Weight Kit
(includes two 35 lb.
weights and mounting
hardware)
Groundsmaster 328D
(30626/30630*)
Rear Weight
Required
Weight Part
Number
Weight
Description
Qty.
Groundsmaster 325D
(30788/30739*)
245780
210 lb.
Rear Weight Kit
(includes two 35 lb.
weights and mounting
hardware)
3
Traction Unit
Description
245780245 lb.
Rear Weight Kit
(includes two 35 lb.
weights and mounting
hardware)
&
3
245790 Rear Weight Kit
(includes one 35 lb.
weight and mounting
hardware)
1
Groundsmaster 325D
4 Wheel Drive
(30795/30741)
70 lb.
1245780
245780210 lb. Rear Weight Kit
(includes two 35 lb.
weights and mounting
hardware)
3
Groundsmaster 345
(30789)
Rear Weight Kit
(includes two 35 lb.
weights and mounting
hardware)
Groundsmaster 328D
4 Wheel Drive
(30627/30631)
70 lb.
245780 1
*Models 30739 and 30630 include 1 Rear Weight Kit.
BEFORE OPERATING
CHECK LUBRICANT IN GEAR BOX
The gear box in designed to operate on SAE 80-90 wt.
gear lube. Although the gear box is shipped with
lubricant from the factory, check the level before
operating the cutting unit.
1. Position the machine on a level surface.
2. Remove check plug from side of gear box and
make sure lubricant is up to bottom of hole. If level of
lubricant is low, add enough lubricant to bring it up to
bottom of hole.
Figure 17
2. Drain Plug
1
2
1. Fill/Check Plug
