Installation Instructions

1 67-005-2402 Mounting Frame 1
2 67-005-0141 Mounting Pin 2
3 67-004-1161 Lower Mounting Pin 1
4 01-282-0600 PTO Assembly 1
5 67-005-0241 Belt Guard 1
6 67-005-2151 Pulley Shaft 1
7 67-005-0251 Bearing Mount 1
* 67-002-0051 Bearing Mount Assembly
(Incl. Ref. #6,7,13,40 - 42) 1
8 67-005-2411 Support Arm 1
9 67-005-2421 Support Bracket 1
10 67-004-2301 Support Pin 1
11 82-004-1171 Key 3
12 67-004-0401 Upper Support Hinge Rod 1
13 01-100-0340 Bearing (see note) 1
14 01-264-0350 Belt 1
15 01-260-0060 Sheave 1
16 01-260-0150 Sheave 1
17 3296-39 Lock Nut 1
18 01-159-0010 Presto Pin 4
19 01-650-0110 All Thread 1
20 3217-9 Hex Nut 4
21 3253-7 Lock Washer 4
22 3256-6 Flat Washer 2
23 01-506-0040 Decal - Danger 1
24 3272-11 Cotter Pin 4
25 67-004-2261 Stop Bracket 1
26 01-506-0130 Decal - Danger 1
27 01-260-0240 Bushing 2
28 01-163-0030 Socket Head Set Screw 1
29 323-13 Capscrew - Hex Hd. 1
30 3217-7 Hex Nut 6
31 3256-4 Flat Washer 5
32 3217-5 Hex Nut 2
33 325-6 Capscrew - Hex Hd. 2
34 3253-5 Lock Washer 4
35 323-8 Capscrew - Hex Hd. 4
36 321-4 Capscrew - Hex Hd. 3
37 3256-2 Flat Washer 3
38 3253-3 Lock Washer 3
39 01-506-0550 Decal - Grease 1
67-004
©
The TORO Company - 1994
All Ri ht R d
PARTS LIST &
ASSEMBLY
INSTRUCTIONS
MODEL NO. 44531
67 BLOWER MOUNTING KIT
for 220D SERIES GROUNDSMASTER
®
(Prior ’89)
FORM NO. 01-502-1320.1
9
10
37
36
34
32
6
7
38
24
30
31
35
4
29
30
28
11
31
19
5
11
14
27
15
16
27
11
20
21
22
20
21
8
17
13
24
12
26
39
20
21
22
18
1
3
18
18
2
33
25
23
2
37
38
36
Note: When installing bearing,
apply #609 Loctite to bearing be-
fore pressing into collar.
Ref.
No.
Part No.
Description
No.
Used
Ref.
No.
Part No.
Description
No.
Used
PARTS LIST
