4. PROGRAMMING OPERATIONS EO1-11154
4.2 Character Entries
4- 6
3. To clarify the operation flow, definitions of keys of the ECR keyboard are as shown below.
|
| --------- Selective numeric value which is entered through the Numeric keys.
[ ] --------- Depression of the function key.
xxxx
----------- Fixed numeric value which is entered through the Numeric keys.
Fixed
4. Table of key names in SET and REG modes
The keyboard layout for programming is adopted in SET mode.
The following table shows key names in SET mode and corresponding ones in REG mode.
Key name in SET mode
Key name in REG mode
(Normal type keyboard)
Key name in REG mode
(Flat type keyboard)
[↑] [LOG/RECIEPT] [R/A]
[↓] [RTN MDSE] [PO]
[←] [NS] [%-]
[→] [PR OPEN] [ - ]
[Enter] [LC OPEN] [CUR]
[Rtn] [ITEM CORR] [VAT]
[?] [ST] [AMT]
[C] [C] [C]
[Dbl] [X] [VOID]
[A/a] [AMT] [ITEM CORR]
[Del] [VALI DATE] [RTN MDSE]
[#] [#] [#]
[History] [RECEIPT ISSUE] [NS]
[End] [AT/TL] [AT/TL]
[PLU] [PLU] [PLU]
4.2 Character Entries
There are two methods of character settings for various names and messages:
CHARACTER CODE ENTRY Method and DIRECT CHARACTER ENTRY Method.
CHARACTER CODE ENTRY Method
This method is to set a character by entering a Character Code and depressing the [#] key. The method is
operated only on the ECR keyboard (Ordinary Type or Flat Type).
DIRECT CHARACTER ENTRY Method
This method is to set a character by directly depressing the Character Keys on any of the following keyboard:
• ECR keyboard with the keyboard layout for programming
• PK-2 keyboard (PLU keyboard; hardware option)
By using those character keys, the characters are directly entered. In this manual, sample operations are
attached to most of the programming operations. And at name or message programming portions, characters
except for numeric and special symbols are entered by the DIRECT CHARACTER ENTRY method.
On the following pages, Character Code Tables under the CHARACTER CODE ENTRY Method and two
different keyboards under the DIRECT CHARACTER ENTRY Method are shown. These pages are to be
referred to, every time the “Character Entries” sequence is contained in various programming operations in
this manual.
Read through these pages at least once first, so that you may know the appropriate method of character
entries using the ECR keyboard and/or option keyboards.
