11. REGISTERING PROCEDURE AND PRINT FORMAT EO1-11154
11.17 Listing Capacity Open
11-12
11.17 Listing Capacity Open
For Departments and PLUs
Depress [LC OPEN] (or [OPEN]) prior to or any time during an entry of an open-department, open-PLU, or
preset-open department or PLU sequence (including REPEAT and QUANTITY EXTENSION entries). Please
note that the [LC OPEN] (or [OPEN]) key must be pressed, at latest, before the final key of the entry sequence.
The High Amount Limit for the department or PLU will be extended with two higher digits, and the Low Amount
Limit will be extended with one lower digit. For entering an amount still exceeding these limits, you must call for a
Manager Intervention.
For Media Tender Amounts
Depress [LC OPEN] (or [OPEN]) before or after the amount but Media Key. The High Amount Limit for the
media tendering will be extended with one higher digit. In need of still exceeding this limit, you must call for a
Manager Intervention.
For Amounts through [ - ], [VND CPN], [STR CPN]
To exceed their limits, you must always call for a Manager Intervention. The [LC OPEN] (or [OPEN]) key will not
be effective. As for the [STR CPN] key only, the amount is limited by both High Amount Limit of the department
through which the store coupon amount is entered and the amount limit for [STR CPN]. That is, when an amount
cannot be entered using [LC OPEN] (or [OPEN]), you must call for a Manager Intervention.
11.18 Tax Status Modification
Depress [TX/M] (or [TX1/M], [TX2/M], [TX3/M], [TX4/M], [TX5/M], [TX6/M], [TX7/M], [TX8/M]), in the same way
as [LC OPEN] is operated, prior to or any time during the entry sequence of the required Department, PLU, or
any other tax-status-programmable item ([ - ], [%-], [%+], [STR CPN], [VND CPN]). The taxable status is
reversed to non-taxable, and vice versa.
11.19 Subtotal (Sale Total Pre-taxed) Read
- - - [ST] - - -
NOTES:
1. When the “Special Rounding” option has been selected, the post-rounded subtotal amount is displayed.
(The pre-rounded subtotal amount is printed.)
When the Add-on Tax feature has been selected, the subtotal including tax is displayed.
(The pre-taxed subtotal before rounding is printed.)
2. When the [ST] key is depressed during a Previous Balance entry, the sale total excluding the previous
balance is displayed.
3. The Repeat entry after a subtotal operation is not possible.
4. When the [ST] key is depressed, the sale total is displayed and printed. However, you can select non-print of
the subtotal (display only) by a program option.
OPERATION
The sale total (pre-taxed) of the items so far entered is
displayed (and printed if so programmed), but the sale is
not finalized. Additional item entries are allowed, if any.
-- Receipt Print Format --
SUBTL €6,00
