e-STUDIO5520C/6520C/6530C © 2008 TOSHIBA TEC CORPORATION All rights reserved
2-47
2. Copier-specific Adjustments
(4) Enter adjustment mode [05]. Change the values for codes [1630 to 1633] to adjust the maximum color
density of text.
Color to adjust
[05] code Recommended value
Acceptable
value range
Default
Y
(Yellow)
05-1630
M
(Magenta)
05-1631
C
(Cyan)
05-1632
K
(Black)
05-1633
Set a value larger than 5 to
increase the density.
Set a value smaller than 5 to
decrease the density.
0 to 10 5
* Set the value in increment of 1, while checking the copy image until the optimum value is obtained.
After adjusting the maximum color density of the text, copy and check the copy image quality.
If further image quality adjustments are still necessary, use the next procedure.
(5) Enter adjustment mode [05]. Change the values for codes [1725] and [7841] to adjust the level of
reproducibility in the Text/Photo mode or the User custom mode.
Color mode Original mode [05] code
Recommended
value
Accept
able
value
range
Default
Text/Photo 05-1725
Full color
User custom 05-7841
Set a value smaller than
3.
0 to 5 0
* Set the value in increment of 1, while checking the copy image until the optimum value is obtained.
First, set "3" for this code and check the copy image. If further image quality improvements are still
necessary, set "2." If even further improvements are still necessary, set "1" for this code.
* Remember that if a value larger than "3" is set, the edges of the image are enhanced (attaching importance
to the reproducibility of text). The table below shows you the correlation between the value and image
quality.
Value Advantage of image quality
Reproducibility of edges
0 Default Intermediate
1
Intended to improve the reproducibility of photos
more than the one obtained when "2" is set.
Soft
2
Intended to improve the reproducibility of photos
more than the one obtained when "3" is set.
↓
3
Equivalent to the one obtained when the default
value ("0") is set.
Intermediate
4
Intended to improve the reproducibility of text more
than the one obtained when "3" is set.
↓
5
Intended to improve the reproducibility of text more
than the one obtained when "4" is set.
Sharp
* For the User custom mode, refer to step (1) in "2.8 To Eliminate Moiré".
