Mid Level Single Zone Series Specifications

MODEL
TW09HQ2C2A TW09HQ2C2D TW12HQ2C2A TW12HQ2C2D TW18HQ2C2D TW24HQ2C2D TW30HQ2B4D TW36HQ2B4D
System Type
WIFI
Voltage/Phase/Hertz
115/1/60 208-230/1/60 115/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60
Cooling Capacity
Btu/h
10,900 9,600 14,600 13,000 20,000 27,300 30,000 36,000
Heating Capacity
Btu/h
9,900 11,000 12,200 13,000 19,800 23,000 28,400 34,600
SEER/EER
23/13.0 23/14.3 22/12.5 22/12.5 20/12.50 20/12.5 18/10.35 18/8.2
HSPF/COP
10.5/3.1 10.5/3.2 10.2/3.6 10.1/3.5 10.0/3.4 10.0/3.4 9.0/3.0 9.0/2.7
Energy Star®
Yes Yes Yes Yes Yes Yes
No No
Cooling Temperature Range
F
0~115 0～115 0~115 0～
115 0~115 0~115 0~115 0～109
Heating Temperature Range
F
-4~75 -4～75 -4~75 -4～75 -4~75 -4~75 -4～75 -4～75
Compressor Type
Indoor Unit
Air flow (min-max)
CFM
171~377 170~377 171~400 171~400 335~559 530~706 412~706 412~736
Sound Level (min-max)
dB(A)
26~43 29~43 28~45 29~45 39~47 36~48 37~51 37~54
Dehumidification
pt/hr
1.7 1.7 3.0 3.0 3.8 4.2 6.3 7.4
Indoor Unit Dimension
(WxHxD)
in
33.2×11.4×8.2 33.2×11.4×8.2 33.2×11.4×8.2 33.2×11.4×8.2 38.2×11.8×8.8 42.4×12.8×9.7 53.2×12.8×9.9 53.2×12.8×9.9
Indoor Package Dimension
(LxWxH)
in
36.3×11.1×14.9 36.3×11.1×14.9 36.3×11.1×14.9 36.3×11.1×14.9 41.0×15.1×12.6 45.2×16.3×13.8 56.7×16.6×14.5
56.7×16.6×14.
5
Indoor Weight (Net/Gross) lbs
23.2/27.6 22.1/26.5 23.2/27.6 22.0/26.5 27.6/34.2 34.2/41.9 41.9/51.8 41.9/51.8
OUTDOOR UNIT
Outdoor Sound Level
dB(A)
Outdoor Unit Dimension
(WxHxD)
in
33.4×21.3×12.6 33.4×21.3×12.6 33.4×21.3×12.6 33.4×21.3×12.6 37.6×27.6×15.6 38.6×31.1×16.8 38.6×31.1×16.8
38.6×31.1×16.
8
Outdoor Package Dimension
(LxWxH)
in
34.7×14.3×23.4 34.7×14.3×23.4 34.7×14.3×23.4 34.7×14.3×23.4 40.5×18.0×29.5 42.6×19.2×33.7 42.6×19.2×33.7
42.6×19.2×33.
7
Outdoor Weight (Net/Gross)
lbs
71.7/77.2 78.3/83.8 77.2/83.8 86.0/92.6 105.8/115.8 142.2/153.2 154.4/165.4 161.0/172.0
Refrigerant / Charge R410A
oz
42.3 45.9 47.6 47.6 56.4 77.6 84.7 91.7
Coil Type
Line Set Size (Liquid - Suction)
in
1/4" - 3/8" 1/4" - 3/8" 1/4" - 1/2" 1/4" - 1/2" 1/4" - 5/8" 1/4" - 5/8" 1/4" - 5/8" 1/4" - 5/8"
Pre-Charge Length
ft
24.6 24.6 24.6 24.6 24.6 24.6 24.6 24.6
Max. Line Length
ft
49.2 49.2 65.6 65.6 82.0 82.0 98.4 98.4
Max. Elevation
ft
32.8 32.8 32.8 32.8 32.8 32.8 32.8 32.8
Rated Current Cooling
amp
11.3 5.8 11.5 6.0 10.4 14.5 17 20
Rated Current Heating
amp
10.7 6.0 12.0 6.3 12.6 14.5 17.5 20.0
MCA
amp
12 9 17 9 16 20 20 24
MOCP
amp
20 15 25 15 25 30 30 40
Interconnecting Wire
Limited Warranty
Heat Pump
AWG 14/4
7 Years on Compressor / 5 Years on Parts
INSTALLATION
ELECTRICAL
Yes
Copper with Aluminum with BLUE FIN Coating
G-10 Inverter Driven 2-Stage Rotary
SYSTEM PERFORMANCE
53
53
53
54 55
59
62
65
