T12019 Safety and Instruction Manual PLEASE READ CAREFULLY *Subject *Subjecttotoregistering registeringYour YourExtended ExtendedGuarantee Guaranteeonline onlineatatwww.towerhousewares.co.uk. www.towerhouswares.co.uk. 1.
1912 Midland Metal Spinners was founded by George Cadman, who was then 65 years old, as a metal holloware manufacturing company, in St. Mark’s Street, Wolverhampton. They later moved into the Tower and Fort Works in Pelham Street, which ultimately gave rise to the famous Tower brand name. 1961 Tower became one of the largest manufacturers of aluminium holloware, electric kettles, tea pots and other household articles with over 1,000 employees. 1974 Russell Hobbs took ownership of the expanding Tower brand.
Safety and Instruction Manual CONTENTS: Please read this Manual carefully BEFORE using the Soup Maker for your own safety. Thank you for purchasing this Tower soup maker from the Tower range of products. It has been designed to provide many years of trouble-free cooking. There are many benefits to using a Tower soup maker: Contents: 1. Specifications Components and structure Technical information 2. Important Safety Information 3. Using your Tower Appliance 4. Trouble Shooting & Faq’s 5.
1 SPECIFICATIONS: Components This box contains: Motor Unit/Lid Ladle Heating/Mixing/Serving Jug Instruction Manual Chopping/Mixing Blade (not shown) 5. 1. 6. 2. 7. 8. 3. 4. Structure of your soup maker: 1. Anti Overflow Sensor 5. Motor Unit and secure interlocking lid 2. Glass Jug 6. Handle 3. Stainless Steel Mixing Blade 7. Control Panel 4. Heating Element 8. On/Off Button 4 Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
Safety and Instruction Manual Technical Data Description: Model: Rated Voltage: Frequency: Power Consumption: 1.7ltr Glass Soup Maker T12019 220-240V ~50/60Hz 800W Documentation We declare that this product conforms to the following product legislation in accordance with the following directive(s): 2004/108/EC Electromagnetic Compatibility Directive. 2006/95/EC Low Voltage Directive. 2011/65/EU Restriction of Hazardous Substances Directive.
2 IMPORTANT SAFETY INFORMATION Please read these notes carefully BEFORE using your Tower appliance • Check that the voltage of the main circuit corresponds with the rating of the appliance before operating. • Switch off and unplug before fitting or removing tools/ attachments, after use and before cleaning. • If the supply cord or appliance is damaged, stop using the appliance immediately and seek advice from the manufacturer, its service agent or a similarly qualified person.
Safety and Instruction Manual • This appliance is for household use only. • • • • This appliance includes a heating function. When the appliance is used for reheating foods, always ensure food is piping hot before eating. • Please ensure that the appliance is used on a stable, level, and heat resistant surface. Never exceed the maximum capacities outlined in this instruction manual.
3 USING YOUR APPLIANCE The Tower Glass Soup Maker is ideal for chunky and smooth soup that serves up to 4 people. Auto functions allow you to stand back as healthy nutritious meals are made for you in under 30 minutes and the blend function means your soup can be perfected to your taste. 1. Begin by washing your vegetables, and peeling any with hard skin (i.e. potatoes, carrots). 2. Chop your ingredients into pieces no larger than 1.5 – 2.5cm. 3.
Safety and Instruction Manual Pulse • Make a full batch of soup at a time and freeze your leftovers to enjoy later in the week. When freezing soup, leave it to chill overnight in the fridge before putting it into the freezer. • Layer softer, lighter ingredients like lentils or chopped tomatoes on top of heavier ingredients such as potato. This stops the lighter ingredients from being pressed down into the bottom of the jug and the blades too much.
• Serving soup with hard boiled eggs is a tasty way to add a kick of protein. • Swap bacon and ham in potato soup recipes for cauliflower which is rich in fibre and full of b-vitamin nutrients. Sweet potatoes add vitamin A. • Garnishing with fresh basil, which is thought to ease stress and help with problem skin. • For low fat soups, replace crème fraîche or soured cream with low fat fromage frais • Always remember to season your soup with salt and pepper after cooking.
Safety and Instruction Manual Stove top Stock A basic stock recipe to cook on the hob. Vegetable Stock: reducing the heat to medium low and allowing the stock to simmer. 3. Let the stock cook for around an hour, stirring intermittently to circulate the vegetables. 4. Take the stock off the heat and strain to remove the pieces of veg. 5. Refrigerate and allow cool before splitting into portions and then freezing immediately. 6.
5 CLEANING & CARE Not dishwasher safe. Do not immerse the soup maker in water or any liquids. 1. Clean the base housing and outside of the jug with a soft cloth. 2. Rinse the lid in warm, soapy water. 3. To clean the inside of the jug, rinse to remove any soup or large food particles. Remove any food remains using a soft cloth and mild detergent before rinsing again. Caution: The blades in the jug are very sharp, extreme caution shall be taken when cleaning the inside of the jug.
Safety and Instruction Manual 7 WIRING SAFETY FOR UK USE ONLY As the colours in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, please proceed as follows: FUSE IMPORTANT Non-Rewireable Mains Plug If your appliance is supplied with a nonrewireable plug fitted to the mains lead and should the fuse need replacing, you must use an ASTA approved one (conforming to BS 1362 of the same rating).
8 WARRANTY This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. We hope that you will enjoy your Tower Soup Maker for many years. As a thank you for purchasing one of our fantastic products, we are giving you 3 years peace of mind.
Safety and Instruction Manual 9 YOUR RECEIPT Affix your store receipt to this page for safe keeping.
thank you! We hope you enjoy your appliance for many years. As a thank you for purchasing one of our fantastic products, we are giving you an extra 2 years peace of mind. *To receive your extra 2 years guarantee, register your appliance online by visiting: www.towerhousewares.co.uk Should you have a problem with your appliance, or need any spare parts, please call our Service Department on: +44 (0) 333 220 6066 Your warranty becomes void should you decide to use non Tower spare parts.
