Chapter 1
Get to Know About Your Router
1. 2. 2. The Side and Back Panel
The following parts (view from left to right) are located on the side and rear panel.
Item Description
WiFi Button
Press the WiFi button for about 2 seconds to turn on or off the wireless
function of your router.
USB 3.0 Port
For connecting to a 3.0 USB device or a 3.0 USB printer. It is also compatible
with USB 2.0 devices.
USB 2.0 Port For connecting to a 2.0 USB device or a 2.0 USB printer.
Reset/WPS Button
Press this button for less than 5 seconds to enable the WPS function.
Press this button for more than 5 seconds to reset the router to its factory
default settings.
Internet Port For connecting to the DSL/Cable modem, or an Ethernet.
Ethernet Ports (1/2/3/4) For connecting the router to your PC or other Ethernet network devices.
Power On/Off Button Press this button to power on or off the router.
Power Port For connecting the router to power socket via the provided power adapter.
Antennas
Used for wireless operation and data transmit. Upright them for the best Wi-
Fi performance.
