User's Manual

18
HARDW
ARE FEATURES
Dimensions
CPE520/CPE220: 275.83*79*60.3mm
CPE510/CPE210: 224.34*79*60.3mm
In
terface
LAN0: 10/100Mbps Ethernet Port(PoE IN)
LAN1: 10/100Mbps Ethernet Port
GND: Grounding Terminal for Lightning Protection
RESET: Button to restore the device to Factory Default
Power Supply
24V Passive PoE Adapter Included
ESD Pr
otection
1
15kV
Lightning P
rotection
1
Up to 6kV
Oper
ating
Temperature
-30
℃
~ 70
℃
(-22
℉
~158
℉
)
Operating Humidity 10% ~ 90%
Certication CE, FCC, RoHS, IPX5
WIRELESS FEATURES
Models CPE210
CPE220 CPE510 CPE520
Antenna Gain 9dBi 12dBi 13dBi 16dBi
Horizontal Beamwidth/
Elevation Beamwidth
2
70°/ 45°
45°/ 30° 45°/ 30° 50°/ 20°
M
aximum Transmit
Power
3
27dBm 30dBm 27dBm 30dBm
Opera
ting
Frequency
3
2.4-
2.4835GHz
2.4-
2.4835GH
z 5.85GHz 5.85GHz
802.11 Standards 11b/g/n 11b/g/n 11a/n 11a/n
Specic
ations
1.
Estimation is based on copper grounding cable and shielded CAT5e cable with ground wire.
2. Beamwidth values may vary throughout operating frequency.
3. Maximum transmit power and operating frequency may vary in dierent countries or regions.
Note:
5.725-
5.725-
