User Guide

5.1.1 Wireless Basic Settings
Figure 5-3 Wireless Basic Settings
2.4GHz
Wireless Radio:
Check the box to enable 2.4GHz Wireless Radio.
Wireless Mode: Select the protocol standard for the wireless network.
We recommend that select 802.11b/g/n, in which way clients supporting
any one of these modes can access your wireless network.
Channel Width: Select the channel width of this device.
According to IEEE 802.11n standard, using a higher bandwidth can
increase wireless throughput. However, users may choose lower
bandwidth due to the following reasons:
1. To increase the available number of channels within the limited total
bandwidth.
2. To avoid interference from overlapping channels occupied by other
devices in the environment.
3.
Lower bandwidth can concentrate higher transmit power,
increasing stability of wireless links over long distances.
Channel:
Select the channel used by this device to improve wireless
performance. 1/2412MHz means the Channel is 1 and the frequency is
2412MHz. By default, channel is automatically selected.
Tx power: Enter the transmit power value. By default, the value is 20.
If the maximum transmit power is set to be larger than local regulation
allows, the maximum Tx power regulated will be applied in actual
situation.
NOTE
: In most cases, it is unnecessary to select maximum transmit
power. Selecting larger transmit power than needed may cause
interference to neighborhood. Also it consumes more power and will
7
