TD-W8101G 54Mbps Wireless ADSL2+ Modem Router Rev: 1.0.
COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011 TP-LINK TECHNOLOGIES CO., LTD.
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
National Restrictions 2400.0-2483.5 MHz Country Restriction General authorization required for outdoor use and public service Bulgaria France Reason/remark Outdoor use limited to 10 mW e.i.r.p. within the band 2454-2483.5 MHz Military Radiolocation use. Refarming of the 2.4 GHz band has been ongoing in recent years to allow current relaxed regulation.
TP-LINK TECHNOLOGIES CO., LTD DECLARATION OF CONFORMITY For the following equipment: Product Description: 54Mbps Wireless ADSL2+ Modem Router Model No.: TD-W8101G Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives: Directives 1999/5/EC The above product is in conformity with the following standards or other normative documents ETSI EN 300 328 V1.7.
CONTENTS Package Contents .................................................................................................... 1 Chapter 1 Introduction ......................................................................................... 2 1.1 Product Overview.................................................................................. 2 1.2 Main Features ....................................................................................... 2 1.3 Conventions ................................
4.5.6 CWMP ..................................................................................................... 47 4.6 Maintenance........................................................................................ 48 4.6.1 Administration.......................................................................................... 48 4.6.2 Time Zone ............................................................................................... 49 4.6.3 Firmware............................................
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Package Contents The following contents should be found in your package: ¾ One TD-W8101G 54Mbps Wireless ADSL2+ Modem Router ¾ One Power Adapter for TD-W8101G ADSL2+ Router ¾ Quick Installation Guide ¾ One RJ45 cable ¾ Two RJ11 cables ¾ One ADSL splitter ¾ One Resource CD , including: z This User Guide z Other Helpful Information ) Note: Make sure that the package contains the above items.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Chapter 1 Introduction 1.1 Product Overview Thank you for choosing the TD-W8101G 54Mbps Wireless ADSL2+ Modem Router. The device is designed to provide a simple and cost-effective ADSL Internet connection for a private Ethernet or IEEE 802.11g/ IEEE 802.11b wireless network. The TD-W8101G connects to an Ethernet LAN or computers via standard Ethernet ports. The ADSL connection is made using ordinary telephone line with standard connectors.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide ¾ Supports All ADSL industrial standards. ¾ Compatible with all mainstreams DSLAM (CO). ¾ Provides integrated access of internet and route function which face to SOHO user. ¾ Real-time Configuration and device monitoring. ¾ Supports Multiple PVC (Permanent Virtual Circuit). ¾ Built-in DHCP server. ¾ Built-in firewall, supporting IP/MAC filter, Application filter and URL filter.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Chapter 2 Hardware Installation 2.1 The Front Panel Figure 2-1 The LEDs, locating on the front panel, indicates the device’s working status. For details, please refer to LED Explanation. LED Explanation: Name Power ADSL Internet WLAN LAN Status Indication On Power is on. Off Power is off. On The LINE port is linked up. Flash The ADSL negotiation is in progress. Off The LINE port is linked down.
TD-W8101G 2.2 54Mbps Wireless ADSL2+ Modem Router User Guide The Back Panel Figure 2-2 ¾ POWER: The Power plug is where you will connect the power adapter. ¾ ON/OFF: The power switch for the Router. ¾ RESET: There are two ways to reset the Router's factory defaults. Method one: With the Router powered on, use a pin to press and hold the Reset button for at least 5 seconds. And the Router will reboot to its factory default settings.
TD-W8101G 2.3 54Mbps Wireless ADSL2+ Modem Router User Guide Installation Environment ¾ The Product should not be located where it will be exposed to moisture or excessive heat. ¾ Place the Router in a location where it can be connected to the various devices as well as to a power source. ¾ Make sure the cables and power cord are placed safely out of the way so they do not create a tripping hazard. ¾ The Router can be placed on a shelf or desktop.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 2-3 7
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Chapter 3 Quick Installation Guide 3.1 Configure PC After you directly connect your PC to the TD-W8101G or connect your adapter to a Hub/Switch which has connected to the Router, you need to configure your PC’s IP address. Follow the steps below to configure it. Step 1: Click the Start menu on your desktop, right click My Network Places, and then select Properties (shown in Figure 3-1).
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 3-2 Step 3: Select General tab, highlight Internet Protocol (TCP/IP), and then click the Properties button.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Step 4: Configure the IP address as Figure 3-4 shows. After that, click OK. Figure 3-4 ) Note: You can configure the PC to get an IP address automatically, select “Obtain an IP address automatically” and “Obtain DNS server address automatically” in the screen above. Now, you can run the Ping command in the command prompt to verify the network connection.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 3-6 You can check it follow the steps below: 1) Is the connection between your PC and the Router correct? The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should be lit. 2) Is the TCP/IP configuration for your PC correct? If the Router's IP address is 192.168.1.1, your PC's IP address must be within the range of 192.168.1.2 ~ 192.168.1.254. 3.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 3-7 Step 1: Select the Quick Start tab, then click RUN WIZARD, and you will see the next screen. Click the NEXT button. Figure 3-8 Step 2: Configure the time for the Router, and then click the NEXT button. Figure 3-9 Step 3: Select the connection type to connect to the ISP (We select PPPoE/PPPoA mode for example here), and then click the NEXT button.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 3-10 Step 4: Configure the following options provided by your ISP: Username, Password, VPI, VCI and Connection Type. Then click NEXT. Figure 3-11 Step 5: Configure the rules for the WLAN, and click NEXT.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 3-12 ) Note: If the Access Point is activated, the wireless function will be available even without the external antenna because of an additional printed antenna. To adopt the wireless security protection measures, please refer to section 4.3.3. Step 6: Click NEXT to save the current settings. Figure 3-13 Step 7: Click CLOSE to complete.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Chapter 4 Software Configuration This User Guide recommends using the “Quick Installation Guide” for first-time installation. For advanced users, if you want to know more about this device and make use of its functions adequately, maybe you will get help from this chapter to configure the advanced settings through the Web-based Utility. After your successful login, you can configure and manage the device.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-2 ) Note: Click the other submenus System Log or Statistics in Figure 4-2, and you will be able to view the system log and traffic statistics about the Router. 4.2 Quick Start Please refer to "3.2 Login". 4.3 Interface Setup Choose “Interface Setup”, you can see the next submenus: Internet and LAN and Wireless. Figure 4-3 Click any of them, and you will be able to configure the corresponding function.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide 4.3.1 Internet Choose “Interface Setup→Internet” menu, you can configure the parameters for WAN ports in the next screen (shown in Figure 4-4). Figure 4-4 ¾ ¾ ATM VC: ATM settings are used to connect to your ISP. Your ISP provides VPI (Virtual Path Identifier), VCI (Virtual Channel Identifier) settings to you. In this Device, you can totally setup 8 VCs on different encapsulations, if you apply 8 different virtual circuits from your ISP.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide PPPoA/PPPoE and Bridge Mode. Please choose the designed type that you want to use. After that, you should follow the configuration below to proceed. 1) Dynamic IP Address Select this option if your ISP provides you an IP address automatically. This option is typically used for Cable services. Please enter the Dynamic IP information accordingly.
TD-W8101G 2) 54Mbps Wireless ADSL2+ Modem Router User Guide Static IP Address Select this option if your ISP provides static IP information to you. You should set static IP address, IP subnet mask, and gateway address in the screen below (shown in Figure 4-6). Figure 4-6 ) Note: Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x), such as 192.168.1.100. The Router will not accept the IP address if it is not in this format.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-7 ¾ Servicename: Enter a name to mark current connection, or you can leave it blank. ¾ Username: Enter your username for your PPPoE/PPPoA connection. ¾ Password: Enter your password for your PPPoE/PPPoA connection. ¾ Encapsulation: For both PPPoE/PPPoA connection, you need to specify the type of Multiplexing, either LLC or VC Mux. ¾ Bridge Interface: Activate the option, and the Router can also work in Bridge mode.
TD-W8101G 4) 54Mbps Wireless ADSL2+ Modem Router User Guide Bridge Mode If you select this type of connection, the modem can be configured to act as a bridging device between your LAN and your ISP. Bridges are devices that enable two or more networks to communicate as if they are two segments of the same physical LAN. Figure 4-8 ) Note: After you finish the Internet configuration, please click SAVE to make the settings take effect. 4.3.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide may be referred to as Private settings. You may change the LAN IP address if needed. The LAN IP address is private to your internal network and cannot be seen on the Internet. ¾ • IP Address: Enter the Router’s local IP Address, then you can access to the Web-based Utility via the IP Address, the default value is 192.168.1.1. • IP Subnet Mask: Enter the Router’s Subnet Mask, the default value is 255.255.255.0.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide • Physical Ports: Specify the Physical Ports of the DHCP client. • DNS Relay: If you want to disable this feature, you just need to set both Primary and secondary DNS IP to 0.0.0.0. If you want to use DNS relay, you can setup DNS server IP to 192.168.1.1 on their Computer. If not, the device will perform as no DNS relay. • Primary DNS Server: Type in your preferred DNS server. • Secondary DNS Server: Type in your preferred DNS server.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-12 ¾ Access Point Settings: These are the settings of the access point. You can configure the rules to allow wireless-equipped computers and other devices to communicate with a wireless network. • Access Point: Select Activated to allow wireless station to associate with the access point. • Channel: Select the country and channel you want to use from the drop-down List of Channel.
TD-W8101G ¾ 54Mbps Wireless ADSL2+ Modem Router User Guide • RTS/CTS Threshold: Should you encounter inconsistent data flow, only minor reduction of the default value 2347 is recommended. If a network packet is smaller than the preset RTS threshold size, the RTS/CTS mechanism will not be enabled. The Router sends Request to Send (RTS) frames to a particular receiving station and negotiates the sending of a data frame.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide ) Note: For most users, it is recommended to use the default Wireless LAN Performance settings. Any changes made to these settings may adversely affect your wireless network. Under certain circumstances, changes may benefit performance. Carefully consider and evaluate any changes to these wireless settings. 1) WEP-64Bits To configure WPA-64Bits settings, select the WPA-64Bits option from the drop-down list.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-16 ¾ Encryption: Select the encryption you want to use: TKIP or AES (AES is an encryption method stronger than TKIP). • TKIP (Temporal Key Integrity Protocol) - a wireless encryption protocol that provides dynamic encryption keys for each packet transmitted. • AES (Advanced Encryption Standard) - A security method that uses symmetric 128-bit block data encryption.
TD-W8101G 4.4 54Mbps Wireless ADSL2+ Modem Router User Guide Advanced Setup Choose “Advanced Setup”, you can see the next submenus: Figure 4-19 Click any of them, and you will be able to configure the corresponding function. 4.4.1 Firewall Choose “Advanced Setup→Firewall” menu, and you will see the next screen (shown in Figure 4-20).
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-22 ¾ Destination IP Address: This parameter specifies the IP network address of the final destination. ¾ IP Subnet Mask: Enter the subnet mask for this destination. ¾ Gateway IP Address: Enter the IP address of the gateway. The gateway is an immediate neighbor of your ADSL Router that will forward the packet to the destination.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide can go to the previous screen (shown in Figure 4-4) to activate the function. ¾ Number of IPs; This field is to specify how many IPs are provided by your ISP for current VC. It can be single IP or multiple IPs. We select Multiple to explain. ) Note: For VCs with single IP, they share the same DMZ and Virtual servers; for VCs with multiple IPs, each VC can set DMZ and Virtual servers.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-25 ¾ Rule Index: The Virtual server rule index for this VC. You can specify 10 rules in maximum. All the VCs with single IP will use the same Virtual Server rules. ¾ Application: The Virtual servers can be used for setting up public services on your LAN. ¾ Protocol: The protocol used for this application. ¾ Start & End port number: Enter the specific Start and End Port number you want to forward.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Enter the index of assigned entry, and click the DELETE button to delete the entry. Click the BACK button to return to the previous screen. Click the CANCEL button to cancel the configuration which is made just now. 4.4.3.3 IP Address Mapping Select Multiple for numbers of IPs in Figure 4-23, and choose “Advanced Setup→NAT→IP Address Mapping(for Multiple IP Service)”. You can configure the Address Mapping Rule in the next screen.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Step 5: After that, click SAVE to make the entry take effect. Other operations for the entries as shown in Figure 4-26: Select the index of assigned entry, and click the DELETE button to delete the entry. Click the BACK button to return to the previous screen. Click the CANCEL button to cancel the configuration which is made just now. 4.4.4 QoS Choose “Advanced Setup→QoS”, you can configure the QoS in the next screen.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide ¾ QoS: Select this option to Activate/Deactivate the IP QoS on different types (IP ToS and DiffServ). ¾ Summary: Click the QoS Settings Summary button to view the configurations of QoS. ¾ Rule: Configure the rules for QoS. If the traffic complies with the rule, then the Router will take the corresponding action to deal with it. • Rule Index: Select the index for the rule you want to configure. • Active: Activate the rule.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide connections, it is very flexible for user/host management, bandwidth allocation and resource optimization. There are two types of VLAN as follows: 1) Port-Based VLAN: Each physical switch port is configured with an access list specifying membership in a set of VLANs.
TD-W8101G 2) 54Mbps Wireless ADSL2+ Modem Router User Guide Define VLAN Group Click Define VLAN Group in Figure 4-28, you can define VLAN groups in the next screen (shown in Figure 4-30). Figure 4-30 ¾ VLAN Index: Select the VLAN index for this VC. You can specify 8 groups in maximum. ¾ VLAN ID: This indicates the VLAN group. ¾ ATM VCs: Select the ATM VCs as members of VLAN, and if you leave the Tagged blank, the tag in frames will be deleted when transmitted from the VC.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-31 ¾ ADSL Mode: Select the ADSL operation mode which your ADSL connection uses. ¾ ADSL Type: Select the ADSL operation type which your ADSL connection uses. ¾ Bitswap Enable: Check this box to enable Bitswap. ¾ SRA Enable: Check this box to enable SRA. 4.5 Access Management Choose “Access Management”, you can see the next submenus: Figure 4-32 Click any of them, and you will be able to configure the corresponding function. 4.5.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-33 ¾ ACL: If Activated, the IP addresses which are contained in the Access Control List can access to the Router. If Deactivated, all IP addresses can access to the Router. ¾ ACL Rule Index: Select the ACL rule index for the entry. ¾ Active: Enable the ACL rule. ¾ Secure IP Address: Select the IP addresses which are permitted to access to the Router remotely. With the default IP 0.0.0.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-34 ¾ Filter Type Selection: Select the filter type for the configuration below. ¾ IP/MAC Filter Set Index: Select the Set index for the IP Filter entry. This index can match with six IP / MAC Filter Rule Indexes. ¾ Interface: Select the interface for the entry. ) Note: If select PVC0~PVC7 as an interface, the filter will match the IP traffic of WAN port with specified IPs (Source IP Address and Destination IP Address).
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide ) Note: Incoming means that IP traffic which is coming into the Router, and the Outgoing means that IP traffic which is going out the Router. ¾ IP/MAC Filter Rule Index: Select the Rule index for the IP Filter entry. ) Note: You should set the IP/MAC Filter Set Index and IP/MAC Filter Rule Index together to appoint the address (shown in the Filter List) for the IP Filter rule.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide ) Note: If you want to make the rule take effect, please select Yes to active the rule. Step 3: Enter the “Source IP Address”, “Destination IP Address”, “Subnet Mask” and “Port Number” in the corresponding field. Step 4: Select the Protocol as “TCP” and select the Unmatched rule as “Next”. Step 5: Finally, click the SAVE to save the entry. Step 6: Go to Step 2 to configure the next two rules: Block E-mail received by the IP address 192.168.1.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide 4.5.2.2 MAC Filter Select IP/Mac Filter as the Filter type, and select MAC as the Rule type (shown in Figure 4-35), and then you can configure the filter rules based on MAC address. Figure 4-35 ¾ Rule Type: Select MAC for the MAC Filter rule. ¾ Active: Select “Yes” to make the rule to take effect. ¾ MAC Address: Enter the MAC address for the rule.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Then you can configure the specific rule for the example. Step 2: Select the IP/MAC Filter Set Index and IP/MAC Filter Rule Index for the rule, then select the Interface “PVC0”, and select the Direction “Outgoing” for the first rule. ) Note: If you want to make the rule take effect, please select Yes to active the rule. Step 3: Enter the “MAC Address” and select the Unmatched rule as “Next”. Step 4: Finally, click the SAVE to save the entry.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-36 ¾ Filter Type Selection: Select the Application Filter for the next configuration. ¾ Application Filter: Activate or deactivate the function. ¾ ICQ & MSN & YMSG & Real Audio/Video: Select Allow or Deny for these applications. If you select Allow, the Router will accept the application; if you select Deny, the Router will forbid the application. 4.5.2.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-37 ¾ Filter Type Selection: Select the URL Filter for the next configuration. ¾ Active: Select “Yes” to make the rule to take effect. ¾ URL Index: Select the index for the URL Filter entry. ¾ URL: Enter the URL for this URL Filter. ¾ URL Filter Listing: This displays the information about the URL Filter rules. To add a URL filter entry: For example: If you want to forbid the user to access the website: www.yahoo.com.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide 4.5.3 SNMP Choose “Access Management→SNMP”, you can see the SNMP screen. The Simple Network Management Protocol (SNMP) is used for exchanging information between network devices. Figure 4-38 ¾ Get Community: Set the password for the incoming Get and Get next requests from the management station. ¾ Set Community: Set the password for incoming Set requests from the management station. 4.5.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide static host name with a dynamic IP address. User should type the host name, user name and password assigned to your ADSL Router by your Dynamic DNS provider. User also can decide to turn on DYNDNS Wildcard or not. Figure 4-40 ¾ Dynamic DNS: Activate the DDNS function or not. ¾ Service Provider: This field displays the service provider of DDNS. ¾ My Host Name: Enter your host name here. ¾ E-mail Address: Enter your E-mail address here.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-41 ¾ CWMP: Select activate the CWMP function. ¾ URL: Enter the website of ACS which is provided by your ISP. ¾ User Name/Password: Enter the User Name and password to login the ACS server. ¾ Path: Enter the path that connects to the ACS server. ¾ Port: Enter the port that connects to the ACS server. ¾ User Name/Password: Enter the User Name and Password that provided the ACS server to login the Router.
TD-W8101G ) Note: 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-43 1) There is only one account that can access Web-Management interface. The default account is "admin", and the password is "admin". Admin has read/write access privilege. 2) When you change the password, you should enter the new password twice, and then click SAVE to make the new password take effect. 4.6.2 Time Zone Choose “Maintenance→Time Zone”, you can configure the system time in the screen (shown in Figure 4-44).
TD-W8101G 2) 54Mbps Wireless ADSL2+ Modem Router User Guide PC’s Clock Select PC’s Clock as the Synchronize time, you don’t need to set any items. Figure 4-45 3) Manually Select Manually as the Synchronize time, you need to set the date and time corresponding to the current time. Figure 4-46 4.6.3 Firmware Choose “Maintenance→Firmware”, you can upgrade the firmware of the Router in the screen (shown in Figure 4-47).
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-47 To upgrade the Router's firmware, follow these instructions below: Step 1: Download a more recent firmware upgrade file from the TP-LINK website (http://www.tp-link.com). Step 2: Type the path and file name of the update file into the “New Firmware Location” field. Or click the Browse… button to locate the update file. Step 3: Click the UPGRADE button. ) Note: 1) New firmware versions are posted at http://www.tp-link.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-48 Step 2: Save the file as the appointed file (shown in Figure 4-49). Figure 4-49 To restore the Router’s settings: Step 1: Click the Browse… button to locate the update file for the device, or enter the exact path in “New Romfile Location” field. Step 2: Click the UPGRADE button to complete. 4.6.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-50 4.6.5 Diagnostics Choose “Maintenance→Diagnostics”, you can view the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides in the screen (shown in Figure 4-51). Figure 4-51 Ping Tool: This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a given host or gateway. ¾ IP Address/Domain Name: Type the destination IP address (such as 202.108.22.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide If the result is similar to Figure 4-52, the connectivity of the Internet is fine. Figure 4-52 If the result is similar to Figure 4-53, there is something wrong with the connectivity of the Internet. Figure 4-53 4.7 Help Choose “Help”, you can view the help information for configuration of any function.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Figure 4-54 ) Note: Click the tab, and you will be able to get the corresponding information.
TD-W8101G 54Mbps Wireless ADSL2+ Modem Router User Guide Appendix A: Specification General ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5 Standards and Protocols Safety & Emission Ports LEDs IEEE 802.11b, IEEE 802.11g ,IEEE 802.3, IEEE 802.
