User's Manual

TD-W8901N
150Mbps Wireless N ADSL2+ Modem Router User Guide
or given by your ISP. For Static IP, you need to specify the IP address, Subnet Mask and
Gateway IP address.
4) Bridge Mode
If you select this type of connection, the modem router can be configured to act as a bridging
device between your LAN and your ISP. Bridges are devices that enable two or more networks to
communicate as if they are two segments of the same physical LAN.
Figure 4-10

Note:
After you finish the Internet configuration, please click SAVE to make the settings take effect.
4.3.1.2 IPv6
If you select IPv6 as IP version, please follow the configuration below to configure the parameters
for WAN ports.
 Encapsulation: There are four connection types: Dynamic IP Address, Static IP Address,
PPPoA/PPPoE and Bridge Mode. Please choose the designed type that you want to use.
After that, you should follow the configuration below to proceed.
1) Dynamic IP Address
Select this option if your ISP provides you an IP address automatically. This option is typically
used for Cable services. Please enter the Dynamic IP information accordingly.
26

