User's Manual

TD-W8901N
150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-24
WPS Settings
 WPS Settings: WPS can help you to add a new wireless device to an existing network
quickly. This section will guide you how to use WPS function.
• WPS state: Display the current WPS state.
• WPS mode: If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can
establish a wireless connection between wireless adapter and modem router using either
Push Button Configuration (PBC) method or PIN method, please select the one you
want.
• WPS progress: Show the current WPS progress.
• Reset to OOB: Use this button to reset the WPS state to “unconfigured”, so that a new
key will be created when using WPS function next time.
1) PBC
If the wireless adapter supports Wi-Fi Protected Setup and the Push Button Configuration
(PBC) method, you can add it to the network by PBC with the following two methods. Click
PBC, you will see the screen as shown below.
Figure 4-25
Method One:
Step 1: Press the WPS/RESET button on the back panel of the modem router for about 2
seconds or click Start WPS button in Figure 4-25.
40

