TL-WDR4300 N750 Wireless Dual Band Gigabit Router Rev: 1.0.
COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2012 TP-LINK TECHNOLOGIES CO., LTD.
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
conjunction with any other antenna or transmitter.” CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Ce dispositif est conforme à la norme CNR-210 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) Le dispositif ne doit pas produire de brouillage préjudiciable, et (2) Ce dispositif doit accepter tout brouillage reçu,y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
당해 무선설비는 운용중 전파혼신 가능성이 있음. NCC Notice: 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功 率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並 改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電 機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що передбачені чинними законодавчими актами України.
TP-LINK TECHNOLOGIES CO., LTD DECLARATION OF CONFORMITY For the following equipment: Product Description: N750 Wireless Dual Band Gigabit Router Model No.
CONTENTS Package Contents..................................................................................................... 1 Chapter 1. Introduction ......................................................................................... 2 1.1 Overview of the Router .................................................................................................2 1.2 Conventions ..................................................................................................................3 1.
4.8 4.9 4.7.1 Wireless Settings ............................................................................................ 47 4.7.2 WPS ................................................................................................................49 4.7.3 Wireless Security ............................................................................................ 51 4.7.4 Wireless MAC Filtering ...................................................................................54 4.7.
4.16 Bandwidth Control ......................................................................................................97 4.16.1 Control Settings .............................................................................................. 98 4.16.2 Rules List ........................................................................................................98 4.17 IP & MAC Binding Setting ........................................................................................... 99 4.17.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Package Contents The following items should be found in your package: TL-WDR4300 N750 Wireless Dual Band Gigabit Router DC Power Adapter for TL-WDR4300 N750 Wireless Dual Band Gigabit Router Quick Installation Guide Resource CD for TL-WDR4300 N750 Wireless Dual Band Gigabit Router, including: This Guide Other Helpful Information Note: Make sure that the package contains the above items.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Chapter 1. Introduction Thank you for choosing the TL-WDR4300 N750 Wireless Dual Band Gigabit Router. 1.1 Overview of the Router The TL-WDR4300 N750 Wireless Dual Band Gigabit Router integrates 4-port Switch, Firewall, NAT-Router and Wireless AP.
TL-WDR4300 1.2 N750 Wireless Dual Band Gigabit Router Conventions The Router or TL-WDR4300 mentioned in this guide stands for TL-WDR4300 N750 Wireless Dual Band Gigabit Router without any explanation. 1.3 Main Features Complies with IEEE 802.11n to provide a wireless data rate of up to 300Mbps (2.4GHz) + 450Mbps (5GHz). One 10/100/1000M Auto-Negotiation RJ45 Internet port, four 10/100/1000M Auto-Negotiation RJ45 Ethernet ports, supporting Auto MDI/MDIX.
TL-WDR4300 1.4 Panel Layout 1.4.1 The Front Panel N750 Wireless Dual Band Gigabit Router Figure 1-1 LEDs on the front panel The Router’s LEDs are located on the front panel (View from left to right). Name Status Indication Off Power is off. On Power is on. On The Router is initializing or maybe has a system error. (Power) (System) (Wireless 2.4GHz) Flashing The Router is working properly. Off The Router has a system error. Off The wireless function is disabled.
TL-WDR4300 (WPS) (USB on the rear panel) N750 Wireless Dual Band Gigabit Router Slow Flash A wireless device is connecting to the network by WPS function. This process will last in the first 2 minutes. On A wireless device has been successfully added to the network by WPS function. Quick Flash A wireless device failed to be added to the network by WPS function. Off No storage device or printer is plugged into the USB port. On A storage device or printer has connected to the USB port.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router WPS/Reset: Pressing this button for less than 5 seconds enables the WPS function. If your client devices, such as wireless adapters, that support Wi-Fi Protected Setup, then you can press this button to quickly establish a connection between the Router and client devices and automatically configure wireless security for your wireless network. Pressing this button for more than 5 seconds enables the Reset function.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Chapter 2. Connecting the Router 2.1 System Requirements Broadband Internet Access Service (DSL/Cable/Ethernet) One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the Router is connected directly to the Ethernet) PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors TCP/IP protocol on each PC Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari 2.
TL-WDR4300 6. N750 Wireless Dual Band Gigabit Router Connect the power adapter to the power socket on the Router, and the other end into an electrical outlet, shown in Figure 2-1. The Router will start to work automatically. 7. Power on your Cable/DSL Modem. Figure 2-1 Hardware Installation Figure 2-2 USB Installation Note: If you want to use the Router to share files or printer, plug the USB storage device to the USB port or connect the printer to the Router with a matching cable.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your N750 Wireless Dual Band Gigabit Router using Quick Setup Wizard within minutes. 3.1 TCP/IP Configuration The default IP address of the Router is 192.168.0.1 and the default Subnet Mask is 255.255.255.0. These values can be changed as you desire. In this guide, we use all the default values for description.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router If the result displayed is similar to Figure 3-2, it means the connection between your PC and the Router failed. Figure 3-2 Failure result of Ping command Please check the connection following these steps: 1. Is the connection between your PC and the Router correct? Note: The 1/2/3/4 LEDs of Ethernet ports which you link to on the Router and LEDs on your PC's adapter should be lit. 2.
TL-WDR4300 3.2 N750 Wireless Dual Band Gigabit Router Quick Installation Guide With a Web-based utility, it is easy to configure and manage the N750 Wireless Dual Band Gigabit Router. The Web-based utility can be used on any Windows, Macintosh or UNIX OS with a Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari. 1. To access the configuration utility, open a web-browser and type in the default IP address http://tplinklogin.net in the address field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 3-5 Quick Setup 3. Click Next, and then WAN Connection Type page will appear, shown in Figure 3-6. The Router provides Auto-Detect function and supports three popular ways Dynamic IP, Static IP and PPPoE to connect to the Internet. It’s recommended that you make use of the Auto-Detect function. If you are sure of what kind of connection type your ISP provides, you can select the very type and click Next to go on configuring.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. If you have difficulty with this process, please contact your ISP. Confirm Password - Enter the password again to make sure that the password is correct. 2) If the connection type detected is Dynamic IP, the next screen will appear as shown in Figure 3-8.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 3-9 Find MAC Address 3) If the connection type detected is Static IP, the next screen will appear as shown in Figure 3-10. Configure the following parameters and then click Next to continue. Figure 3-10 Quick Setup - Static IP IP Address - This is the WAN IP address as seen by external users on the Internet (including your ISP). Your ISP will provide you with the IP address you need to enter here. Enter the IP address into the field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router for introduction. Click Next to continue. Figure 3-11 Quick Setup – Dual Band Selection 2.4GHz - You can use the 2.4GHz band to connect to many classic wireless devices like gaming consoles, laptops, DVRs, ect. 5GHz - This band is less crowded and is used for time-sensitive music, video streaming or gaming. Using this band can avoid interference with 2.4GHz networks or noisy devices like cordless phones and microwave ovens. 6.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router in your network. The default SSID is set to be TP-LINK_2.4GHz_XXXXXX. This value is case-sensitive. For example, TEST is NOT the same as test. Region - Select your region from the drop-down list. This field specifies the region where the wireless function of the Router can be used. It may be illegal to use the wireless function of the Router in a region other than one of those specified in this field.
TL-WDR4300 7. N750 Wireless Dual Band Gigabit Router Configure the basic parameters for 5GHz wireless network in the following screen as shown in Figure 3-13, and then click Next. Figure 3-13 Quick Setup – Wireless Wireless Radio - Choose from the drop-down list to enable or disable the wireless radio. Wireless Network Name - Also called the SSID (Service Set Identification). Enter a value of up to 32 characters. The same name must be assigned to all wireless devices in your network.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Channel Width - Select any channel width from the drop-down list. The default setting is “Auto”, which can adjust the channel width for your clients automatically. Channel - This field determines which operating frequency will be used. It is not necessary to change the wireless channel unless you notice interference problems with another nearby access point. If you select “Auto”, then the AP will select the best channel automatically.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Chapter 4. Configuring the Router This chapter will show each Web page's key functions and the configuration way. 4.1 Login After your successful login, you will see the sixteen main menus on the left of the Web-based utility. On the right, there are the corresponding explanations and instructions. The detailed explanations for each Web page’s key function are listed below. 4.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-1 Router Status - 20 -
TL-WDR4300 4.3 N750 Wireless Dual Band Gigabit Router Quick Setup Please refer to 3.2 Quick Installation Guide. 4.4 Network Figure 4-2 the Network menu There are three submenus under the Network menu (shown in Figure 4-2): WAN, LAN and MAC Clone. Click any of them, and you will be able to configure the corresponding function. 4.4.1 WAN Choose menu “Network → WAN”, you can configure the IP parameters of the WAN on the screen below. 1.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-3 WAN – Dynamic IP This page displays the WAN IP parameters assigned dynamically by your ISP, including IP address, Subnet Mask, Default Gateway, etc. Click the Renew button to renew the IP parameters from your ISP. Click the Release button to release the IP parameters. MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Get IP with Unicast DHCP - A few ISPs' DHCP servers do not support the broadcast applications. If you cannot get the IP Address normally, you can choose this option. (It is rarely required.) Click the Save button to save your settings. 2. If your ISP provides a static or fixed IP Address, Subnet Mask, Gateway and DNS setting, select Static IP. The Static IP settings page will appear, shown in Figure 4-4.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-5 WAN - PPPoE User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Secondary Connection - It’s available only for PPPoE Connection. If your ISP provides an extra Connection type such as Dynamic/Static IP to connect to a local area network, then you can check the radio button of Dynamic/Static IP to activate this secondary connection.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: Only when you have configured the system time on “System Tools → Time Settings” page, will the Time-based Connecting function can take effect. Connect Manually - You can click the Connect/Disconnect button to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect on Demand mode.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Detect Online Interval - The Router will detect Access Concentrator online at every interval. The default value is “0”. You can input the value between “0” and “120”. The value “0” means no detect. Primary DNS/Secondary DNS - If your ISP does not automatically assign DNS addresses to the Router during login, please click “Use the following DNS servers” check box and enter the IP address in dotted-decimal notation of your ISP’s primary DNS server.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router is 1500 Bytes. It is not recommended that you change the default MTU Size unless required by your ISP. Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be re-established when you attempt to access the Internet again. If you want your Internet connection keeps active all the time, please enter “0” in the Max Idle Time field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-8 WAN - L2TP/Russia L2TP User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Dynamic IP/ Static IP - Choose either as you are given by your ISP. Click the Connect button to connect immediately. Click the Disconnect button to disconnect immediately.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Connect Manually - You can configure the Router to make it connect or disconnect manually. After a specified period of inactivity (Max Idle Time), the Router will disconnect from your Internet connection, and you will not be able to re-establish your connection automatically as soon as you attempt to access the Internet again. To use this option, check the radio button.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-9 PPTP Settings User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Dynamic IP/ Static IP - Choose either as you are given by your ISP and enter the ISP’s IP address or the domain name. If you choose static IP and enter the domain name, you should also enter the DNS assigned by your ISP. And click the Save button. Click the Connect button to connect immediately.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Otherwise, enter the number of minutes you want to have elapsed before your Internet connection terminates. Connect Automatically - Connect automatically after the Router is disconnected. To use this option, check the radio button. Connect Manually - You can configure the Router to make it connect or disconnect manually.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-10 LAN MAC Address - The physical address of the Router, as seen from the LAN. The value can't be changed. IP Address - Enter the IP address of your Router or reset it in dotted-decimal notation (factory default: 192.168.0.1). Subnet Mask - An address code that determines the size of the network. Normally use 255.255.255.0 as the subnet mask.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router WAN MAC Address - This field displays the current MAC address of the Internet port. If your ISP requires you to register the MAC address, please enter the correct MAC address into this field in XX-XX-XX-XX-XX-XX format (X is any hexadecimal digit). Your PC's MAC Address - This field displays the MAC address of the PC that is managing the Router.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router streaming or gaming. Using this band can avoid interference with 2.4GHz networks or noisy devices like cordless phones and microwave ovens. 4.6 Wireless 2.4GHz Figure 4-13 Wireless menu There are five submenus under the Wireless menu (shown in Figure 4-13): Wireless Settings, WPS, Wireless Security, Wireless MAC Filtering, Wireless Advanced and Wireless Statistics. Click any of them, and you will be able to configure the corresponding function. 4.6.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router TP-LINK_2.4GHz_XXXXXX. This value is case-sensitive. For example, TEST is NOT the same as test. Region - Select your region from the drop-down list. This field specifies the region where the wireless function of the Router can be used. It may be illegal to use the wireless function of the Router in a region other than one of those specified in this field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Enable SSID Broadcast - When wireless clients survey the local area for wireless networks to associate with, they will detect the SSID broadcast by the Router. If you select the Enable SSID Broadcast checkbox, the Wireless Router will broadcast its name (SSID) on the air. Enable WDS Bridging - Check this box to enable WDS. With this function, the Router can bridge two or more Wlans.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-16 WPS WPS Status - Enable or disable the WPS function here. Current PIN - The current value of the Router's PIN is displayed here. The default PIN of the Router can be found in the label or User Guide. Restore PIN - Restore the PIN of the Router to its default. Gen New PIN - Click this button, and then you can get a new random value for the Router's PIN. You can ensure the network security by generating a new PIN.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-17 Figure 4-18 Add A New Device Step 2: Press and hold the WPS button of the client device directly. Step 3: The Wi-Fi Protected Setup LED flashes for two minutes during the Wi-Fi Protected Setup process. Step 4: When the WPS LED is on, the client device has successfully connected to the Router. Step 5: Refer back to your client device or its documentation for further instructions. II.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router III. Enter the Router’s PIN on your client device Use this method if your client device asks for the Router’s PIN number. Step 1: On the client device, enter the PIN number listed on the Router’s Wi-Fi Protected Setup screen, shown in Figure 4-16 (It is also labeled on the bottom of the Router). Step 2: The Wi-Fi Protected Setup LED flashes for two minutes during the Wi-Fi Protected Setup process.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-20 Wireless Security Disable Security - If you do not want to use wireless security, check this radio button. But it’s strongly recommended to choose one of the following modes to enable security. WPA/WPA2-Personal - It’s the WPA/WPA2 authentication type based on pre-shared passphrase. The Router is configured by this security type by default. Version - you can choose the version of the WPA-PSK security on the drop-down list.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-21 WPA/WPA2 – Personal PSK Password - You can enter ASCII characters between 8 and 63 characters or 8 to 64 Hexadecimal characters. The default password is the same with the default PIN code, which is labeled on the bottom of the Router or can be found in Figure 4-16. Group Key Update Period - Specify the group key update interval in seconds. The value should be 30 or above. Enter 0 to disable the update.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-23 WEP Type - you can choose the type for the WEP security on the drop-down list. The default setting is Automatic, which can select Shared Key or Open System authentication type automatically based on the wireless station's capability and request. WEP Key Format - Hexadecimal and ASCII formats are provided here. Hexadecimal format stands for any combination of hexadecimal digits (0-9, a-f, A-F) in the specified length.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-24 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. The default setting is Disabled. MAC Address - The wireless station's MAC address that you want to filter. Status - The status of this entry, either Enabled or Disabled. Description - A simple description of the wireless station. To Add a Wireless MAC Address filtering entry, click the Add New… button.
TL-WDR4300 2. Modify the information. 3. Click the Save button. N750 Wireless Dual Band Gigabit Router Click the Enable All button to make all entries enabled Click the Disabled All button to make all entries disabled. Click the Delete All button to delete all entries. Click the Next button to go to the next page. Click the Previous button to return to the previous page.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-26 Wireless Advanced Transmit Power - Here you can specify the transmit power of Router. You can select High, Middle or Low which you would like. High is the default setting and is recommended. Beacon Interval - Enter a value between 20-1000 milliseconds for Beacon Interval here. The beacons are the packets sent by the Router to synchronize a wireless network. Beacon Interval value determines the time interval of the beacons.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: If you are not familiar with the setting items in this page, it's strongly recommended to keep the provided default values; otherwise it may result in lower wireless network performance. 4.6.6 Wireless Statistics Choose menu “Wireless 2.4GHz → Wireless Statistics”, you can see the MAC Address, Current Status, Received Packets and Sent Packets for each connected wireless station.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router There are five submenus under the Wireless menu (shown in Figure 4-13): Wireless Settings, WPS, Wireless Security, Wireless MAC Filtering, Wireless Advanced and Wireless Statistics. Click any of them, and you will be able to configure the corresponding function. 4.7.1 Wireless Settings Choose menu “Wireless 5GHz → Wireless Settings”, you can configure the basic settings for the wireless network of 5GHz on this page.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: Limited by local law regulations, version for North America does not have region selection option. Mode - Select the desired mode. 11a only - Select if all of your wireless clients are 802.11a. When 802.11a mode is selected, only 802.11a wireless stations can connect to the Router. 11n only- Select only if all of your wireless clients are 802.11n. When 802.11n mode is selected, only 802.11n wireless stations can connect to the Router.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router BSSID(to be bridged) - The BSSID of the AP your Router is going to connect to as a client. You can also use the search function to select the BSSID to join. Survey - Click this button, you can search the AP which runs in the current channel. Key type - This option should be chosen according to the AP's security configuration.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can establish a wireless connection between wireless adapter and Router using either Push Button Configuration (PBC) method or PIN method. Note: To build a successful connection by WPS, you should also do the corresponding configuration of the new device for WPS function meanwhile. I.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-34 Add A New Device Step 2: Enter the PIN number from the client device in the field on the above WPS screen. Then click Connect button. Step 3: “Connect successfully” will appear on the screen of Figure 4-34, which means the client device has successfully connected to the Router. III. Enter the Router’s PIN on your client device Use this method if your client device asks for the Router’s PIN number.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-35 Wireless Security Disable Security - If you do not want to use wireless security, check this radio button. But it’s strongly recommended to choose one of the following modes to enable security. WPA/WPA2-Personal - It’s the WPA/WPA2 authentication type based on pre-shared passphrase. The Router is configured by this security type by default. Version - you can choose the version of the WPA-PSK security on the drop-down list.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-36 WPA/WPA2 – Personal PSK Password - You can enter ASCII characters between 8 and 63 characters or 8 to 64 Hexadecimal characters. The default password is the same with the default PIN code, which is labeled on the bottom of the Router or can be found in Figure 4-31. Group Key Update Period - Specify the group key update interval in seconds. The value should be 30 or above. Enter 0 to disable the update.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-38 WEP Type - you can choose the type for the WEP security on the drop-down list. The default setting is Automatic, which can select Shared Key or Open System authentication type automatically based on the wireless station's capability and request. WEP Key Format - Hexadecimal and ASCII formats are provided here. Hexadecimal format stands for any combination of hexadecimal digits (0-9, a-f, A-F) in the specified length.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-39 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. The default setting is Disabled. MAC Address - The wireless station's MAC address that you want to filter. Status - The status of this entry, either Enabled or Disabled. Description - A simple description of the wireless station. To Add a Wireless MAC Address filtering entry, click the Add New… button.
TL-WDR4300 2. Modify the information. 3. Click the Save button. N750 Wireless Dual Band Gigabit Router Click the Enable All button to make all entries enabled Click the Disabled All button to make all entries disabled. Click the Delete All button to delete all entries. Click the Next button to go to the next page. Click the Previous button to return to the previous page.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-41 Wireless Advanced Transmit Power - Here you can specify the transmit power of Router. You can select High, Middle or Low which you would like. High is the default setting and is recommended. Beacon Interval - Enter a value between 20-1000 milliseconds for Beacon Interval here. The beacons are the packets sent by the Router to synchronize a wireless network. Beacon Interval value determines the time interval of the beacons.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: If you are not familiar with the setting items in this page, it's strongly recommended to keep the provided default values; otherwise it may result in lower wireless network performance. 4.7.6 Wireless Statistics Choose menu “Wireless → Wireless Statistics”, you can see the MAC Address, Current Status, Received Packets and Sent Packets for each connected wireless station.
TL-WDR4300 4.8.1 N750 Wireless Dual Band Gigabit Router DHCP Settings Choose menu “DHCP → DHCP Settings”, you can configure the DHCP Server on the page as shown in Figure 4-44.The Router is set up by default as a DHCP (Dynamic Host Configuration Protocol) server, which provides the TCP/IP configuration for all the PC(s) that are connected to the Router on the LAN. Figure 4-44 DHCP Settings DHCP Server - Enable or Disable the DHCP server.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: To use the DHCP server function of the Router, you must configure all computers on the LAN as "Obtain an IP Address automatically". 4.8.2 DHCP Clients List Choose menu “DHCP → DHCP Clients List”, you can view the information about the clients attached to the Router in the screen as shown in Figure 4-45.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Reserved IP Address - The IP address reserved for the PC by the Router. Status - The status of this entry, either Enabled or Disabled. To Reserve an IP address: 1. Click the Add New… button. Then Figure 4-47 will pop up. 2. Enter the MAC address (in XX-XX-XX-XX-XX-XX format.) and IP address (in dotted-decimal notation) of the computer for which you want to reserve an IP address. 3. Click the Save button.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router There are four submenus under the USB Settings menu (shown in Figure 4-48), Storage Sharing, FTP Server, Media Server, Print Server and User Accounts. Click any of them, and you will be able to configure the corresponding function. 4.9.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-50 Safe Unplug Message Click the Rescan button to start a new scan. Follow the instructions below to set up your Router as a file server: 1. Plug an external USB hard disk drive or USB flash drive into this Router. 2. Click the Rescan button to find the USB drive that has been attached to the Router. 3. Click the Start button to start the Storage Sharing service. 4. Click the Enable button under Shared to enable the disk to share. 5.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-51 FTP Server Configuration Service Status - Indicates the FTP Server's current status. Internet Access - Select enable to allow access of the FTP server from the Internet. Otherwise, select disable to only allow local network access. Service Port - Enter the FTP Port number to use. The default is 21. Name - This folder's display name. Partition - The volume that the folder resides.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-52 Add or Modify Share Folder 2. Select the Share entire partition or a specific folder option. 3. Enter display name of the share folder in Display Name filed. 4. Click the Save button to save the settings. You can click the upper button to go to the upper folder. You can click the Back button to return to the ftp server configuration page. Note: 1. 2. The max share folders number is 10.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Server Status - Indicates the Media Server’s current status, started or stopped. You can click the Start button to start the Media Server and click the Stop button to stop it. Name - The display name of this folder. File System - The file system type on the partition can be FAT32 or NTFS. Folder - The real full path of the specified folder. Delete - You can delete the share folder by click Delete.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-56 Add New Folder Display Name - You can enter a display name for the share folder. Share entire partition - Choose this option and then the folders contained in this partition will all be shared. Folder Location- Displays the location of this folder. Select - Check the radio button to select the folder to share. Folder - Displays folders that are in current path. Upper - Click this button to get into the upper folder.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-57 Pint Server Setting There are two states of the print server, they are as follows: Online - Indicates the print service has been turned on, and no user is using the print service at present. You can click the "Stop" button to stop the print service. Offline - Indicates the print service feature is disabled. You can click "Start" button to start the print service. 4.9.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 4. Re-enter the password in the Confirm Password field. 5. Choose the Storage Authority from the drop-down list, Read and Write or Read Only. 6. Choose FTP Access from the drop-down list, Yes or No. Figure 4-59 Add or Modify User Account User Name - Type the user name that you want to give access to the USB drive. The user name must be composed of alphanumeric symbols not exceeding 15 characters in length.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 4.10 NAT Choose “NAT”, and you can enable or disable the NAT function. Figure 4-60 The Forwarding menu 4.11 Forwarding Figure 4-61 The Forwarding menu There are four submenus under the Forwarding menu (shown in Figure 4-61): Virtual Servers, Port Triggering, DMZ and UPnP. Click any of them, and you will be able to configure the corresponding function. 4.11.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-62 Virtual Servers Service Port - The numbers of External Service Ports. You can enter a service port or a range of service ports (the format is XXX – YYY; XXX is the Start port and YYY is the End port). Internal Port - The Internal Service Port number of the PC running the service application. You can leave it blank if the Internal Port is the same as the Service Port, or enter a specific port number when Service Port is a single one.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-63 Add or Modify a Virtual Server Entry Note: It is possible that you have a computer or server that has more than one type of available service. If so, select another service, and type the same IP address for that computer or server. To modify or delete an existing entry: 1. Find the desired entry in the table. 2. Click Modify or Delete as desired on the Modify column.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-64 Port Triggering To add a new rule, follow the steps below. 1. Click the Add New… button, the next screen will pop-up as shown in Figure 4-65. 2. Select a common application from the Common Applications drop-down list, then the Trigger Port field and the Incoming Ports field will be automatically filled. If the Common Applications do not have the application you need, enter the Trigger Port and the Incoming Ports manually. 3.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Trigger Protocol - The protocol used for Trigger Ports, either TCP, UDP, or All (all protocols supported by the Router). Incoming Port - The port or port range used by the remote system when it responds to the outgoing request. A response using one of these ports will be forwarded to the PC which triggered this rule. You can input at most 5 groups of ports (or port sections).
TL-WDR4300 N750 Wireless Dual Band Gigabit Router (shown in Figure 4-66).The DMZ host feature allows one local host to be exposed to the Internet for a special-purpose service such as Internet gaming or videoconferencing. The Router forwards packets of all services to the DMZ host. Any PC whose port is being forwarded must have its DHCP client function disabled and should have a new static IP Address assigned to it because its IP Address may be changed when using the DHCP function.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router App Description - The description about the application which initiates the UPnP request. External Port - The port which the Router opened for the application. Protocol - The type of protocol which is opened. Internal Port - The port which the Router opened for local host. IP Address - The IP address of the local host which initiates the UPnP request. Status - Either Enabled or Disabled.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-69 Basic Security Firewall - A firewall protects your network from the outside world. Here you can enable or disable the Router’s firewall. SPI Firewall - SPI (Stateful Packet Inspection, also known as dynamic packet filtering) helps to prevent cyber attacks by tracking more state per session. It validates that the traffic passing through the session conforms to the protocol. SPI Firewall is enabled by factory default.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router gateway to support address and port translation for certain application layer "control/data" protocols such as FTP, TFTP, H323 etc. FTP ALG - To allow FTP clients and servers to transfer data across NAT, click Enable. TFTP ALG - To allow TFTP clients and servers to transfer data across NAT, click Enable. H323 ALG - To allow Microsoft NetMeeting clients to communicate across NAT, click Enable.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router DoS Protection - Denial of Service protection. Check the Enable or Disable button to enable or disable the DoS protection function. Only when it is enabled, will the flood filters be enabled. Note: Dos Protection will take effect only when the Traffic Statistics in “System Tool → Traffic Statistics” is enabled. Enable ICMP-FLOOD Attack Filtering - Enable or Disable the ICMP-FLOOD Attack Filtering.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-71 Local Management By default, the radio button “All the PCs on the LAN are allowed to access the Router's Web-Based Utility” is checked. If you want to allow PCs with specific MAC Addresses to access the Setup page of the Router's Web-Based Utility locally from inside the network, check the radio button “Only the PCs listed can browse the built-in web pages to perform Administrator tasks”, and then enter each MAC Address in a separate field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-72 Remote Management Web Management Port - Web browser access normally uses the standard HTTP service port 80. This Router's default remote management web port number is 80. For greater security, you can change the remote management web port to a custom port by entering that number in the box provided. Choose a number between 1 and 65534 but do not use the number of any common service port.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-73 Parental Control Settings To add a new entry, please follow the steps below. 1. Click the Add New… button and the next screen will pop-up as shown in Figure 4-74. Figure 4-74 Add or Modify Parental Control Entry Parental Control - Check Enable if you want this function to take effect; otherwise, check Disable.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router MAC Address of Your PC - This field displays the MAC address of the PC that is managing this Router. If the MAC Address of your adapter is registered, you can click the Copy To Above button to fill this address to the MAC Address of Parental PC field above. Website Description - Description of the allowed website for the PC controlled. Schedule - The time period allowed for the PC controlled to access the Internet.
TL-WDR4300 2. N750 Wireless Dual Band Gigabit Router Click “Access Control → Schedule” on the left to enter the Schedule Settings page. Click Add New... button to create a new schedule with Schedule Description is Schedule_1, Day is Sat and Time is all day-24 hours. 3. Click “Parental Control” menu on the left to go back to the Add or Modify Parental Control Entry page: 4. 1) Click Add New... button. 2) Enter 00-11-22-33-44-AA in the MAC Address of Child PC field.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-77 Access Control Rule Management Enable Internet Access Control - Select the check box to enable the Internet Access Control function, so the Default Filter Policy can take effect. Rule Name - Here displays the name of the rule and this name is unique. Host - Here displays the host selected in the corresponding rule. Target - Here displays the target selected in the corresponding rule.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Method One: 1. Click Setup Wizard button and the next screen will appear as shown in Figure 4-78. Figure 4-78 Quick Setup – Create a Host Entry Host Description - In this field, create a unique description for the host (e.g. Host_1). Mode - Here are two options, IP Address and MAC Address. You can select either of them from the drop-down list.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Mode - Here are two options, IP Address and Domain Name. You can choose either of them from the drop-down list. If the IP Address is selected, you will see the following items: IP Address - Enter the IP address (or address range) of the target (targets) in dotted-decimal format (e.g. 192.168.0.23). Target Port - Specify the port or port range for the target. For some common service ports, you can make use of the Common Service Port item below.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Start Time - Enter the start time in HHMM format (HHMM are 4 numbers). For example 0800 is 8:00. Stop Time - Enter the stop time in HHMM format (HHMM are 4 numbers). For example 2000 is 20:00. 4. Click Next when finishing creating the advanced schedule entry, and the next screen will appear as shown in Figure 4-81. Figure 4-81 Quick Setup – Create an Internet Access Control Entry Rule - In this field, create a name for the rule.
TL-WDR4300 5. N750 Wireless Dual Band Gigabit Router Select a schedule from the Schedule drop-down list or choose “Click Here To Add New Schedule”. 6. In the Status field, select Enabled or Disabled to enable or disable your entry. 7. Click the Save button. Figure 4-82 Add Internet Access Control Entry For example: If you desire to allow the host with MAC address 00-11-22-33-44-AA to access www.google.
TL-WDR4300 4) In Schedule field, select Schedule_1. 5) In Status field, select Enable. 6) Click Save to complete the settings. N750 Wireless Dual Band Gigabit Router Then you will go back to the Access Control Rule Management page and see the following list. 4.14.2 Host Choose menu “Access Control → Host”, and then you can view and set a Host list in the screen as shown in Figure 4-83. The host list is necessary for the Access Control Rule.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Click the Next button to go to the next page, or click the Previous button to return to the previous page. Figure 4-84 Add or Modify a Host Entry Figure 4-85 Add or Modify a Host Entry For example: If you desire to restrict the internet activities of host with MAC address 00-11-22-33-44-AA, you should first follow the settings below: 1. Click Add New... button in Figure 4-83 to enter the Add or Modify a Host Entry page. 2.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-86 Target Settings Target Description - Here displays the description about the target and this description is unique. Information - The target can be IP address, port, or domain name. Modify - To modify or delete an existing entry. To add a new entry, please follow the steps below. 1. Click the Add New… button. 2. In Mode field, select IP Address or Domain Name. 3. If you select IP Address, the screen shown is Figure 4-87.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-88 Add or Modify an Access Target Entry 1) In Target Description field, create a unique description for the target (e.g. Target_1). 2) In Domain Name field, enter the domain name, either the full name or the keywords (for example, google) in the blank. Any domain name with keywords in it (www.google.com, www.google.cn) will be blocked or allowed. You can enter 4 domain names. 5. Click the Save button.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-89 Schedule Settings Schedule Description - Here displays the description of the schedule and this description is unique. Day - Here displays the day(s) in a week. Time - Here displays the time period in a day. Modify - Here you can edit or delete an existing schedule. To add a new schedule, follow the steps below: 1. Click Add New... button shown in Figure 4-89 and the next screen will pop-up as shown in Figure 4-90. 2.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-90 Advanced Schedule Settings For example: If you desire to restrict the internet activities of host with MAC address 00-11-22-33-44-AA to access www.google.com only from 18:00 to 20:00 on Saturday and Sunday, you should first follow the settings below: 1. Click Add New... button shown in Figure 4-89 to enter the Advanced Schedule Settings page. 2. In Schedule Description field, create a unique description for the schedule (e.g. Schedule_1).
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 4.15.1 Static Routing List Choose menu “Advanced Routing → Static Routing List”, and then you can configure the static route in the next screen (shown in Figure 4-92). A static route is a pre-determined path that network information must travel to reach a specific host or network. Figure 4-92 Static Routing To add static routing entries: 1. Click Add New… shown in Figure 4-92, you will see the following screen.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Click the Enable All button to enable all the entries. Click the Disable All button to disable all the entries. Click the Delete All button to delete all the entries. Click the Previous button to view the information in the previous screen, click the Next button to view the information in the next screen. 4.15.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router There are two submenus under the Bandwidth Control menu as shown in Figure 4-95: Control Settings and Rules List. Click any of them, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below. 4.16.1 Control Settings Choose menu “Bandwidth Control → Control Settings”, and then you can configure the Egress Bandwidth and Ingress Bandwidth in the next screen.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Egress bandwidth - This field displays the max and mix upload bandwidth through the Internet port, the default is 0. Ingress bandwidth - This field displays the max and mix download bandwidth through the Internet port, the default is 0. Enable - This displays the status of the rule. Modify - Click Modify to edit the rule. Click Delete to delete the rule. To add/modify a Bandwidth Control rule, follow the steps below. 1.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-100 Binding Setting MAC Address - The MAC address of the controlled computer in the LAN. IP Address - The assigned IP address of the controlled computer in the LAN. Bind - Check this option to enable ARP binding for a specific device. Modify - To modify or delete an existing entry. When you want to add or modify an IP & MAC Binding entry, you can click the Add New… button or Modify button, and then you will go to the next page.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 2. Enter the MAC Address or IP Address. 3. Click the Find button in the page as shown in Figure 4-102. Figure 4-102 Find IP & MAC Binding Entry Click the Enable All button to make all entries enabled. Click the Delete All button to delete all entries. 4.17.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: An item could not be loaded to the IP & MAC Binding list if the IP address of the item has been loaded before. Error warning will prompt as well. Likewise, "Load All" only loads the items without interference to the IP & MAC Binding list. 4.18 Dynamic DNS Choose menu “Dynamic DNS”, and you can configure the Dynamic DNS function.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 2. Enter the User Name for your DDNS account. 3. Enter the Password for your DDNS account. 4. Click the Login button to login the DDNS service. Connection Status -The status of the DDNS service connection is displayed here. Click Logout to log out of the DDNS service. Note: If you want to login again with another account after a successful login, please click the Logout button, then input your new username and password and click the Login button.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Note: If you want to login again with another account after a successful login, please click the Logout button, then input your new username and password and click the Login button. 4.18.3 No-ip.com DDNS If the dynamic DNS Service Provider you select is www.no-ip.com, the page will appear as shown in Figure 4-106. Figure 4-106 No-ip.com DDNS Settings To set up for DDNS, follow these instructions: 1. Enter the User Name for your DDNS account. 2.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 4.19 System Tools Figure 4-107 The System Tools menu Choose menu “System Tools”, and you can see the submenus under the main menu: Time Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot, Password, System Log and Statistics. Click any of them, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below. 4.19.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Time Zone - Select your local time zone from this pull down list. Date - Enter your local date in MM/DD/YY into the right blanks. Time - Enter your local time in HH/MM/SS into the right blanks. NTP Server I / NTP Server II - Enter the address or domain of the NTP Server I or NTP Server II, and then the Router will get the time from the NTP Server preferentially.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-109 Time settings Note: 1. This setting will be used for some time-based functions such as firewall. You must specify your time zone once you login to the router successfully, otherwise, these functions will not take effect. 2. The time will be lost if the router is turned off. 3. The Router will automatically obtain GMT from the Internet if it is configured accordingly. 4.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Traceroute - This diagnostic tool tests the performance of a connection. Note: You can use ping/traceroute to test both numeric IP address or domain name. If pinging/tracerouting the IP address is successful, but pinging/tracerouting the domain name is not, you might have a name resolution problem. In this case, ensure that the domain name you are specifying can be resolved by using Domain Name System (DNS) queries.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-112 Firmware Upgrade Firmware Version - Displays the current firmware version. Hardware Version - Displays the current hardware version. The hardware version of the upgrade file must accord with the Router’s current hardware version. To upgrade the Router's firmware, follow these instructions below: 1. Download a most recent firmware upgrade file from our website (www.tp-link.com). 2.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-113 Restore Factory Default Click the Restore button to reset all configuration settings to their default values. The default User Name: admin The default Password: admin The default Subnet Mask: 255.255.255.0 Note: All changed settings will be lost when defaults are restored. 4.19.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router 4.19.6 Reboot Choose menu “System Tools → Reboot”, and then you can click the Reboot button to reboot the Router via the next screen. Figure 4-115 Reboot the Router Some settings of the Router will take effect only after rebooting, which include Change the LAN IP Address (system will reboot automatically). Change the DHCP Settings. Change the Wireless configurations. Change the Web Management Port.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router will be prompted for the Router's default user name and password. Note: The new user name and password must not exceed 14 characters in length and not include any spaces. Enter the new Password twice to confirm it. Click the Save button when finished. Click the Clear All button to clear all. 4.19.8 System Log Choose menu “System Tools → System Log”, and then you can view the logs of the Router.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure 4-118 Mail Account Settings From - Your mail box address. The Router would connect it to send logs. To - Recipient’s address. The destination mailbox where the logs would be received. SMTP Server - Your smtp server. It corresponds with the mailbox filled in the From field. You can log on the relevant website for help if you are not clear with the address. Authentication - Most SMTP Server requires Authentication.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Save Log - Click to save all the logs in a txt file. Mail Log - Click to send an email of current logs manually according to the address and validation information set in Mail Settings. Clear Log - All the logs will be deleted from the Router permanently, not just from the page. Click the Next button to go to the next page, or click the Previous button to return to the previous page. 4.19.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Statistics Table: IP/MAC Address Packets The IP and MAC address are displayed with related statistics. The total number of packets received and transmitted by the Router. Total Bytes Packets Bytes ICMP Current Tx The total number of bytes received and transmitted by the Router. The total number of packets received and transmitted in the last Packets Statistic interval seconds.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Appendix A: FAQ 1. How do I configure the Router to access Internet by ADSL users? 1) First, configure the ADSL Modem configured in RFC1483 bridge model. 2) Connect the Ethernet cable from your ADSL Modem to the Internet port on the Router. The telephone cord plugs into the Line port of the ADSL Modem. 3) Login to the Router, click the “Network” menu on the left of your browser, and click "WAN" submenu.
TL-WDR4300 2. N750 Wireless Dual Band Gigabit Router How do I configure the Router to access Internet by Ethernet users? 1) Login to the Router, click the “Network” menu on the left of your browser, and click "WAN" submenu. On the WAN page, select “Dynamic IP” for "WAN Connection Type", finish by clicking “Save”. 2) Some ISPs require that you register the MAC Address of your adapter, which is connected to your cable/DSL Modem during installation.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure A-5 Add or Modify a Virtual server Entry Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. 4) How to enable DMZ Host: Log in to the Router, click the “Forwarding” menu on the left of your browser, and click "DMZ" submenu. On the "DMZ" page, click Enable radio button and type your IP address into the “DMZ Host IP Address” field, using 192.168.0.169 as an example, remember to click the Save button.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Figure A-7 Basic Security 4. I want to build a WEB Server on the LAN, what should I do? 1) Because the WEB Server port 80 will interfere with the WEB management port 80 on the Router, you must change the WEB management port number to avoid interference. 2) To change the WEB management port number: Log in to the Router, click the “Security” menu on the left of your browser, and click "Remote Management" submenu.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router field of the Web browser. If the LAN IP of the modem connected with your router is 192.168.0.x, the default LAN IP of the Router will automatically switch from 192.168.0.1 to 192.168.1.1 to avoid IP conflict; in this case, please try http://192.168.1.1:88. 3) Log in to the Router, click the “Forwarding” menu on the left of your browser, and click the "Virtual Servers" submenu.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Appendix B: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows XP. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed. 1. Install TCP/IP component 1) On the Windows taskbar, click the Start button, point to Settings, and then click Control Panel.
TL-WDR4300 4) N750 Wireless Dual Band Gigabit Router In the prompt page that showed below, double click on the Internet Protocol (TCP/IP). Figure B-2 5) The following TCP/IP Properties window will display and the IP Address tab is open on this window by default.
TL-WDR4300 6) N750 Wireless Dual Band Gigabit Router Select Obtain an IP address automatically and Obtain DNS server automatically, as shown in the Figure below: Figure B-3 - 123 -
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Appendix C: Specifications General Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, IEEE 802.3, IEEE 802.3u, IEEE 802.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router Appendix D: Glossary 802.11n - 802.11n builds upon previous 802.11 standards by adding MIMO (multiple-input multiple-output). MIMO uses multiple transmitter and receiver antennas to allow for increased data throughput via spatial multiplexing and increased range by exploiting the spatial diversity, perhaps through coding schemes like Alamouti coding. The Enhanced Wireless Consortium (EWC) [3] was formed to help accelerate the IEEE 802.
TL-WDR4300 N750 Wireless Dual Band Gigabit Router SSID - A Service Set Identification is a thirty-two character (maximum) alphanumeric key identifying a wireless local area network. For the wireless devices in a network to communicate with each other, all devices must be configured with the same SSID. This is typically the configuration parameter for a wireless PC card. It corresponds to the ESSID in the wireless Access Point and to the wireless network name.
