 Egress Bandwidth - The upload speed through the WAN port.
 Ingress Bandwidth - The download speed through the WAN port.
4.15.2 Rule List
Choose menu “Bandwidth Control
→
Rule List”, you can view and configure the Bandwidth
Control rules in the screen below.
Figure 4-74 Bandwidth Control Rule List
 Description - This is the information about the rules such as address range.
 Egress Bandwidth - This field displays the max and mix upload bandwidth through the WAN
port, the default is 0.
 Ingress Bandwidth - This field displays the max and mix download bandwidth through the
WAN port, the default is 0.
 Enable - This displays the status of the rule.
 Modify - Click Modify to edit the rule. Click Delete to delete the rule.
To add/modify a Bandwidth Control rule, follow the steps below.
Step 1: Click Add New… shown in Figure 4-74, you will see a new screen shown in Figure 4-75.
Step 2: Enter the information like the screen shown below.
Figure 4-75 Bandwidth Control Rule Settings
 Enable - Enable or disable the rule.
 IP Range - Interior PC address range. If both are blank (or 0.0.0.0), the domain is no
effective.
