TL-WR810N
300Mbps Wireless N Mini Router
- 117 -
Configure - The button is used for loading the item to the Wireless MAC Filtering list.
Allow - If the Wireless MAC Filtering function enable, allow the station to access.
Deny - If the Wireless MAC Filtering function enable, deny the station to access.
To update this page and to show the current connected wireless stations, click on the Refresh
button.
If the numbers of connected wireless stations go beyond one page, click the Next button to go to
the next page and click the Previous button to return the previous page.
Note:
This page will be refreshed automatically every 5 seconds.
5.7.6 Throughput Monitor
Choose menu “Wireless
→
Throughput Monitor”, and then you can see the wireless
throughput info.
Figure 5-16 Wireless Statistics
Rate - The Throughput unit.
Run Time - How long this function is running.
Transmit - Wireless transmit rate information.
Receive - Wireless receive rate information.
Click the Start button to start wireless throughput monitor.
Click the Stop button to stop wireless throughput monitor.
