TL-WR810N
300Mbps Wireless N Mini Router
- 151 -
Click the Next button to go to the next page and Click the Previous button to return the previous
page.
6.8 USB Settings
Figure 6-21 The USB Settings menu
There are four submenus under the USB Settings menu (shown in Figure 6-21), Storage Sharing,
FTP Server, Media Server and User Accounts. Click any of them, and you will be able to
configure the corresponding functions.
6.8.1 Storage Sharing
Choose menu “USB Settings
→
Storage Sharing”, you can configure a USB disk drive
attached to the router and view volume and share such properties as share name, capacity, used
space, and free space on this page as shown below.
Figure 6-22 Storage Sharing
Service Status - Indicates the Network Sharing service's current status. You can click the
Start button to start the Storage Sharing service and click the Stop button to stop it.
Volume - The volume name of the USB drive the users have access to. Volume 1-8 is
mapping to USB port1, and Volume 9-16 is mapping to USB port2.
Capacity - The storage capacity of the USB driver.
Used - The used space of the USB driver.
Free - The available space of the USB driver.
Use% - The percentage of the used space.
