TL-WR810N
300Mbps Wireless N Mini Router
- 6 -
Figure 2-1 Hardware Installation of the TL-WR810N in Standard Wireless Router Mode
1. Power off your Cable/DSL Modem.
2. Connect the LAN/WAN port of TL-WR810N to the LAN Port on the DSL/Cable Modem.
3. Connect the WAN port on the DSL/Cable Modem to the wired Internet.
4. Plug the power plug of TL-WR810N in electrical wall socket. The Router will start to work
automatically.
5. Power on the DSL/Cable Modem.
6. Connect your device to the router wirelessly or via an Ethernet cable. The Wi-Fi network
name and password are on the router’s label.
2.3.2 Access Point Mode
Create a wireless network from an Ethernet connection. This mode is suitable for dorm rooms or
homes where there's already a wired router but you need a wireless hotspot. (Note: if the hotel’s
Internet has an authentication process, you will need to authenticate it on EACH device.)
Figure 2-2 Hardware Installation of the TL-WR810N in Access Point Mode
