TL-WR810N
300Mbps Wireless N Mini Router
- 244 -
In Host field, select Host_1.
In Target field, select Target_1.
In Schedule field, select Schedule_1.
In Action field, select Allow.
In Status field, select Enabled.
Click Save to complete the settings.
Then you will go back to the Access Restriction Rule Management page and see the following list.
Figure 8-57 Rule Settings
8.13.2 Host
Choose menu “Access Control
→
Host”, you can view and set a Host list in the screen as
shown in Figure 8-58. The host list is necessary for the Access Restriction Rule.
Figure 8-58 Host Settings
Host Description - Here displays the description of the host and this description is unique.
Information - Here displays the information about the host. It can be IP or MAC.
Modify - To modify or delete an existing entry.
To add a new entry, please follow the steps below.
1. Click the Add New… button.
2. In the Mode field, select IP Address or MAC Address.
If you select IP Address, the screen shown is Figure 8-59.
1) In Host Description field, create a unique description for the host (e.g. Host_1).
2) In LAN IP Address field, enter the IP address.
If you select MAC Address, the screen shown is Figure 8-60.
1) In Host Description field, create a unique description for the host (e.g. Host_1).
2) In MAC Address field, enter the MAC address.
