Chapter 1
Get to Know About Your Router
The following parts (view from left to right) are located on the rear panel.
Item Description
USB 3.0 Ports
(Type A + Type C)
For connecting your USB storage devices to the router.
Reset Button
Use a pin to press and hold this button until the LED blinks to reset the router
to its factory default settings.
2.5 Giga WAN Port For connecting to a DSL/Cable modem, or an Ethernet jack.
Ethernet Ports For connecting your PC or other wired devices to the router.
Power On/Off Button Press this button to power on or off the router.
Power Port For connecting the router to a power socket via the provided power adapter.
Button Description
Name Description
(WPS Button)
Press this WPS button, and immediately press the WPS button on your client
device. The
LED of the router should change from pulsing white to solid
on, indicating successful WPS connection.
(Wi-Fi Button)
Press the Wi-Fi button to turn on or off the wireless function of your router.
(LED Button)
Press the LED button to turn on or off the LEDs of your router.
