TL-WA901ND 450Mbps Wireless N Access Point User Guide Package Contents The following items should be found in your package: One TL-WA901ND 450Mbps Wireless N Access Point One Power Injector Ethernet Cable One Power Adapter for TL-WA901ND 450Mbps Wireless N Access Point Quick Installation Guide One Resource CD for TL-WA901ND 450Mbps Wireless N Access Point, including: This User Guide Other helpful information Note: Make sure that the package contains the above items.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Chapter 1 Introduction 1.1 Product Overview The TL-WA901ND 450Mbps Wireless N Access Point is dedicated to Small Office/Home Office (SOHO) wireless network solutions. It allows for greater range and mobility within your wireless network while also allowing you to connect the wireless devices to a wired environment. Increased mobility and the absence of cabling will be beneficial for your network. With using IEEE 802.
TL-WA901ND 1.3 450Mbps Wireless N Access Point User Guide Main Features Wireless speed up to 450Mbps Supports Access Point, Multi-SSID, Client, Repeater(Universal Repeater)and Bridge with AP modes Up to 4 SSIDs and VLAN support Up to 30 meters (100 feet) of flexible deployment with included Power over Ethernet Injector Easily setup a WPA encrypted secure connection at a push of the WPS button Supports Remote and Web management Backward compatible with 802.11b/g products 1.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1.4.2 The Rear Panel Figure 1-2 Viewed from left to right, the following parts are located on the rear panel of TL-WA901ND. ON/OFF: The switch for the power. POWER: The power port connects to the power adapter provided with the TL-WA901ND 450Mbps Wireless N Access Point. Ethernet: One LAN 10/100Mbps RJ45 port connects to a network device, such as a switch or a router. WPS/RESET: This button is used for both WPS and Reset function.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Used as WPS button: If you have client devices, such as wireless adapters, that support Wi-Fi Protected Setup, then you can press this button to quickly establish a connection between the Access Point and client devices and automatically configure wireless security for your wireless network. Wireless antenna: The external antenna is used to transmit and receive wireless data.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Chapter 2 Hardware Installation 2.1 Before You Begin Please read this User Guide carefully before installing and using the equipment. The operating distance range of your wireless connection can vary significantly depending on the physical position of the wireless devices. Factors that can weaken signals by getting in the way of your network’s radio waves are metal appliances or obstructions, and walls.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 2-1 The Example of Infrastructure Network Incorporating the TL-WA901ND To establish a typical connection of the AP, please take the following steps: 1. Connect the Cable or DSL modem to a Router. 2. Locate an optimum location for the AP. The best place is usually near the center of the area in which your wireless devices like PCs, smart phones will wirelessly connect. 3. Adjust the direction of the antenna. Normally, upright is a good direction.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Note: The diameter of the screw, 3.5mm
TL-WA901ND 450Mbps Wireless N Access Point User Guide Chapter 3 Quick Installation Guide This chapter will guide you to configure your PC to communicate with the AP and to configure and manage the TL-WA901ND 450Mbps Wireless N Access Point easily with a Web-based utility. 3.1 Quick Setup With a Web-based utility, it is easy to configure and manage the TL-WA901ND 450Mbps Wireless N Access Point.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Note: If the above screen does not prompt, it means that your web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it. 2. After successfully logging in, the Quick Setup page will display. Click Next to continue. Figure 3-3 Quick Setup 3. The Quick Setup Start page will display. Click Next to continue.
TL-WA901ND 5. A. 450Mbps Wireless N Access Point User Guide In Access Point mode, the product will act as a wireless central hub for your wireless LAN clients, giving a wireless extension for your current wired network. In Repeater(Range Extender) mode, the product can extend the coverage of your main Router/AP. In Bridge with AP mode, the product can wirelessly connect two or more remote LANs together.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 3-7 AP List 1) Find the SSID of the Access Point / Router or WISP which you want you to connect to, and click Connect in the corresponding row. You will then see the page shown in Figure 3-8. 2) Select the security mode and enter the password that is the same as on your router or access point in Figure 3-8. 3) Click Next, you will then come to Network Settings page for furthers configuration.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 3-9 AP List 1) Find the SSID of the Access Point / Router or WISP which you want you to connect to, and click Connect in the corresponding row. You will then see the page shown in Figure 3-10. 2) Select the security mode and enter the password that is the same as on your router or access point in Wireless Bridge Setting. 3) You can name the bridge AP in Local Wireless Name, and configure the Local Wireless Setting for the bridge AP.
TL-WA901ND D. 450Mbps Wireless N Access Point User Guide When you choose Client mode, the AP will detect the wireless networks in your neighborhood, and then the window displaying a list of available SSIDs will appear in Figure 3-11. Figure 3-11 AP List 1) Find the SSID of the Access Point / Router or WISP which you want you to connect to, and click Connect in the corresponding row. You will then see the page shown in Figure 3-12.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 3-13 Wireless Setting – Multi-SSID mode You are suggested to implement Multi-SSID function with a switch that supports Tag VLAN feature. For advanced configuration of this step, please refer to explanations of this mode in 4.6.1 Wireless Settings. 6. When you have configured Wireless Settings in step 4, The Network Settings page will appear then, shown in Figure 3-14. It is recommended that you keep the default settings on this page.
TL-WA901ND 7. 450Mbps Wireless N Access Point User Guide Click the Next button. You will then see the Finish page. Here takes the settings for Access Point mode for example. Check your settings and click Save to save your settings for future reference. Click the Finish button to finish the configuration of the Access Point.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Chapter 4 Configure the Device This Chapter describes how to configure your Access Point via the web-based management page. The TL-WA901ND 450Mbps Wireless N Access Point is easy to configure and manage with the Web-based (Internet Explorer, Netscape® Navigator, Firefox, Safari, Opera or Chrome) management page, which can be launched on any windows, Macintosh or UNIX OS with a web browser. 4.1 Login Open your web browser. Type in http://tplinkap.
TL-WA901ND 4.2 450Mbps Wireless N Access Point User Guide Status Selecting Status will enable you to view the AP’s current status and configuration, all of which is read-only. Figure 4-3 Device Status Firmware Version - This field displays the current firmware version of the AP. Hardware Version - This field displays the current hardware version of the AP Wired - This field displays the current settings or information for the Network, including the MAC address, IP address and Subnet Mask.
TL-WA901ND 450Mbps Wireless N Access Point User Guide System Up Time - This filed displays the run time of the AP since it’s powered on or reset. Note: If you select Client mode in Figure 4-14, the wireless status in Figure 4-3 will change, similar to the figure below: Figure 4-4 Device Status - Client 4.3 Quick Setup Please refer to Section 3.1 Quick Setup for more details. 4.4 WPS WPS (Wi-Fi Protected Setup) can help you to quickly and securely connect to a network.
TL-WA901ND 450Mbps Wireless N Access Point User Guide device can be found in the label or User Guide. Restore PIN - Restore the PIN of the device to its default. Gen New PIN - Click this button, and then you can get a new random value for the device's PIN. You can ensure the network security by generating a new PIN. Disable PIN of this device - WPS external register of entering the device’s PIN can be disabled or enabled manually.
TL-WA901ND 450Mbps Wireless N Access Point User Guide The WPS Configuration Screen of Wireless Adapter Method Two: Step 1: Press the WPS/RESET button on the rear panel of the device. Step 2: For the configuration of the wireless adapter, please choose “Push the button on my access point or wireless router.” in the configuration utility of the WPS as below, and click Next. The WPS Configuration Screen of Wireless Adapter Step 3: Wait for a while until the next screen appears.
TL-WA901ND 450Mbps Wireless N Access Point User Guide The WPS Configuration Screen of Wireless Adapter Method Three: Step 1: Keep the default WPS Status as Enabled and click the Add device button in Figure 4-5, then the following screen will appear. Figure 4-6 Add A New Device Step 2: Choose “Press the button of the new device in two minutes” and click Connect.
TL-WA901ND 450Mbps Wireless N Access Point User Guide The WPS Configuration Screen of Wireless Adapter Step 4: Wait for a while until the next screen appears. Click OK to complete the WPS configuration. The WPS Configuration Screen of Wireless Adapter II. By PIN If the new device supports Wi-Fi Protected Setup and the PIN method, you can add it to the network by PIN with the following two methods.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 4-7 Enter the PIN Step 2: Choose “Enter the new device's PIN” and enter the PIN code (take 16952898 for example) of the wireless adapter in the field after PIN as shown in the figure above. Then click Connect. Note: The PIN code of the adapter is always displayed on the WPS configuration screen as shown in the following figure.
TL-WA901ND 450Mbps Wireless N Access Point User Guide enter the PIN code of the AP into the field after “Access Point PIN”. Then click Next. The WPS Configuration Screen of Wireless Adapter Note: The default PIN code of the AP can be found in its label or the WPS configuration screen as Figure 4-5 . You will see the following screen when the new device has successfully connected to the network. Note: 1.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4.5.1 LAN The Network option allows you to customize your local network manually by changing the default settings of the AP. Selecting Network will enable you to configure the IP parameters of Network on this page. Figure 4-8 Network MAC Address - The physical address of the AP. The value can't be changed.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 4-9 DHCP Settings DHCP Server - Selecting the radio button before Disable/Enable will disable/enable the DHCP server on your AP. The default setting is Enable. If you disable the Server, you must have another DHCP server within your network or else you must manually configure the computer. Start IP Address - This field specifies the first address in the IP Address pool. 192.168.0.100 is the default start IP address.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4.5.3 DHCP Client List Selecting DHCP > DHCP Client List will enable you to view the Client Name, MAC Address, Assigned IP and Lease Time for each DHCP Client attached to the device (Figure 4-10). Figure 4-10 DHCP Clients List ID - Here displays the index of the DHCP client. Client Name - Here displays the name of the DHCP client. MAC Address - Here displays the MAC address of the DHCP client.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 4-11 Wireless menu 4.6.1 Wireless Settings Selecting Wireless > Wireless Settings will enable you to configure the basic settings for your wireless network on the screen below (Figure 4-12).This page allows you to configure the wireless mode for your device. Six operation modes are supported here, including Access Point, Multi-SSID, Client, WDS Repeater, Universal Repeater and Bridge with AP.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Note: Limited by local law regulations, version for North America does not have region selection option. Channel - Determines the operating frequency to be used. It is not necessary to change the wireless channel unless you notice interference problems with another nearby access point. Mode - Select the desired wireless mode. The options are: • 11b only - Only 802.11b wireless stations can connect to the device. • 11g only - Only 802.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 2) Multi-SSID: This mode allows the device to support up to four SSIDs. Figure 4-13 Wireless Settings in Multi-SSID mode Enable VLAN - Check this box and then you can change the VLAN ID of each SSID. If you want to configure the Guest and Internal networks on VLAN, the switch you are using must support VLAN. As a prerequisite step, configure a port on the switch for handling VLAN tagged packets as described in the IEEE802.
TL-WA901ND 450Mbps Wireless N Access Point User Guide wireless channel unless you notice interference problems with another nearby access point. Mode - This field determines the wireless mode which the device works on. • 11b only - Only 802.11b wireless stations can connect to the device. • 11g only - Only 802.11g wireless stations can connect to the device. • 11n only - Only 802.11n wireless stations can connect to the device. • 11bg mixed - Both 802.11b and 802.
TL-WA901ND 1. 450Mbps Wireless N Access Point User Guide Configure the Access Point Configure the Access Point Select Multi-SSID as the operation mode of TL-WA901ND. Select the checkbox before Enable VLAN to enable VLAN function for this access point. Configure the SSID and its corresponding VLAN ID. The detailed parameters are shown as the above figure. STA1, STA2, STA3 and STA4 join to the wireless network with SSID1, SSID2, SSID3 and SSID4 respectively.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 2. Configure the Switch. Enable 802.1Q Tag VLAN function on the switch. Make sure the Untag frames are forwarded.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Note: If the LAN port of TL-WA901ND is not connected to a switch but directly to a PC, 1. The PC can directly log on to the Web management page of TL-WA901ND and manage the access point. 2. Only the wireless STA with its VLAN ID set to 1 can communicate with the wired PC. 3) Client: This mode allows the device to act as a wireless station to enable wired host(s) to access an AP.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Click the Survey button to detect the SSIDs in the local area. Note: To apply any settings you have altered on the page, please click the Save button, and then you will be reminded to reboot the device. 4) WDS Repeater: In WDS Repeater mode, the AP with WDS enabled will relay data to an associated root AP. AP function is enabled meanwhile. The wireless repeater relays signal between its stations and the root AP for greater wireless range.
TL-WA901ND 450Mbps Wireless N Access Point User Guide • 11n only - Only 802.11n wireless stations can connect to the device. • 11bg mixed - Both 802.11b and 802.11g wireless stations can connect to the device. • 11bgn mixed - All 802.11b, 802.11g and 802.11n wireless stations can connect to the device. Channel Width - Determines the channel width to be used. It is unnecessary to change the default value unless required.
TL-WA901ND 450Mbps Wireless N Access Point User Guide the device in a region other than one of those specified in this field. If your country or region is not listed, please contact your local government agency for assistance. Note: Limited by local law regulations, version for North America does not have region selection option. Mode - Select the desired wireless mode. The options are: • 11b only - Only 802.11b wireless stations can connect to the device. • 11g only - Only 802.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 6) Bridge with AP: This mode can bridge the AP and up to 4 APs also in bridge mode to connect two or more wired LANs. Figure 4-17 Wireless Settings in Bridge with AP mode Wireless Bridge Settting Wireless Name of Remote AP - If you select the radio button before Wireless Name of Remote AP, the AP client will connect to the AP according to SSID. Enter the SSID of AP that you want to access.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Region - Select your region from the pull-down list. This field specifies the region where the wireless function of the device can be used. It may be illegal to use the wireless function of the device in a region other than one of those specified in this field. If your country or region is not listed, please contact your local government agency for assistance.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1) Access Point Figure 4-18 Wireless Security - Access Point Disable Security - Check this box radio button to disable wireless security. If disabled, the wireless stations will be able to connect this device without encryption. It is strongly recommended that you choose one of the security types to enable security. WPA/WPA2-Personal(Recommended) - Select WPA/WPA2 based on Radius Server. • Version - You can select one of following versions.
TL-WA901ND • 450Mbps Wireless N Access Point User Guide Group Key Update Period - Specify the group key update interval in seconds. The value can be either 0 or at least 30. Enter 0 to disable the update. WPA/WPA2-Enterprise - Select WPA/WPA2 based on Radius Server. • Version - You can select one of following versions. 1) Automatic - Select WPA or WPA2 automatically based on the wireless station's capability and request. 2) WPA - Wi-Fi Protected Access. 3) WPA2 - WPA version 2.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 2) Multi-SSID Figure 4-19 Wireless Security – Multi-SSID You can choose which SSID to configure wireless security settings for in the blank behind Operation Mode. Disable Security - Check this box radio button to disable wireless security. If disabled, the wireless stations will be able to connect this device without encryption. It is strongly recommended that you choose one of the security types to enable security.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1) Automatic - Select WPA or WPA2 automatically based on the wireless station's capability and request. 2) WPA - Wi-Fi Protected Access. 3) WPA2 - WPA version 2. • Encryption - You can select either Automatic, TKIP or AES. • Radius Server IP - Enter the IP address of the Radius Server. • Radius Port - Enter the port used by radius service. • Radius Password - Enter the password for the Radius Server.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1) Automatic(Recommended) - Select WPA-Personal or WPA2-Personal automatically based on the wireless station's capability and request. 2) WPA-PSK - Pre-shared key of WPA. 3) WPA2-PSK - Pre-shared key of WPA2. • Encryption - You can select either Automatic(Recommended), TKIP or AES. • Wireless Password - You can enter ASCII or Hexadecimal characters.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4) WDS Repeater Figure 4-21 Wireless Security – Repeater Disable Security - Check this box radio button to disable wireless security. If disabled, the wireless stations will be able to connect this device without encryption. It is strongly recommended that you choose one of the security types to enable security. WPA/WPA2-Personal(Recommended) - Select WPA/WPA2 based on Radius Server. • Version - You can select one of following versions.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1) Automatic - Select Shared Key or Open System authentication type automatically based on the wireless station's capability and request. 2) Shared Key - Select 802.11 Shared Key authentication type. 3) Open System - Select 802.11 Open System authentication. • WEP Key Format - You can select ASCII or Hexadecimal format. ASCII format stands for any combination of keyboard characters in the specified length.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 5) Universal Repeater Figure 4-22 Wireless Security – Repeater Disable Security - Check this box radio button to disable wireless security. If disabled, the wireless stations will be able to connect this device without encryption. It is strongly recommended that you choose one of the security types to enable security. WPA/WPA2-Personal(Recommended) - Select WPA/WPA2 based on Radius Server.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 1) Automatic - Select Shared Key or Open System authentication type automatically based on the wireless station's capability and request. 2) Shared Key - Select 802.11 Shared Key authentication type. 3) Open System - Select 802.11 Open System authentication. • WEP Key Format - You can select ASCII or Hexadecimal format. ASCII format stands for any combination of keyboard characters in the specified length.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 6) Bridge with AP Figure 4-23 Wireless Security – Bridge with AP Disable Security - Check this box radio button to disable wireless security. If disabled, the wireless stations will be able to connect this device without encryption. It is strongly recommended that you choose one of the security types to enable security. WPA/WPA2-Personal(Recommended) - Select WPA/WPA2 based on Radius Server. • Version - You can select one of following versions.
TL-WA901ND • 450Mbps Wireless N Access Point User Guide Group Key Update Period - Specify the group key update interval in seconds. The value can be either 0 or at least 30. Enter 0 to disable the update. WPA/WPA2-Enterprise - Select WPA/WPA2 based on Radius Server. • Version - You can select one of following versions. 1) Automatic - Select WPA or WPA2 automatically based on the wireless station's capability and request. 2) WPA - Wi-Fi Protected Access. 3) WPA2 - WPA version 2.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4.6.3 Wireless MAC Filtering Selecting Wireless > Wireless MAC Filtering will allow you to set up some filtering rules to control wireless stations accessing the device, which depend on the station’s MAC address on the following screen as shown Figure 4-24. This function is not available when the operation is set to Client. As the configuration is the same in each operation mode, here we just take the Access Point for example.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Status - Select a status for this entry, either Enabled or Disabled. To set up an entry, follow these instructions: First, you must decide whether the unspecified wireless stations can access the device or not.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Note: If you enable the function and select the “Allow the stations specified by any enabled entries in the list to access” for Filtering Rules, and there are not any enabled entries in the list, thus, no wireless stations can access the device. 4.6.4 Wireless Advanced Selecting Wireless > Wireless Advanced will allow you to do some advanced settings for the device in the following screen shown in Figure 4-26.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Enable AP Isolation - Isolates all connected wireless stations so that wireless stations cannot access each other through WLAN. This function will be disabled if WDS/Bridge is enabled. 4.6.5 Wireless Statistics Selecting Wireless > Wireless Statistics will allow you to see the wireless transmission information in the following screen shown in Figure 4-27.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 4-28 Throughput Monitor Rate - The Throughput unit. Run Time - How long this function is running. Transmit - Wireless transmit rate information. Receive - Wireless receive rate information. Click the Start button to start wireless throughput monitor. Click the Stop button to stop wireless throughput monitor. 4.7 System Tools System Tools option helps you to optimize the configuration of your device.
TL-WA901ND 450Mbps Wireless N Access Point User Guide There are nine submenus under the System Tools menu (shown as Figure 4-29): Time Settings, Diagnostic, Ping Watch Dog, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot, Password, System Log and Statistics. Clicking any of them will enable you to configure the corresponding function. The detailed explanations for each submenu are provided below. Figure 4-29 The System Tools menu 4.7.
TL-WA901ND 450Mbps Wireless N Access Point User Guide SNMP Agent - Select the radio button before Enable will enable this function if you want to have remote control through SNMPv1/v2 agent with MIB-II. Select the radio button before Disable will disable this function. The default setting is Disable. SysContact - The textual identification of the contact person for this managed node. SysName - An administratively-assigned name for this managed node.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Figure 4-31 Diagnostic Diagnostic Tools - Click the radio button to select one diagnostic tool • Ping - This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a given host or gateway by using the Internet Control Message Protocol (ICMP) protocol's mandatory Echo Request datagram to elicit an ICMP Echo Response from a host or gateway. You can use ping to test both numeric IP address or domain name.
TL-WA901ND 450Mbps Wireless N Access Point User Guide IP Address - Enter the IP Address (such as 202.108.22.5) of the PC whose connection you wish to diagnose. Ping Count - Specifies the number of Echo Request messages sent. The default is 4. Ping Packet Size - Specifies the number of data bytes to be sent. The default is 64. Ping Timeout - Specifies the time to wait for a response in milliseconds. The default is 800.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Enable - Turn on/off Ping Watch Dog. IP Address - The IP address of the target host where the Ping Watch Dog Utility is sending ping packets. Interval - Time internal between two ping packets which are sent out continuously. Delay - Time delay before first ping packet is sent out when the device is restarted. Fail Count - Upper limit of the ping packet the device can drop continuously.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4.7.5 Factory Defaults Selecting System Tools > Factory Defaults allows you to restore the factory default settings for the device on the screen shown in Figure 4-35. Figure 4-35 Restore Factory Defaults Click Restore to reset all configuration settings to their default values. • Default User Name: admin • Default Password: admin • Default IP Address: 192.168.0.254 • Default Subnet Mask: 255.255.255.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 4.7.7 Reboot Selecting System Tools > Reboot allows you to reboot the device on the screen shown in Figure 4-37. Figure 4-37 Reboot the device Click the Reboot button to reboot the device. Some settings of the device will take effect only after rebooting, which include: • Change LAN IP Address (System will reboot automatically). • Change the Wireless configurations. • Change the Web Management Port.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Click Save when finished. Click Clear All to clear all. 4.7.9 System Log Selecting System Tools > System Log allows you to query the Logs of the device on the screen shown in Figure 4-39. Figure 4-39 System Log The device can keep logs of all traffic. You can query the logs to find what happened to the device. Log Type - By selecting the log type, only logs of this type will be shown.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Appendix A: Application Example The TL-WA901ND allows you to connect a wireless device to the wired network. Providing that you want to connect your computer equipped with wireless adapter to a wired network wirelessly, you can take the following instructions. 1. 2. Configure the AP via a wired connection. 1) Connect your AP to your PC with an Ethernet cable. 2) Log on to the web-based management page.
TL-WA901ND 450Mbps Wireless N Access Point User Guide 2) On the My Network Connections window, right-click Wireless Network and choose Enable to enable wireless network function. 3) Right-click the wireless connection icon “ View Available Wireless Networks. 4) Highlight the SSID of the AP (Here is TP-LINK) and click Connect to add to the network.
TL-WA901ND 5) 450Mbps Wireless N Access Point User Guide Then the following page will display, which indicates you have been successfully added to the network wirelessly.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Appendix B: Factory Defaults Item Default Value Common Default Settings Login Username admin Login Password admin IP Address 192.168.0.254 Subnet Mask 255.255.255.0 Wireless SSID TP-LINK_AP_XXXX Wireless Security Disable Wireless MAC Address Filtering Disable DHCP DHCP Server Enable Start IP Address 192.168.0.100 End IP Address 192.168.0.199 Domain Name http://tplinkap.net Default Gateway (optional) 0.0.0.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Appendix C: Troubleshooting T1. How do I restore my Access Point’s configuration to its factory default settings? With the Access Point powered on, use a pin to press and hold the WPS/RESET button on the rear panel for more than 8 seconds before releasing it. Note: Once the Access Point is reset, the current configuration settings will be lost and you will need to reconfigure the Access Point. T2.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Appendix D: Specifications General Standards and Protocols IEEE 802.3, 802.3u, 802.11n, 802.11b and 802.11g, TCP/IP, DHCP Safety & Emission FCC, CE Ports One 10/100M Auto-Negotiation RJ45 port, supporting passive PoE Cabling Type 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Wireless Frequency Band 2.4~2.
TL-WA901ND 450Mbps Wireless N Access Point User Guide Appendix E: Glossary 802.11n - 802.11n builds upon previous 802.11 standards by adding MIMO (multiple-input multiple-output). MIMO uses multiple transmitter and receiver antennas to allow for increased data throughput via spatial multiplexing and increased range by exploiting the spatial diversity, perhaps through coding schemes like Alamouti coding. The Enhanced Wireless Consortium (EWC) [3] was formed to help accelerate the IEEE 802.
TL-WA901ND 450Mbps Wireless N Access Point User Guide key technologies behind WPA is the Temporal Key Integrity Protocol (TKIP). TKIP addresses the encryption weaknesses of WEP. Another key component of WPA is built-in authentication that WEP does not offer. With this feature, WPA provides roughly comparable security to VPN tunneling with WEP, with the benefit of easier administration and use. This is similar to 802.1x support and requires a RADIUS server in order to implement.
