DC/DC Converters
TEP 160 Series 150 – 196 Watt
0.20 0.5
0.023
2.40
2.00
0.30
0.70
1.00
1.900.19
2.28
(57.9)
1
2
3
4
5
6
8
9
7
4 x M3 THD
(48.26)(4.8)
(50.80)
(61.0)
(17.78)
(12.7)
(25.40)
Bottom view
(7.62)
(0.6)
(5.1)
(trough hole)
Top view
0.95
0.45
(24.2)
(11.4)
2.40 (61.0)
2.28 (57.9)
TEP 160 module
Dimensions in Inch, () = mm
Tolerances ±0.02 (±0.5)
Pin pich tolerances ±0.01 (±0.25)
Mounting hole pich tolerances ±0.01 (±0.25)
Weight: 105g (3.70oz)
Pin-Out
*Sense line to be connected
to the output either at the
module or at the load under
regard of polarity.
Weight: 142 g (5.01oz)
(Heatsink + Converter)
Order code: TEP-HS1
Includes heatsink with termal pad and mounting screws
To order modules with mounted heatsink ask factory.
Pin diameter pin 5 & 9: 0.08 (2.0)
Pin diameter other pins: 0.04 (1.0)
Dimensions
Pin
1
– Vin
2
Case
3
Remote On/Off
4
+ Vin
5
– Vout
6
– Sense*
7
Trim
8
+ Sense*
9
+ Vout
TEP-HS1 Heatsink (pictured with heatsink mounted)
