User's Manual

3
Note: When charging the reader, tag read performance may be
degraded. TransCore recommends that you do not attempt to read
tags while the reader is charging.
Battery Status Light-Emitting Diode Indicator
The charger LED indications are as follows:
Color
Definition
Red
Charger is connected and charging
Green
Battery is fully charged
Blinking Red
Warning, low battery
Yellow
Charger detected but the battery charger temperature is too
high or too low to recharge. Charging will start when battery
temperature is within specifications
Blinking Yellow
Charging disabled by the application program.
No Light
Power from the charger not detected.
TransCore recommends that you charge the Encompass 1d reader after each
shift.
2. Power up the office cradle by plugging the round connector of
the modular charger into the office cradle (Figure 3).
Figure 3. Ethernet Office Cradle with Charger
3. Slide the Encompass 1d Handheld Reader into the cradle
(Figure 4).
