D-3
Appendix D
Hardware Interfaces
This appendix describes the physical interconnections within an MPI
6000 System.
Hardware Interfaces
This appendix describes the hardware interfaces in the MPI 6000 and to external com-
ponents, such as antennas.
Figure D-1 shows the basic hardware interconnections for the MPI 6000.
Figure D-1 MPI 6000 Hardware Interconnection Block Diagram
