MPI 6000 Multi-Protocol Reader System Guide
D-8
• Connector E22, RF system test data is the same as connector B11 on the digital
board.
• Connector E29, RF system test data is the same as connector B11 on the digital
board. This connector is used to connect the data cables from the MPI 6000 to the
antenna multiplexer board and the RF system test boards.
• Connector E23 is the RF in signal.
Table D-7 RF System Test Connector Pin-out
Pin Signal Description
1 RF Input/Output RF input output signal
