General Software Information
6-5
Diagnostic RS–232 Serial Communications
The MPI 6000 can communicate via a serial, RS–232, communications protocol
(
Table 6-4). The diagnostic RS–232 port can be used to display the operating system
boot sequence.
If you connect the MPI 6000 directly to a host PC serial port, you must use a null-
modem connector.
Diagnostic Commands (Mike?)
By using the version command, you can display data about the configuration of the
MPI 6000 including its Internet protocol (IP) address.
The RS-232 diagnostic connector can be used to check the external input/output sta-
tus. Table 6-5 lists this connector pin assignments.
Table 6-3 RS-232B/TDM Connector Parameters
Pin Signal Description
1 TXD Transmit Data
2 RXD Receive Data
3 DTR Data Terminal Ready (not connected)
4 RTS Request to Send
5 CTS Clear to Send
6 GND Ground
7 TDM + TDM positive signal
8 TDM - TDM negative signal
Table 6-4 RS-232 Connector Specifications
Connector Type
9 pin D-sub male
Protocol
RS-232
Baud
9600
Bits
8
Parity
None
Stop Bits
1
Flow Control
None
