Configuration Commands and Responses
7-5
System Interface Command Group Commands
This section describes the system commands used to configure the MPI 6000.
Each of the system command group commands is listed in this section.
Table 7-4 System Interface Command Group
System Interface Command Command Code
System Identify 0000H
Set Communications Baud Rate 0001H
Get Communications Baud Rate 0002H
Set Time and Date 0003H
Get Time and Date 0004H
Firmware Download 0005H
Reset Reader 0006H
Get Stored Tag Response Message 0007H
Get Number of Stored Tag Response Messages 0008H
Delete All Stored Tag Response Messages 0009H
Get System Startup Status 000AH
Get Lane Controller Interface Status 000BH
Get System Interface Status 000CH
Get DigBrd Hdwr Remote Inventory 000DH
Get DigBrd CPU Boot Fmwr Remote Inventory 000EH
Get DigBrd CPU Appl Fmwr Remote Inventory 000FH
Get DigBrd FPGA UDP/IP Core Fmwr Remote Inventory 0010H
Set UDP/IP Core Lane Controller IP Address and Port Number Parameters 0011H
Get UDP/IP Core Lane Controller IP Address and Port Number Parameters 0012H
Set UDP/IP Core IP Address 0013H
Get UDP/IP Core IP Address 0014H
Get UDP/IP Core UDP Port Number 0015H
