MPI 6000 Multi-Protocol Reader System Guide
7-6
System Identify
System Identify Data Sizes
Set Communications Baud Rate
System Identify Command Data
Data
Payload
System Identify Command 0000H
System Identify Response Data
Data
Payload
System Identify Command 0000H
Vendor Name
Version ID
Part Number
Serial Number
System Identify Data
Data
Size
Vendor Name 15 Bytes
Version ID 15 Bytes
Part Number 15 Bytes
Serial Number 15 Bytes
Set Communications Baud Rate Command Data
Data
Payload
Set Communications Baud Rate Command 0001H
Baud Rate Data Code XXH
