Configuration Commands and Responses
7-7
Baud Rate Data Codes
Get Communications Baud Rate
Set Communications Baud Rate Response Data
Data
Payload
Set Communications Baud Rate Command 0001H
Baud Rate
Data
Code
19,200 bps 0CH
38,400 bps (System Default) 0DH
57,600 bps 0EH
115,200 bps 0FH
Get Communications Baud Rate Command Data
Data
Payload
Get Communications Baud Rate Command 0002H
Get Communications Baud Rate Response Data
Data
Payload
Get Communications Baud Rate Command 0002H
Baud Rate Data Code XXH
