MPI 6000 Multi-Protocol Reader System Guide
7-8
Set Time and Date
Time and Date Data Ranges
Set Time and Data Command Data
Data
Payload
Set Time and Date Command 0003H
Hours XXH
Minutes XXH
Seconds XXH
Hundredths of Seconds XXH
Month XXH
Day XXH
Ye a r XXH
Set Time and Data Response Data
Data
Payload
Set Time and Date Command 0003H
Time and Date Data Data Range
Hours 0 to 23 (00H to 17H)
Minutes 0 to 59 (00H to 3BH)
Seconds 0 to 59 (00H to 3BH)
Hundredths of Seconds 0 to 99 (00H to 63H)
Month 1 to 12 (01H to 0CH)
Day 1 to 31 (01H to 1FH)
Ye a r 0 to 99 (00H to 63H)
