MPI 6000 Multi-Protocol Reader System Guide
7-10
The Firmware Download command is implemented as defined for
both UDP/IP Fast Ethernet and serial communications.
Reset Reader
Get Stored Tag Response Message
Reset Reader Command Data
Data
Payload
Reset Reader Command 0006H
Reset Reader Control Word A5A5H
Reset Reader Response Data
Data
Payload
Reset Reader Command 0006H
Get Stored Tag Response Message Command Data
Data
Payload
Get Stored Tag Response Message Command 0007H
Stored Tag Response Message Number XXXXH
Get Stored Tag Response Message Response Data
Data
Payload
Get Stored Tag Response Message Command 0007H
Stored Tag Response Message Number XXXXH
Stored Tag Response Message Data
