MPI 6000 Multi-Protocol Reader System Guide
7-16
Set UDP/IP Core Lane Controller Parameters
Get UDP/IP Core Lane Controller Parameters
Firmware Remote Inventory Data
Data
Size
Vendor Name 15 Bytes
Version ID 15 Bytes
Part Number 15 Bytes
Set UDP/IP Core Lane Controller Parameters Command Data
Data
Payload
Set UDP/IP Core Lane Controller Parameters Command 0011H
IP Address (MSW) XXXXH
IP Address (LSW) XXXXH
Port Number XXXXH
Set UDP/IP Core Lane Controller Parameters Response Data
Data
Payload
Set UDP/IP Core Lane Controller Parameters Command 0011H
Get UDP/IP Core Lane Controller Parameters Command Data
Data
Payload
Get UDP/IP Core Lane Controller Parameters Command 0012H
