owner’s manual B R U S H L E S S MODEL 7007 B R U S H L E S S B R U S H L E S S MODEL 7107
INTRODUCTION 3 BEFORE YOU PROCEED 4 SAFETY PRECAUTIONS 5 TOOLS, SUPPLIES AND REQUIRED EQUIPMENT 5 DECORATING YOUR MODEL 6 ANATOMY OF THE 1/16 SLASH VXL 4WD 7 ANATOMY OF THE 1/16 E-REVO VXL 8 QUICK START: GETTING UP TO SPEED 9 TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM 17 ADJUSTING THE ELECTRONIC SPEED CONTROL 19 DRIVING YOUR MODEL 22 TUNING ADJUSTMENTS 27 MAINTAINING YOUR MODEL 28 TQ 2.
BEFORE YOU PROCEED Carefully read and follow all instructions in this and any accompanying materials to prevent serious damage to your model. Failure to follow these instructions will be considered abuse and/or neglect. SUPPORT Before running your model, look over this entire manual and examine the model carefully. If for some reason you decide it is not what you wanted, then do not continue any further. Your hobby dealer absolutely cannot accept a model for return or exchange after it has been run.
el = Myriad Semi Bold SAFETY PRECAUTIONS All instructions and precautions outlined in this manual should be strictly followed to ensure safe operation of your model. All of us at Traxxas want you to safely enjoy your new model. Operate your model sensibly and with care, and it will be exciting, safe, and fun for you and those around you. Failure to operate your model in a safe and responsible manner may result in property damage and serious injury.
TOOLS, SUPPLIES AND REQUIRED EQUIPMENT Your model comes with a set of specialty metric tools. You’ll need to purchase other items, available from your hobby dealer, to operate and maintain your model. SUPPLIED TOOLS AND EQUIPMENT 1.5mm “L” wrench 2.0mm “T” wrench REQUIRED EQUIPMENT (sold separately) 2.
ANATOMY OF THE 1/16 SLASH VXL 4WD Battery Compartment Vent Rear Half Shaft Hex Hub Battery Door Release Tab Turnbuckle Pivot Ball Antenna Mount Battery Compartment Door Rear Body Mount Axle Carrier Light Pipe Rear Bumper Receiver Box Slipper Clutch Turnbuckle Push Rod Rocker Front Bumper Front Body Mount Rocker Push Rod Rear Suspension Arm Electronic Speed Control (VXL-3m) Oil Shock (Damper) Motor (Velineon® 380) Transmission Front Suspension Arm Steering Servo Traxxas High-Current Connecto
ANATOMY OF THE 1/16 E-REVO VXL Rear Half Shaft Battery Compartment Vent Hex Hub Battery Door Release Tab Turnbuckle Antenna Mount Rear Body Mount Pivot Ball Battery Compartment Door Light Pipe Wing Axle Carrier Receiver Box Slipper Clutch Turnbuckle Push Rod Rocker Front Bumper Front Body Mount Electronic Speed Control (VXL-3m) Rocker Oil Shock (Damper) Motor (Velineon® 380) Traxxas High-Current Connector Push Rod Front Suspension Arm Transmission Rear Suspension Arm Steering Servo Ch
QUICK START: GETTING UP TO SPEED The Quick Start Guide is not intended to replace the full operating instructions available in this manual. Please read this entire manual for complete instructions on the proper use and maintenance of your model. The following guide is an overview of the procedures for getting your model running. Look for the Quick Start logo on the bottom corners of Quick Start pages. 1.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM INTRODUCTION Your model includes the latest in Traxxas 2.4GHz transmitter technology. The transmitter’s easy-to-use design provides instant driving fun for new R/C enthusiasts, and also offers a full compliment of pro-level tuning features for advanced users – or anyone interested in experimenting with the performance of their model. The steering and throttle channels feature adjustable Exponential, End Points, and Sub-Trims.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM To prevent loss of radio range do not kink or cut the black wire, do not bend or cut the metal tip, and do not cut the white wire at the end of the metal tip. NiMH - Abbreviation for nickel-metal hydride. Rechargeable NiMH batteries offer high current handling, and much greater resistance to the “memory” effect. NiMH batteries generally allow higher capacity than NiCad batteries. They can last up to 500 charge cycles.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM Your model is equipped with the newest Traxxas 2.4 GHz transmitter with Traxxas Link.™ The transmitter has two channels for controlling your throttle and steering. The receiver inside the model has 5 output channels. Your model is equipped with one servo and an electronic speed control. TQ 2.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM INSTALLING TRANSMITTER BATTERIES If the power indicator doesn’t light green, check the polarity of the batteries. Check rechargeable batteries for a full charge. If you see any other flashing signal from the LED, refer to the chart on page 29 to identify the code. Your TQ transmitter uses 4 AA batteries. The battery compartment is located in the base of the transmitter. Use the Right Batteries Your transmitter uses AA batteries.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM The Traxxas High Current Connector Your model is equipped with the patented Traxxas High-Current Connector. Standard connectors restrict current flow and are not capable of delivering the power needed to maximize the output of the Velineon Brushless Power system. The Traxxas connector’s gold-plated terminals with a large contact surfaces ensure positive current flow with the least amount of resistance.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM TQ 2.4GHz RADIO SYSTEM CONTROLS Remember, always turn the TQ transmitter on first and off last to avoid damage to your model. Automatic Fail-Safe The TQ 2.4GHz transmitter and receiver are equipped with an automatic failsafe system that does not require user programming. In the event of signal loss or interference, the throttle will return to neutral and the steering will hold its last commanded position.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM The TQ 2.4GHz Radio System has been pre-adjusted at the factory. The adjustment should be checked before running the model, in case of movement during shipping. Here’s how: 7. Gently operate the throttle trigger to ensure that you have forward and reverse operation, and that the motor stops when the throttle trigger is at neutral. Warning: Do not apply full throttle in forward or reverse while the model is elevated. 1. Turn the transmitter switch on.
TRAXXAS TQ 2.4GHz RADIO & VELINEON Power SYSTEM TQ 2.4GHz Binding Instructions For proper operation, the transmitter and receiver must be electronically ‘bound.’ This has been done for you at the factory. Should you ever need to re-bind the system or bind to an additional transmitter or receiver, follow these instructions. Note: the receiver must be connected to a 4.8-6.0v (nominal) power source for binding and the transmitter and receiver must be within 5 feet of each other.
ADJUSTING THE ELECTRONIC SPEED CONTROL The electronic speed control is factory set and should not require any adjustments. These instructions are provided for your reference. Transmitter Adjustments for the electronic speed control Before attempting to program your ESC, it is important to make sure your TQ transmitter is properly adjusted (set back to the factory defaults). Otherwise, you may not get the best performance from your speed control.
ADJUSTING THE ELECTRONIC SPEED CONTROL Patent Pending Training Mode (Profile #3) reduces forward and reverse throttle by 50%. Training Mode is provided to reduce the power output allowing beginning drivers to better control the model. As driving skills improve, simply change to Sport or Race Mode for full-power operation. Tip For Fast Mode Changes The ESC is set to Profile 1 (Sport Mode) as the default.
DRIVING YOUR MODEL Now it’s time to have some fun! This section contains instructions on driving and making adjustments to your model. Before you go on, here are some important precautions to keep in mind. Allow the model to cool for a few minutes between runs. This is particularly important when using high capacity battery packs that allow extended periods of running. Monitoring temperatures will extend the lives of the battery and motor.
DRIVING YOUR MODEL Not all batteries can be used in wet environments. Consult your battery manufacturer to see if their batteries can be used in wet conditions. The Traxxas TQ transmitter is not water resistant. Do not subject it to wet conditions such as rain. Do NOT operate your model during a rain storm or other inclement weather where lightning may be present.
DRIVING YOUR MODEL • Transmission: Remove, disassemble, and clean the transmission components. No grease is required for the nylon gears. Refer to your exploded view diagrams for help with disassembly and reassembly. • Motor: Remove the motor, clean with aerosol motor cleaner, and re-oil the bearings (Velineon 380 motor) with lightweight motor oil. Be sure to wear eye protection when using spray aerosol cleaners.
TUNING ADJUSTMENTS Important: The shocks are assembled at the factory with a center-to-center distance (between the rod end balls) of 47.75mm. Any time the shocks are removed and disassembled, this distance should be checked to ensure proper operation of the suspension. The Slash VXL 4WD and E-Revo VXL are factory-tuned for optimum performance in a wide variety of off-road conditions.
TUNING ADJUSTMENTS Static Camber Adjustment The wheels can be set to have either positive or negative camber (see illustration below). The camber angle changes as the wheel moves up and down through its range of travel. Static camber is the camber angle at the wheel when the vehicle is set at its normal, stationary ride height. TRANSMISSION TUNING The suspension pivot balls located in the axle carriers adjust the static camber.
TUNING ADJUSTMENTS traction and tend to spin up to extremely high rpms. Higher viscosity (thicker) oil causes the differential to act like a limited-slip differential, distributing more equal power to the left and right wheels. Your model will generally benefit from higher viscosity oil when climbing, rock crawling, or racing on low traction surfaces. Note: Heavier oil will allow power to be transferred even with one or more tires off the ground. This can make the vehicle more likely to overturn.
TUNING ADJUSTMENTS Gearing for 50+mph The included “High Speed” pinion gear will allow your model to reach 50+mph when used with an additional Power Cell Series 1 battery (Part #2925) and (Part #3063) series connector (battery and series connector sold separately). 50+mph Pinion Installation Instructions 1. Remove the motor as described in Motor Installation (following). 2. Use the supplied 1.5mm wrench to loosen the pinion’s set screw. Remove the stock pinion. 3.
TUNING ADJUSTMENTS Adjusting Gear Mesh Incorrect gear mesh is the most common cause of stripped spur gears. Gear mesh should be checked and adjusted anytime a gear is replaced. Access the gears by removing the single screw on the top gear cover. To set the gear mesh, cut a narrow strip of notebook paper and run it into the gear mesh of the motor. The motor is mounted Motor Mount Screw to an aluminum motor mount. Loosen the single motor mount screw with the provided 2.
MAINTAINING YOUR MODEL Your model requires timely maintenance in order to stay in top running condition. The following procedures should be taken very seriously. Inspect the vehicle for obvious damage or wear. Look for: 1. Cracked, bent, or damaged parts 2. Check the wheels and steering for binding. 3. Check the operation of the shock absorbers. 4. Check the wiring for any frayed wires or loose connections. 5. Check the mounting of the receiver and servo(s) and speed control. 6.
TQ 2.4GHz ADVANCED TUNING GUIDE Starting Over: Restoring Factory Defaults When programming your 2.4GHz transmitter, you may feel the need to start over with a clean slate. Follow these simple steps to restore the factory settings: 1. Turn transmitter off. 2. Hold both MENU and SET. 3. Turn transmitter on. 4. Release MENU and SET. The transmitter LED will blink red. 5. Press SET to clear settings. The LED will turn solid green and the transmitter is restored to default.
TQ 2.4GHz ADVANCED TUNING GUIDE Model Lock The Traxxas Link feature can store up to twenty models (receivers) in its memory. If you bind a twenty-first receiver, Traxxas Link will delete the “oldest” receiver from its memory (in other words, the model you used the longest time ago will be deleted). Activating Model Lock will lock the receiver in memory so it cannot be deleted.
TQ 2.4GHz ADVANCED TUNING GUIDE Press MENU to move through options. Press SET to select an option. MENU TREE The menu tree below shows how to navigate through the TQ 2.4GHz transmitter’s various settings and functions. Press and hold MENU to enter the menu tree, and use the following commands to navigate through the menu and select options. MENU: When you enter a menu, you always start at the top. Press MENU to move down the menu tree.
TQ 2.
B R U S H L E S S MODEL 7007 B R U S H L E S S MODEL 7107 B Rowner U S’s Hmanual L E S S 1100 Klein Road, Plano Texas 75074 1-888-TRAXXAS 100205 KC1256-R01
