HD7 Wireless speaker User’s Manual Please read this manual before using the product
Thank you for choosing TREBLAB HD7! This speaker provides superior sound quality and mobility combined with rugged construction and the convenience of hands-free wireless technology. WHAT’S IN THE BOX HD7 1. 2. 1. TREBLAB HD7 speaker 2. User’s manual 3. Insert card 5. 4. Charging cable 5. Round Treblab logo sticker 6. Carrying strap 7. Carabiner 8. 3.5 mm Audio cable 7. 3. 4. 6. 8.
BUTTONS AND PARTS POWER ON / OFF LED PREVIOUS / VOLUME PLAY / PAUSE NEXT / VOLUME + Place for the carrying strap Microphone (Mic) Bike mounting 1/4-20 UNC AUX LINE-IN Micro USB port
Function Operation Power ON Press and hold the POWER button for 3 seconds. Power OFF Press and hold the POWER button for 2 seconds. Play / Pause Press the PLAY / PAUSE button. Volume + Press the VOLUME + button. Volume - Press the VOLUME - button. Answer a phone call Press the PLAY / PAUSE button. Reject a phone call Press and hold the PLAY / PAUSE button for 2 seconds. End a phone call (hang up) Press the PLAY / PAUSE button. Redial Press and hold the PLAY / PAUSE button for 3 seconds.
TWS OFF Press and hold the VOLUME + and VOLUME buttons simultaneously on one of the speakers until you hear “Disconnected”. Factory reset Press and hold the VOLUME + and VOLUME - buttons simultaneously for 3 seconds. SETTING UP YOUR HD7 Turn ON Press and hold the POWER button for 3 seconds. You will hear the sound cue, and the BLUE LED light will start flashing. Turn OFF Press and hold the POWER button for 2 seconds. You will hear the sound cue, and the flashing BLUE LED light will go off.
1. Turn on your speaker by pressing and holding the POWER button for 3 seconds. You will hear the sound cue, and the LED will start flashing BLUE indicating that the speaker is in pairing mode. 2. Activate the Bluetooth mode on your device (smartphone, tablet, laptop). 3. Select TREBLAB HD7 from the Bluetooth devices list. Keep it within 3 feet / 1 meter from the speaker while pairing. 4. If necessary, enter the passcode 0000. 5.
TRUE WIRELESS STEREO (TWS) - PAIRING TWO SPEAKERS The TWS technology allows you to pair wirelessly two speakers to create a dual-channel system for true stereo sound. Turn OFF the Bluetooth mode on your smart device Place two speakers near each other (the distance should not be over 3 feet / 1 meter) Power ON both speakers simultaneously. You will hear the “Power on” voice prompt, and the LED indicators will flash BLUE Click twice the POWER button on one of the speakers.
Now you can use the speakers in stereo mode. Kindly note that the maximum distance between speakers should not exceed 33 feet / 10 meters NOTE: If the speakers were already paired with each other, you would skip the TWS pairing steps, as they will switch to a stereo mode automatically. After turning on both speakers simultaneously, wait for the “Stereo mode” voice prompt. Then turn on the Bluetooth mode on your smart device, and the speakers will connect to it seamlessly.
AUX LINE-IN MODE. 3.5 MM AUDIO CABLE CONNECTION You can connect TREBLAB HD7 to compatible devices using the supplied 3.5 mm Audio cable. Plug one end of the 3.5 mm Audio cable into the AUX LINE-IN port on the bottom side of the speaker (under the cover). Plug the other end into the 3.5 mm jack on your device. Turn on the speaker. You will hear the sound cue and the LED light will turn GREEN. Now you can play music and audio.
PHONE CALLS TREBLAB HD7 can be used to make and receive phone calls when connected wirelessly. Audio playback will be paused during the calls. To answer / end a call: Press the PLAY / PAUSE button. To reject a call: Press and hold the PLAY / PAUSE button for 2 seconds. To redial: Press and hold the PLAY / PAUSE button for 3 seconds. NOTE: For the better call quality, speak into the microphone. TROUBLESHOOTING Problem Solution Not powering on Make sure the speaker is fully charged.
Not pairing Make sure the 3.5 mm Audio cable is not plugged in. Make sure the speaker is not paired with any other device, as it can only pair with one device at a time. Press the VOLUME + and VOLUME - buttons simultaneously and hold for 3-5 seconds. This will make the speaker forget previously paired devices. Repeat the steps for pairing as previously described. Alternatively, disconnect the device from your speaker and remove HD7 from your device’s pairing list. Try to pair again.
Check if the volume level is set on both the source device and the speaker. Check if the speaker is running out of power. CHARGING One full battery charge provides up to 6 hours of playtime at maximum volume and up to 25 hours at moderate volume. When the battery is running low, you will hear a voice signal. TREBLAB HD7 may be used while charging in both Bluetooth mode and AUX LINE-IN mode.
with lower power will increase the overall charging time. Unplug HD7 from the charging cable and the cable - from the power source when not in use. If the speaker is left unused, make sure that it is charged, as this may lead to the reduction of battery capacity. Even the fully charged battery will lose its charge over time. We recommend fully charging the HD7 speaker at least twice a month to maintain the sufficient battery life.
RECYCLING The speakers can be recycled, and they should be in order to keep our planet clean. Where should you bring them? In the US, there are a couple of options: 1. Best Buy has a recycling program. Just take the broken earbuds with you next time you visit a Best Buy store. This link will help you find the best location: https: //www.bestbuy.com/site/store-locator/ 2. Check for other possible locations next to you on these websites (just enter your ZIP to find a location): https: //www.call2recycle.
SAFETY RULES Don’t disassemble or modify your speaker for any reason. Doing this may cause the speaker to malfunction or explosion. The damage to your device can void the manufacturer’s warranty. Do not let your device get wet by liquids – liquids can cause severe damage. The damage caused by water can void the manufacturer’s warranty. Make sure the speaker is completely dry before charging. Clean only with a dry cloth.
SPECIFICATIONS Battery: Up to 25 hours playtime, Rechargeable Li-Ion 2500 mAh 3.6 V, Input 5 V / 0.5 A - 1.5 A Charging time: 3 hours Wireless connection version: 4.2 HFP, A2DP, AVRCP, GAVDP, AVDTP, SPP, AVCTP Signal range: 33 ft / 10 m Output power: 2x 6 W Water resistance: IPX6 Charging port: Micro USB Audio port: 3.5 mm jack Dimensions: 3 x 3 x 7.3 inches / 158.5 x 65 x 62.
THANK YOU We truly appreciate that you chose TREBLAB as your trusted brand of wireless speakers and sincerely hope you enjoy the great sound and seamless usability TREBLAB HD7 provides. We love making our customers happy by providing true value with our products. If for any reason you are not completely satisfied with your purchase or have any questions, please visit https: //treblab.com/contact_us. We care about our customers most of all and are always here to help you.
1 YEAR WARRANTY Parts and Labor Warranty Please visit www.treblab.com to register YOUR product. Manufactured by Productech Made in China WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.
