HT/O Installation Instructions TG200992 Issue 1/A 30/01/08
HT/O Installation Instructions
2 Installation (continued)
Requirements (continued)
2
h
ij k
Fit Bracket, Shield and Sensor
4
a
b
c
Caution: This unit contains static sensitive devices. Suitable anti-static precautions
should be taken throughtout the operation to prevent damage to the units.
BS EN100015/1 Basic Specification: protection of electrostatic sensitive
devices.
L1
> 1 m, 1 yd
B1 < L1
L2
B2 < L2
Remove Cover
3
a
b
44 mm (1.73”)
Ø 6 mm (0.24”)
2 wallplugs and screws supplied
