Quick Installation Guide TEG-S16g TEG-S24g 1.
Table of Contents English 1. Before You Start 2. Hardware Installation 3. LEDs 1 1 2 3 Technical Specifications Troubleshooting 4 5 Version 01.12.
1. Before You Start Package Contents ŸTEG-S16g/TEG-S24g ŸMulti-Language Quick Installation Guide ŸPower Cord (1.8m / 6ft.) ŸRack Mount Kit System Requirements ŸComputer with Network adapter installed ŸCAT-5e or CAT-6 Network Cable ŸThe surface must support at least 2.3Kg (5 lbs.) for the Switch ŸThe power outlet should be within 1.
2. Hardware Installation 1. Connect the Power Cord to the TEG-S16g/TEG-S24g and then to a power outlet. 2. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port on the TEG-S16g/TEG-S24g. 3. Move the power switch to the on position.
3.
Technical Specifications Hardware TEG-S16g TEG-S24g Standards IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T; IEEE 802.3x Flow Control Network Media ŸEthernet: Cat. 5 up to 100m ŸFast Ethernet: Cat. 5 and 5e up to 100m ŸGigabit Ethernet: Cat. 5, 5e, 6, up to 100m Data Rates ŸEthernet: 10Mbps/20Mbps (half/full-duplex) ŸFast Ethernet: 100Mbps/200Mbps (half/full-duplex) ŸGigabit Ethernet: 2000Mbps (full-duplex) Protocol / Topology CSMA/CD, Star Power Consumption (max) 7.
Troubleshooting 1. After connecting the Switch to a power outlet, the LEDs do not turn on. 1. Check the connection of the power cord to the TEG-S16g/TEG-S24g and the power outlet. 2. Check that the power outlet is receiving power. 2. When I connect a computer to one of the ports on the Switch, the 10M/LINK/ACT LED turns on, but I am not getting Gigabit speeds. 1. Check the LEDs. If the 100M/1000M LED is green, the computer's connection speed is 1000Mbps.
Limited Warranty TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase.
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT TRENDNET'S OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
