TRENDnet User’s Guide Cover Page
TRENDnet User’s Guide Contents Product Overview ...........................................................................1 Package Contents .......................................................................................................... 1 Features ......................................................................................................................... 1 Product Hardware Features...........................................................................................
TRENDnet User’s Guide Table of Contents Setup Port Mapping ..................................................................................................... 41 Check the router DSL Statistics .................................................................................... 50 Setup IPv6 on your router ........................................................................................... 41 View your router log .................................................................................
TEW-722BRM TRENDnet User’s Guide Features Product Overview TRENDnet’s N300 Wireless ADSL 2+ Modem Router, model TEW-722BRM, is a combination high performance modem for Internet access and powerful wireless N300 router—well suited for medium to large size homes. The modem is compatible with most ADSL Internet service provider networks and it comes with an intuitive guided setup wizard. For your convenience the wireless network is setup and pre-encrypted out of the box.
TEW-722BRM TRENDnet User’s Guide Advanced QoS Product Hardware Features Classify and prioritize different types of data such as video and audio transmissions Energy Savings Rear View Embedded GREENnet technology reduces power consumption by up to 50% Ethernet Ports Four Ethernet ports to hardwire devices LAN Ports IPv6 IPv6 network support *Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications.
TEW-722BRM TRENDnet User’s Guide Front View WLAN On/Off Button WPS Butto n Diagnostic LEDs o LAN 1-4 (Link/Activity) LEDs – These LED indicators are solid green when the LAN ports are successfully connected to your wired network devices (which are turned on). These LED indicators will blink green while data is transmitted or received through your modem router’s LAN ports.
TRENDnet User’s Guide TEW-722BRM Application Diagram The router is installed near the wall telephone jack/DSL line (DSL service supplied by your ISP “Internet Service Provider”) which connects to the Internet. Wireless signals from the router are broadcasted to wireless clients such as laptops (with wireless capability) thereby providing Internet access. © Copyright 2013 TRENDnet. All Rights Reserved.
TEW-722BRM TRENDnet User’s Guide Basic Router Setup Creating a Home Network What is a network? A network is a group of computers or devices that can communicate with each other. A home network of more than one computer or device also typically includes Internet access, which requires a router. A typical home network may include multiple computers, a media player/server, a printer, a modem, and a router.
TEW-722BRM TRENDnet User’s Guide Router Installation Before you Install Many Internet Service Providers (ISPs) allow your router to connect to the Internet without verifying the information fields listed below. Skip this section for now and if your router cannot connect to the Internet using the standard installation process, come back to this page and contact your ISP to verify required ISP specification fields listed below.
TEW-722BRM TRENDnet User’s Guide Hardware Installation 1. Connect the detachable antenna to your modem router. 2. Connect one end of the RJ-11 telephone cable to the modem router ADSL port. Connect the other end of the RJ-11 telephone cable to the telephone jack/DSL line. 3. Using the Network cable, connect your computer to one of the four LAN ports on the modem router. 4. Connect the power adapter to the modem router and then to a power outlet. 5.
TRENDnet User’s Guide TEW-722BRM 3. The Setup Wizard will automatically appear. This section determines what method the router will use to interface with your ISP service. Select the ADSL Internet connection type provided by your ISP and click Next. Note: If the Setup Wizard does not automatically appear, click Setup Wizard (the top button on the left tab). 6.
TRENDnet User’s Guide 7. The Summary page will allow you to quickly review the settings you applied in the Setup Wizard. Click Save to apply settings. TEW-722BRM 10. For added security, the router is pre-encrypted with its own unique wireless network security key. You can find the unique network security key and pre-assigned network name (SSID) on a sticker on the front of the router and on a label on the bottom of the router.
TEW-722BRM TRENDnet User’s Guide Connect additional wired devices to your network Wireless Networking and Security You can connect additional computers or other network enabled devices to your network by using Network cables. Connect them to one of the available LAN ports labeled 1,2,3,4 on your modem router. Check the status of the LED indicators (1, 2, 3, or 4) on the front panel of your router to ensure the physical cable connection from your computer or device.
TEW-722BRM TRENDnet User’s Guide network uses WPA encryption your wireless network will use WPA encryption. Only when all wireless clients disconnect to the network and a wireless client with WPA2 encryption connects your wireless network will then change to WPA2 encryption. NOTE: WPA2 encryption supports 802.11n speeds and WPA encryption will limit your connection speeds to 54Mbps WPA2: This is the most secure wireless encryption available today, similar to WPA encryption but more robust.
TEW-722BRM TRENDnet User’s Guide Note: It is recommended to use Open System because it is known to be more secure than Shared Key. WEP Key 1-4 o Choose HEX or ASCII. Note: It is recommended to use ASCII because of the much larger character set that can be used to create the key. o This is where you enter the password or key needed for a computer to connect to the router wirelessly o You can define up to 4 passwords or 4 keys. Only one key can be active at a given time. Most users simply define one key.
TEW-722BRM TRENDnet User’s Guide Connect wireless devices using WPS Setup > Wireless Settings > WPS Setup WPS (Wi-Fi Protected Setup) is a feature that makes it easy to connect devices to your wireless network. If your wireless devices support WPS, you can use this feature to easily add wireless devices to your network. Note: You will not be able to use WPS if you set the SSID Broadcast setting to Disabled. There are two methods the WPS feature can easily connect your wireless devices to your network.
TEW-722BRM TRENDnet User’s Guide In addition to the hardware push button located physically on your router, the router management page also has push button which is a software or virtual push button you can click to activate WPS on your router. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Setup and click Wireless Settings, then click on the WPS Setup button at the bottom of the page. 3.
TEW-722BRM TRENDnet User’s Guide o B only: This mode only allows devices to connect to the router using older and slow 802.11b technology (typically not recommended). Note: Please check the specifications on your wireless devices for the highest wireless capability supported first before applying these settings. If you are unsure, it is recommended that you keep the default setting (B/G/N mixed) for the best compatibility.
TEW-722BRM TRENDnet User’s Guide Radio On/Off: Select to enable wireless guest network. Name (SSID): Enter the wireless name or SSID of your guest network. Security Mode: Select the wireless security or encryption of your guest network. Steps to improve wireless connectivity There are a number of factors that can impact the range of wireless devices. Follow these tips to help improve your wireless connectivity: 1. Keep the number of obstructions to a minimum.
TEW-722BRM TRENDnet User’s Guide Advanced wireless settings Setup > Wireless Settings The advanced wireless features can provide you with additional options for setting up your wireless network such as multiple SSID, activate/deactivate wireless according to schedule, and operation modes such as WDS (Wireless Distribution System) bridging or wireless bridging. Multiple SSID Setup > Wireless Settings The multiple SSID feature allows you to broadcast up to two additional SSIDs (or wireless network names).
TEW-722BRM TRENDnet User’s Guide Regulatory Domain: The channel region assigned (FCC 1~11 or ETSI 1~13). This setting cannot be modified and is displayed for informational purposes. Transmit Power: The wireless transmit power can be modified to a lower setting such as 50%, 25%, and 12% if necessary. Lowering the wireless transmit may help to better stabilize the wireless connectivity and reduce the effects of wireless interference in areas where there are several 2.4GHz wireless devices.
TEW-722BRM TRENDnet User’s Guide MAC address filters Advanced > Firewall > MAC Filter Every network device has a unique, 12-digit MAC (Media Access Control) address. Using MAC filters, you can allow or deny specific computers and other devices from using this router’s wired or wireless network. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Advanced, click on Firewall, and click on MAC Filter. 3.
TEW-722BRM TRENDnet User’s Guide 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Advanced, click on Firewall, and click on Domain Filter. 3. Under Domain blocking section select Enable. 4. Enter the website URL to block and click Add. Select the time schedule of when to enable the rule or select Always to always block entry.
TEW-722BRM TRENDnet User’s Guide 3. Under Packet Filter section select Enable and click Apply. Filter 1. To create a new filter rule. Click Add in the Filters section. 2. Review the settings and click Apply to save. Name: Enter the name of the filter. Interface: Type: Select the type of packets to filter. In for incoming packets and Out to filter outgoing packets Select the interface used for the filter.. Default Action: Select to drop or allow the packets. Rules 1. To create a new rule.
TEW-722BRM TRENDnet User’s Guide DSCP: Select the DSCP value to apply Source/Destination MAC Address: Enter the source and destination MAC address of the rule. Advanced Router Setup Access your router management page Generic Rules 1. To create a new rule. Click Add in the Rules section. Note: Your router management page http://192.168.10.1 is accessed through the use of your Internet web browser (e.g.
TEW-722BRM TRENDnet User’s Guide Change your router login password Set your router date and time Maintenance > Password Setup > Time and Date There are two ways to set the router’s date and time. NTP (Network Time Protocol) is based on time servers. You can also manually set the router’s date and time. Note: It is important that the time is configured correctly before setting any schedules. Oour router management page http://192.168.10.1 is accessed through the use of your Internet web browser (e.g.
TEW-722BRM TRENDnet User’s Guide Internet Connection Settings Enable: Check option to enable daylight savings Start/End Time: Configure the start and end time of daylight savings. Manual 1. Manually set the date and time of the router by select the from the pull down menus. Click Sync Time to synchronize with your computer’s current time. Year: Enter the year to Enable: Check option to enable NTP feature Server IP: Enter the NTP server IP address or domain to use.
TEW-722BRM TRENDnet User’s Guide Internet Settings PPPoE / PPPoA If you select PPPoE (RFC-2516 PPP over Ethernet), the screen below is displayed. Internet Settings: Select your ADSL internet type. Contact your ISP for additional information. State of Connection: Select whether to enable or disable this connection. IPMode of Connection: Select the connection mode, options are: © Copyright 2014 TRENDnet. All Rights Reserved.
TEW-722BRM TRENDnet User’s Guide o Dynamic: Select this option if the IP address can be automatically obtained from your ISP. o Static: Select this option if you are required to use a permanent IP address to connect to the Internet. You must enter the IP address and subnet mask provided by your ISP. Name: Enter your desired connection name. NAT: Select whether to enable or disable NAT (Network Address Translation). Enable this setting to share one WAN IP address with multiple computers on your network.
TEW-722BRM TRENDnet User’s Guide Default Gateway: Enter the default gateway provided by your ISP. DNS Enabled: Select whether to enable or disable DNS (Domain Name System). DNS Override Allowed: Select whether to enable or disable DNS override. DNS Server 1 / DNS Server 2: If provided by your ISP, enter the DNS server. Otherwise, leave these fields blank. As system default route: Check this box to set the current setting as the default route.
TEW-722BRM TRENDnet User’s Guide CIP If you select CIP mode, the screen below is displayed. As system default route: Check this box to set the current setting as the default route. ICMP Reply Enable: Check this box to enable ICMP (Internet Control Message Protocol) messages to be sent back to the host that sent the message. Proxy ARP Enable: Check this box to enable proxy ARP function.
TRENDnet User’s Guide TEW-722BRM Note: You will need to access your router management page using your new router IP address to access the router management page. (e.g. Instead of using the default http://192.168.10.1 using your new router IP address will use the following format using your new router IP address http://(new.router.ipaddress.here) to access your router management page. Subnet Mask: Click the Subnet Mask drop-down list to select a mask. (e.g. 255.255.255.
TEW-722BRM TRENDnet User’s Guide Sub Range IP Enable: Check this box to set another range of IP address. Vendor Class (Option 60): Enter a vendor class name. o o o o o o Sub-String Match: Check to enable the sub-string match function. IP Pool Starting Address: Enter the lowest sub range of IP address to assign. IP Pool Ending Address: Enter the highest sub range of IP address to assign. Subnet Mask: Enter the subnet mask. IPRouters: Enter the IP address of your modem router.
TEW-722BRM TRENDnet User’s Guide Configure ALG settings Advanced > NAT > ALG A Virtual Private Network (VPN) is a network that uses a public network, such as the Internet, to provide secure communications between a remote computer or network and another network. Some offices often provide VPN access to their networks to enable employees to work from their remote office/home office, or while traveling.
TEW-722BRM TRENDnet User’s Guide Dos Protection: Check this box to enable DoS protection. Dos Protection Option: Check the appropriate boxes to enable protection from SYN flood, FIN flood, UDP flood, ICMP flood, SMURF, IP spoofing, and others. Enter the flood count numbers or retain the default values if you are unsure about them. SPI Settings 1. Log into your router management page (see “Access your router management page” on page 22). 2.
TEW-722BRM TRENDnet User’s Guide WLAN/LAN1-4: Select device interface to reflect IGMP rule. MLD 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Advanced, click on Multicast and select IGMP. 3. Under MLD option select which IGMP to activate. 3. Review the settings below and click Apply to save changes.
TEW-722BRM TRENDnet User’s Guide User Name / E-mail: The user name needed to log in to your Dynamic DNS service account Password/Key: This is the password to gain access to Dynamic DNS service (NOT your router or wireless network password) for which you have signed up to. 6. To save changes, click Apply. Allow remote access to your router management page Telnet Enable: Select to enable telnet remote access. Session Timeout: Enter the session timeout period.
TEW-722BRM TRENDnet User’s Guide 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Maintenance, and click on Access Management. 3. Click Add to a rule and Apply to save settings, Packet Layer User Name: Select the user name who can access the control rule. Interface: Select the interface. Match Type: Select the control rule type. Match Condition: Select the control rule condition.
TRENDnet User’s Guide that makes all the ports and services available on the WAN/Internet side of the router and forwards them to a single IP address (computer or network device) on your network. The DMZ feature is an easy way of allowing access from the Internet however, it is a very insecure technology and will open local area network to greater threats from Internet attacks.
TRENDnet User’s Guide Note: Please refer to the device documentation to determine which ports and protocols are required. Protocol Type: Select the protol to assign the rule. Public IP: Enter the public IP that will have access to your device (you can enter 0.0.0.0 or * for all IP) Private IP: Enter the IP address of the device to forward the port. (e.g. 192.168.10.101).
TEW-722BRM TRENDnet User’s Guide Prioritize traffic using QoS (Quality of Service) Configuration > Advanced Setting > Quality of Service You may want to prioritize outbound traffic for specific computers or devices on your network to have higher priority. Queue Config This page allows you to configure a QoS queue entry and assign it to a specific network interface. Each of the queues can be configured for a specific precedence.
TEW-722BRM TRENDnet User’s Guide Queue Classification This section allows you to configure classification rules to classify upstream traffic and assign queues which define the precedence, interface, and optionally overwrite the IP header DSCP byte. A rule consists of a class name and at least one condition. All the specified conditions in the classification rule must be satisfied for the rule to take effect. Class Name: Enter a class name. Class Enable: Check this box to enable.
TEW-722BRM TRENDnet User’s Guide another network may have 192.168.20.x IP addressing and because the IP addressing of these two networks are different, they are separate networks. In order to communicate between the two separate networks, static routing needs to be configured. Below is an example diagram where routing is needed for devices and computers on your network to access the other network. Note: Configuring this feature assumes that you have some general networking knowledge.
TEW-722BRM TRENDnet User’s Guide 3. Select the Inteface to configure then select appropriate dynamic routing protocol and version communicate with other routers. Click Add to save settings. RIPv1: Enables sending and receiving or exchange of routing information dynamically between your router and other routers to build routes to your network and other networks using the RIP version 1 protocol.
TEW-722BRM TRENDnet User’s Guide Note: If you are unsure which Internet connection type you are using, please contact your ISP (Internet Service Provider). IPv6 LAN 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Advanced, and click on IPv6 LAN. 4. Select your IPv6 WAN Interface on the pull down menu and click Apply to save settings.
TRENDnet User’s Guide TEW-722BRM Router Default Settings Administrator User Name admin Administrator Password admin Router IP Address 192.168.10.1 Router Subnet Mask 255.255.255.0 DHCP Server IP Range 192.168.10.101-192.168.199 Wireless Enabled SSID (wireless network name) Please refer sticker or device label Wireless Security Please refer sticker or device label 802.11 Mode 2.4GHz 802.11b/g/n mixed mode Channel Auto Channel © Copyright 2014 TRENDnet. All Rights Reserved.
TEW-722BRM TRENDnet User’s Guide Backup and restore your router configuration settings To restore your router configuration: Maintenance > Configuration Backup/Restore You may have added many customized settings to your router and in the case that you need to reset your router to default, all your customized settings would be lost and would require you to manually reconfigure all of your router settings instead of simply restoring from a backed up router configuration file. 1.
TRENDnet User’s Guide Upgrade your router firmware Maintenance > FW Upgrade TRENDnet may periodically release firmware upgrades that may add features or fix problems associated with your TRENDnet router model and version. To check if there is a firmware upgrade available for your device, please check your TRENDnet model and version using the link. http://www.trendnet.
TEW-722BRM TRENDnet User’s Guide Restart your router Maintenance > Reboot Device You may want to restart your router if you are encountering difficulties with your router and have attempted all other troubleshooting. There are two methods that can be used to restart your router. Turn the router off disconnect the power adapter from the rear panel of your router for 10 seconds and reconnect the power adapter, see “Product Hardware Features” on page 2 .
TEW-722BRM TRENDnet User’s Guide 5. To show scripts on your computer click Show script. Press Delete to remove script. Check Internet connectivity using the router management page Maintenance > Diagnostic This page allows you to test the connectivity of the physical and protocol layers on the WAN side. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Maintenance, and click on Diagnostic. 3. Select your DSL interface and click test.
TEW-722BRM TRENDnet User’s Guide System ATM PVC Status Firmware Version: Displays the firmware version currently loaded on the router Modem Type: Displays the modem type Modem Vendor: Displays modem vendor Modem OUI: Displays modem OUI Modem Serial Number: Serial number of modem Uptime: Time duration of modem up time Current Time: Time of router DSL Link Status VPI: Current VPI settings applied on the router VCI: Current VCI settings applied on the router Link Type: Link type app
TEW-722BRM TRENDnet User’s Guide Wireless Interface Mode: Current wireless mode Channel: Wireless channel SSID: Wireless network name MAC Address: Wireless MAC address Security Mode: Wireless encryption of security Check the router IPv6 status Status > IPv6 Info You may want to check the system IPv6 information of your router. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Status and IPv6 Info. 3. Review the device information.
TEW-722BRM TRENDnet User’s Guide Check the router LAN clients Status > LAN Clients This page displays all connected clients. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Status and LAN Clients. 3. Review the device information. 2. Click on Status and Basic Statistics. 3. Review the device information. Check the router Routing Table Status > Routing Table This page displays all connected clients. 1.
TEW-722BRM TRENDnet User’s Guide IP Address: Router’s IP address Subnet Mask: Router’s subnet mask MAC Address: MAC address of router View your router log Status > Logs Your router log can be used to obtain activity information on the functionality of your router or for troubleshooting purposes. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Maintenance, and click on Syslog. 3. Review the device log information.
TEW-722BRM TRENDnet User’s Guide 4. On the Traffic Bandwidth Interval section, enter the interval of refreshing the traffic bandwidth. Configure your router log Maintenance > Syslog You may want send your router log to your e-mail address or to an external log server (also known as Syslog server) so you can check it periodically while away from home. You may also want to only see specific categories of logging. Module: Select the module type. Facility: Select the facility type.
TEW-722BRM TRENDnet User’s Guide SMTP Password/Confirm Password: Enter the password required for authentication by your SMTP mail server. Enter the password again in the Send router logs to your e-mail address Maintenance > Syslog 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Maintenance, click on Syslog. 3. Review the e-mail log settings and click Apply to save setting. SMTP Server: Check the box to enable the email log notification.
TRENDnet User’s Guide Enable TR-069 on your router Maintenance > TR069 Setting TR-069 is a network management protocol used to remote manage multiple network devices on a network typically by ISPs (Internet Service Providers). TR069 usually used in conjunction with ACS (Auto Configuration Servers) server managed by your ISP. 1. Log into your router management page (see “Access your router management page” on page 22). 2. Click on Maintenance and click on TR069 Setting. 3.
TRENDnet User’s Guide Troubleshooting Q: I typed http://192.168.10.1 in my Internet Browser Address Bar, but an error message says “The page cannot be displayed.” How can I access the router management page? Answer: 1. Check your hardware settings again. See “Router Installation” on page 2. 2. Make sure the LAN and WLAN lights are lit. 3. Make sure your network adapter TCP/IP settings are set to Obtain an IP address automatically or DHCP (see the steps below). 4.
TRENDnet User’s Guide Appendix How to find your IP address? Note: Please note that although the following procedures provided to follow for your operating system on configuring your network settings can be used as general guidelines, however, it is strongly recommended that you consult your computer or operating system manufacturer directly for assistance on the proper procedure for configuring network settings. Command Prompt Method Windows 2000/XP/Vista/7 1.
TEW-722BRM TRENDnet User’s Guide In MAC 10.6, from the Configure drop-down list, select Using DHCP and click the Apply button. f. Restart your computer. Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance. How to find your MAC address? In Windows 2000/XP/Vista/7, Your computer MAC addresses are also displayed in this window, however, you can type getmac –v to display the MAC addresses only. In MAC OS 10.4, 1.
TRENDnet User’s Guide Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
TEW-722BRM TRENDnet User’s Guide Česky [Czech] TRENDnet tímto prohlašuje, že tento TEW-722BRM je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES, 2006/95/ES, a 2009/125/ES. Dansk [Danish] Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW722BRM overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF, 2006/95/EF, og 2009/125/EF.
Limited Warranty TRENDnet User’s Guide Limited Warranty TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. TEW-722BRM – 3 Years Warranty AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 year warranty.
