1
1. Before You Start
Package Contents
Ÿ TEW-740APBO
Ÿ CD-ROM (User's Guide)
Ÿ Quick Installation Guide
Ÿ Proprietary PoE injector
Ÿ Power adapter (12 V DC, 1 A)
Ÿ Mounting Hardware
Ÿ Grounding wire
Minimum Requirements
Ÿ Computer with a network port and web browser
Ÿ A network switch or router with an available network LAN port
Ÿ Additional TEW-740APBO H/W: v2.xR wireless N300 directional access point
Ÿ 4 x RJ-45 network cables
Note:
It is recommended to use network cables without additional caps, molded caps, or boots with
the access points for cable fitment inside the enclosure.
Note:
The TEW-740APBO does not support IEEE 802.3at/af PoE standards. You must use the
proprietary Power over Ethernet injector that is supplied with the TEW-740APBO. This
installation guide will walk you through the installation and configuration of two TEW-740APBO
access points to establish a wireless point to point bridge using WDS (wireless distribution
system). The RJ-45 Ethernet cable between the passive PoE injector and access point can have
a maximum length of up to 60 m (197 ft.).
