Satellite reception | Dishes - LNB - Switches - Accessories Dishes TDS steel/TDA alu. series TDS steel/TDA alu.
Dishes TD | TDS single packed A dish for any job Satellite reception TD dishes are available in sizes, materials and colours for any job ranging from single to multiple user applications and any type of environment: • 5 sizes ranging from 50 x 55 cm (34.2 dBi gain) to 100 x 105 cm (40.
Dishes TD | TDA single packed • Delivered in individual packaging, but also available in bulk packs minimizing costs of transportation and handling Technical data Type: Art. no. / Colour Light grey - RAL 7035 Grey - RAL 7030 Anthracite - RAL 7016 Brick red TDA 78 Triax logo TDA 88 Triax logo 123718 123818 TDA 110 Triax logo 123801 123901 123812 123912 - RAL 8012 123914 Electrical Frequency range Gain @ 11.7 GHz G/T LNB 0.7 X-polarisation GHz 10.7 - 12.75 GHz 10.7 - 12.75 GHz 10.7 - 12.
Dishes TD | TDS Euroline, single packed TDS and TDA Euroline dishes All Euroline dishes will be delivered with painted mast bracket and back structure with pre-mounted feedarm. They also have a deluxe version of wingnuts Satellite reception Mounted and adjusted in two minutes Saving trouble and money is not only a long-term consumer benefit. TD dishes allow a substantial reduction in time used for mounting and adjusting: >>>> Technical data Type: TDS 64 Euroline w. logo TDS 78 Euroline w.
Dishes TD | TDA Euroline, single packed >>>> Satellite reception 1. The elevation bracket is pre-mounted and is easily fixed to the mast with non-slip mast brackets 2. A setting scale on the elevation brackets facilitates precise adjustment to the required satellite 3. The pre-mounted feedarm just needs unfolding, and the LNB holder with the LNB is simply clicked on. Technical data Type: TDA 64 Euroline w. logo TDA 78 Euroline w. logo TDA 88 TDA 110 Euroline w. logo Euroline w. logo Art. no.
Paraboles TD | TDS with wall bracket TDS dishes - mounted and adjusted in two minutes Saving trouble and money is not only a long-term consumer benefit. TD dishes allow a substantial reduction in time used for mounting and adjusting: Satellite reception 1. The elevation bracket is pre-mounted and is easily fixed to the mast with non-slip mast brackets 2. A setting scale on the elevation brackets facilitates precise adjustment to the required satellite 3.
Paraboles TD | TMB mini bulk - excl. logo Triax bulk solutions reduce costs and contribute considerably to the protection of the environment due to the heavy reduction of packaging costs. Satellite reception Triax Mini-bulk consists of 3 or 5 complete satellite dishes (dish, back bracket, arm, mast bracket, LNB brackets and screws) packed in one carton box. Technical data Type: Art. no.
Paraboles TD | Triax TD bulk packed dishes Triax bulk solution Bulk solutions reduce costs and contribute considerably to the protection of the environment due to the heavy reduction of packaging costs. Mini-bulk with 3-5 dishes Three or five complete satellite dishes packed in one carton box.
Parabolantennen | DAP Dishes • Available in 60, 70, 80 and 90 cm sizes with gains from 35.5 dB to 39.0 dB • Light grey and anthracite colour The mast bracket and the LNB holder are both easy to mount and absolutely stable with strength and stability tested in windtunnels and through mechanical tests. Technical data DAP 610 Art. no. / Colour Creme - RAL 1013 DAP 611 362610 Anthracite - RAL 7016 DAP 710 DAP 711 362710 362611 DAP 910 DAP 911 362910 362711 362911 Electrical 10.7 - 12.75 10.7 - 12.
LNB brackets | TD-brackets Triax LNB brackets - multi satellite reception Triax’s complete range of LNB brackets and accessories for perfect installations. Well-designed LNB bracket in UV-resistent plast and aluminium ensures stable and easy mounting. Satellite reception Technical data Type: TD - 6° DuoBlock TD - 3° DuoBlock TD - 6° DuoBlock TD - 3° 10° FlexiBlock Art.
LNB brackets | TD-brackets Triax LNB brackets - multi satellite reception DAP-brackets Triax LNB brackets - multi satellite reception Technical data Type: TD multiblock with 4xLNB and switch TD multiblock with 2xLNB and switch Plastic parts for TD Ral 7030 Plastic parts for TD Black Plastic parts for TD RAL 7035 300725 300730 129420 129421 129422 Black/Alu Black/Alu Ral 7030 Ral 7030 Ral 7035 Plastic Plastic Plastic degrees 3 - 20 3 - 20 mm Ø 40 Ø 40 Packing size Single set pack
Notes | for your personal notes
LNB | Universal Single Full KU-band coverage for both digital and analogue reception. Excellent noise figure and low phase noise. High gain and excellent crosspole isolation. Waterproof. High output and low power consumption. Gain flatness. For 1 set top box. Weather boot protection included. Colour options: RAL 7035 Light grey or RAL 7016 Anthracite grey. Single packed in gift box. Technical data Type: Colour Art. No.
LNB | Universal Single Complete range of LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power consumption • Gain flatness • For 2 or 4 set-top boxes • Supplied sliding cover • Available in 2 colours • Single packed in gift box Technical data Type: Colour Art. No.
LNB | Universal Twin Complete range of LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power consumption • Gain flatness • For 2 or 4 set-top boxes • Supplied sliding cover • Available in 2 colours • Single packed in gift box Technical data Type: Colour Art. No.
LNB | Universal Twin Complete range of LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power consumption • Gain flatness • For 2 or 4 set-top boxes • Supplied sliding cover • Available in 2 colours • Single packed in gift box Technical data Type: Colour Art. No.
LNB | Universal Quad Complete range of LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power consumption • Gain flatness • For 2 or 4 set-top boxes • Supplied sliding cover • Available in 2 colours • Single packed in gift box Technical data Type: TQD 003 Universal Quad TQD 006 Universal Quad, TQD 007 Universal Quad, Colou
LNB | Universal Quattro Complete range of LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power consumption • Gain flatness • For 4 set-top boxes • Supplied sliding cover • Available in 2 colours • Single packed in gift box Technical data Type: Colour Art. No.
LNB | OCTO LNB units, adopting the latest cutting-edge RF technology • Full Ku-band coverage for analogue and digital reception • Excellent noise figure and low phase noise • High gain and excellent cross-pole isolation • High output and low power c onsumption • Gain flatness • TQT for SMATV installation, 4 outputs: VH, VL, HH, HL • OCTO for 8 set-top boxes • Supplied sliding cover • Available in 2 colours Technical data Type: Colour Art. No.
LNB | Alps LNBs
- Available as single, dual and quad for 1, 2 or 4 set top boxes.
- Also available in quattro version for multi switch systems.
- Full Ku-band coverage for both digital and analogue reception.
- Low noise figures (0.6 dB).
- High cross polar isolation (typically >25 dB).
Technical data Type: Colour Art.LNB | SCR LNB [Single cable router] New satellite reception and distribution technology introducing new standards for single cable distribution. The new industry standard CENELEC EN50494 facilitates the delivery of broadcast programming over a single coaxial cable to multiple users, and hence helps to eliminate the numerous coaxial cables previously required to connect satellite PVRs and other highend set top boxes to the satellite dish.
DiSEqC switches | Triax DiSEqC switches DiSEqC switch DiSEqC switches are used in multi satellite installations for switching between 2 or 4 LNBs each pointing at different satellites. DiSEqC 4x1 Pos - 300504 Satellite reception DiSEqC 2x1 Pos - 300502 Technical data Type: Art. No: Number of inputs pcs. DiSEqC 502 2x1 switch DiSEqC 504 4x1 switch DiSEqC 502 2x1 switch DiSEqC 504 4x1 switch 300502 300504 300513 300514 2 2 2 2 Number of positions pcs. 2 2 2 2 Number of outputs pcs.
DiSEqC switches | Triax DiSEqC switches MFD DiSEqC switches are used in multi satellite installations for switching between 2 or 4 LNBs each pointing at different satellites. Available with 2 or 4 inputs for switching between 2 or 4 satellite positions. High isolation ensures problem-free operation in multi user installations. Available in diode or relay versions (relay: mechanical solution for extreme weather conditions). MFD 21D switch Can be used with single, dual and quad LNBs.
Mounting accessories | Wall bracket Triax has a wide range of mounting brackets for dishes. You will also and a complete range of different accessories - everything for making a perfect mounting. Satellite reception Technical data Type: Art. No: Material Mast diameter mm Clearence from wall mm Triax 2561 stand Wall bracket type “J” Wall bracket type “S” Universal roff/ wall bracket 127100 128050 128070 300709 Galv. steel Galv. steel Galv.
Mounting accessories | Wall bracket Triax has a wide range of mounting brackets for dishes. Satellite reception You will also and a complete range of different accessories - everything for making a perfect mounting. Technical data Type: Art. Nr: Material Mast diameter mm Wall plate dimension EXA 192 Wall bracket EXA 194 Wall bracket 131092 131094 Aluminium Aluminium Ø 48 Ø 48 155 x 155 x 3 155 x 155 x 3 250 450 Clearence from wall mm Thickness mm 2.5 2.
Mounting accessories | Bracket Triax supplies a range of brackets for mounting dishes on masts. You will find a complete range of different accessories - everything for making a perfect mounting. Satellite reception Technical data Type: Art. No: Material Tube dimension mm Plate dimension mm Clearance from wall mm Packing QTY pcs. Remarks Mastbracket TD-serie Mastbracket TD110 dish Mastbracket Unique dish 129415 140051 140050 Galv. steel Galv. steel Galv.
Mounting accessories | Bracket Triax supplies a range of brackets for mounting dishes on masts. You will find a complete range of different accessories - everything for making a perfect mounting. Technical data Type Art. No. Size Width Lenght mm mm Material Weight Packing QTY per box Tape Grey 153060 Black selfvulcanized 153061 10 1000 18 1000 Plastic Rubber Cable grommet Grey 760056 Cable grommet Black 153057 Rubber Rubber kg pcs.
