JUICE EXTRACTOR WITH T EA AR R WIIN N G GE TW TECHNOLOGY OPERATION MANUAL □INSTRUCTIONS □WARRANTY □OWNERSHIP REGISTRATION □IMPORTANT SAFEGUARDS □DO’ S AND DON’ TS □WHEN YOU NEED SERVICE □RECIPES SAVE THIS MANUAL-KEEP IT HANDY FOR QUICK REFERE NCE
Congratulations!!!! You are now the proud owner of a new Green Star Gold Juice Extractor. The Green Star Gold Juice Extractor will juice almost anything from carrots and apples to wheatgrass and pine needles. You are not limited to just regular juicing — you can enjoy a variety of other delicious foods such as pastas, baby foods, breadsticks, nut butters, pates, frozen sorbets and more.
TABLE OF CONTENTS Warranty ……………………………………………… 4 Warranty Registration Card ……………… Insert When You Need Service …………………………… 5 Important Safeguards ……………………………… 6 Do’ s and Don’ ts ……………………………………… 7 ’ ’ Green Star Gold Juice Extractor Features Green Star Gold Parts ………………………… 8-9 Green Star Gold Parts Order Form ………… 10 Assembling and Disassembling ………… 11-14 Machine Set-Up(for different uses) Screens and Plastic Plunger ………………… 15 To juice Wheat Grass …………………………… 15 To make Pasta, Rice Cake(mochi), Bread
WARRANTY (Please read carefully) We warrant to you, the end-user customer who has properly registered after purchasing the Green Star Gold Juice Extractor (hereinafter referred to as“GS GOLD”) for a valuable consideration, that the plastic parts, motor and the Twin Gears of this GS GOLD will be free from defects in materials and workmanship for a period of five (5) years from the date of purchase.
Place Stamp Here Green Star Gold Juicer Registration: TRIBEST CORP. P.O. Box 4089 Cerritos, CA 90703 USA ● Do you have an Internet Service? 1. Yes 2. No ● Have you ever purchased any products through Internet Stores? 1. Yes 2. No ● Do you use e-mail in your business communication? 1. Yes 2. No E-mail Address ● Do you use e-mail in your private communication? 1. Yes 2. No E-mail Address Please check all that apply to your household 4. Support Health Charities Regularly Purchase Items 5.
PUT GLUE HERE TO SEAL IMPORTANT! GREEN STAR GOLD JUICER REGISTRATION FORM PLEASE FILL OUT AND RETURN WITHIN THE NEXT IO DAYS 1. Mr 1. Mrs 1. Mis 1. Miss First Name Initial Last Name Street Apt.No City State Phone Zip Email Address (Area Code) Date of purchase: Month a. Model number: 1. GS-1000 3. 2. GS-2000 4. Day Year GS- 3000 GP-E1503 b. Color 1. White 3. 2. Off-White c.
WHEN YOU NEED SERVICE In the unlikely event that you do need service on your GREEN STAR GOLD JUICE EXTRACTOR, or if it fails to function properly while within the warranty period (used in normal : household operation only.) - PLEASE FOLLOW THE INSTRUCTIONS BELOW : Contact the nearest authorized Green Star Gold Service Center.
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: 1. Please read all instructions carefully. 2. To protect against risk of electric shock, do not put the motor base in water or other liquid. 3. Close supervision is necessary when any appliance is used by or near children. 4. Unplug the appliance from the electrical outlet when not in use, before assembling or disassembling and before cleaning. 5.
DO’S AND DON’TS DO : DON’T : ● Very important! When joining the Twin Gears for assembly-make sure to align the locating dots marked on the surface of the gears. ● Do not lift your Green Star Gold Juice Extractor with wet hands because it is heavy and it may accidentally slip from your grip. ● Do not keep the juice extractor where children can reach it. ● Soak grains in water for 6 hours or more. Drain the grain and put into the machine a little at a time, together with a small amount of water.
GREEN STAR GOLD JUICE EXTRACTOR Screen Outlet Adjusting Knob Pulp Dischrge Outlet Juice Outlet Pulp Dischrge Casing Green Star Gold Parts Homogenizing Blank (Open Blank) CJST1-051A Fine Screen Juice Pitcher Cleaning Brush Plastic Plunger Wooden Plunger Drive Gear Free Wheel Gear CJST1-034A CJST1-040A CJST1-039A CJGP2-036A CJST1-038A CJST1-044A CJST1-045A 700 cc 500 cc Twin Gear Housing Pulp Outlet Discharge Casing Adjusting Knob Latching Arm Knob Safety Tray Feeding Chute Feeding C
FEATURES AND PARTS Safety Tray Convenience Handle Feeding Chute Body Twin Gear Housing Twin Gear Power Cord Storage Compartment Power Switch Latching Arm Knob Latching Arm Speed Reducer Cover Green Star Gold parts Coarse Screen Strainer CJST1-035A CJST1-042A Pasta Guide Outlet Adjusting Knob-Soft CJST1-031A CJGP2-031A Bread Stick Blank (Closed Blank) CJST1-033A Bread Stick Guide Drip Tray Pasta Screen Pasta Attachment Pasta Screw CJGP2-035A CJGP2-038A CJGP1-033A CJGP1-034A CJST1-03
GREEN STAR GOLD PARTS GREEN STAR GOLD PARTS & ORDER FORM Description Twin Gear Housing Pulp Discharge Casing Outlet Adjusting Knob-Regular Drive Gear Free Wheel Gear Fine Screen Homogenizing Blank Juice Pitcher Wooden Plunger Cleaning Brush Safety Tray Coarse Screen Feeding Chute Feeding Chute Cover Plastic Plunger Strainer Drip Tray Bread Stick Blank Bread Stick Guide Pasta Screen Pasta Attachment Pasta Screw Pasta Guide Outlet Adjusting Knob-Soft Assorted Sets price Twin Gear Set Pasta Set Bread Stick Mak
GREEN STAR GOLD ASSEMBLY Safety Reminder: Make sure to unplug the juicer from the outlet before assembling. 1. Join the Twin Gear Housing to the body with the Latching Arm Knobs loosened and the Latching Arms open. Insert the Feeding Chute into the Twin Gear Housing “neck”, with the small rectangular tab toward the rear of the machine. Note : Before putting your machine away for future use, once it has been cleaned and dried, cover the Feeding Chute with its protective lid.
GREEN STAR GOLD ASSEMBLY (Cont’d) 3. Slide the desired Screen or Blank over the Twin Gears and into the Twin Gear Housing. 4. Slide the Pulp Discharge Casing over the gears and screen into the Twin Gear Housing. 5. Place each Latching Arm into the corresponding groove of the Twin Gear Housing. Turn both Latching Arm Knobs clockwise and tighten. 6. Insert the Outlet Adjusting Knob into the Pulp Discharge Casing and turn clockwise. When the Outlet Adjusting Knob comes to a stop, it is considered ‘tight’.
GREEN STAR GOLD DISASSEMBLY Safety Reminder : Make sure to unplug the juicer from the outlet before disassembly 1. Remove the Safety Tray by lifting it vertically from the Feeding Chute. 2. Turn the Outlet Adjusting Knob counter clockwise until it separates from its threads : then pull it out from its grooves. 3. Turn the Latching Arm Knobs counter clockwise to loosen. Open the Latching Arms horizontally outward on their hinges. 4. Remove the Pulp Discharge Casing.
GREEN STAR GOLD DISASSEMBLY (Cont’d) 5. Remove the Screen. The Twin Gears may come out with it. Be careful not to drop the Twin Gears. 6. Slide the Twin Gears out. 7. Remove the Twin Gear Housing by grasping the Feeding Chute. Then, gently pull it away from the body of the machine. Note : The Twin Gears on your juicer never need sharpening. They are not blades. They work by “biting” off small bits of produce at a time－ much like your teeth.
MACHINE SETUP Screens ----- Which one to use 1. Fine Screen separates maximum pulp from the juice. However, the pressure built up inside of the screen could push some finely ground pulp through holes of the screen. So, minimum pulp may be contained in the juice. Use to juice: carrot, parsley, kale, angelica utilis, wheatgrass, other green leafy vegetables and herbs. 2. Coarse Screen : allows some pulp to mix with the juice. Use to juice: Apples, Oranges, many other kinds of fruits and vegetables. B A 3.
MACHINE SETUP (Cont’d) 4. After a few drops of juice come out from the Pulp Discharge Outlet, loosen the Outlet Adjusting Knob about half way. 5. Carrots, apples and other“more palatable”fruits and vegetables can be added to create a milder tasting combination for those who have not yet “acquired”a taste for pure wheat grass juice. Note: Please refer to“Wheat Grass Delight”on page 22. To make pasta 1. Attach the Twin Gear Housing to the juicer body. 2.
CLEANING AND MAINTENANCE Proper Cleaning Lengthens the Life Span of the Juice Extractor ● Since Green Star Gold extracts minerals, such as calcium, from the produce so well, we recommend cleaning all of the juicer parts immediately after use to prevent mineral build-up which can cause problems. ●Completely remove the Pulp Discharge Casing and Twin Gear Housing sections. Immerse them in water and clean them with the Cleaning Brush, which is provided for your convenience.
TROUBLE SHOOTING Symptom - What if: Machine doesn’ t turn on. Machine stops Noisy gears Pulp discharge casing doesn’t fit properly Pulp discharge casing begins shaking Pulp is not being ejected Too much pulp Pulp comes out with juice Low amount of juice Material jammed Check to see if: The power supply is active; the plug is correctly positioned in the electrical outlet and the machine is switched on. ● The fuse is okay. ● The machine is correctly assembled.
HELPFUL HINTS NOISES Even though the Green Star Gold juicer is very quiet, there may be some normal noises. Please test your juicer as follows ; 1. Completely disassemble your Green Star Gold and then turn on the motor. You will hear a normal humming motor sound. If you hear any squeaking sound, your juicer may need lubrication between the Drive Shaft and the rubber seals. Do not be intimidated because of this noise.
HELPFUL HINTS CLEAN UP Maintaining maximum cleanliness of your juicer is extremely important for both your health and the peak performance of the machine. We recommend cleaning the juicer immediately after each use, since cleaning the machine as quickly as possible is the easiest way to remove food particles.
Wipe any other exterior surfaces with a damp cloth. DO NOT SUBMERGE THE MOTOR UNIT INTO WATER AT ANY TIME. 4. Others - Use the narrow, pointed end of the cleaning brush to push food out through the pulp discharge outlet. - Dried fruits and nuts can be very sticky on the inside surfaces of the juicer. To remove the residue more easily run a couple of stalks of celery through before disassembling the machine.
RECIPE INDEX JUICE AND DRINKS Citrus Blend ………………………………………… 23 Apple Lemonade …………………………………… 23 Wheat Grass Delight ……………………………… 23 Ambrosia Nectar …………………………………… 24 Watermelon Quench ……………………………… 24 Mellow Melon Punch ……………………………… 25 Snappy Apple ……………………………………… 25 Dr.
JUICES AND DRINKS MACHINE SET-UP FOR ALL JUICES AND DRINK RECIPES: 1. Place the Twin Gears in position 2. Use the Fine Screen 3. Tighten the Latching Arm Knobs snugly. 4. The Outlet Adjusting Knob closed. 5. Put glass Juice Pitcher under the Juice Outlet. 6. Put container under the Pulp Discharge Outlet to catch residue.
JUICES AND DRINKS (Cont’d) (See page 15 for machine set-up) Ambrosia Nectar 2 3 1 1 1 1 ½ BUNCHES SLICE SLICE WHOLE CUP GRAPES APPLES (YELLOW DELICIOUS, GRANNY SMITH,OR PIPPIN - Cut into 6 pieces) KIWI (Peeled and cut into 2 pieces) HONEYDEW (Cut into cubes) PINEAPPLE (Cut into cubes) LEMON (Peeled and cut into 4 pieces) CRANBERRIES Method: 1. Alternate juicing grapes, kiwi pieces, melon cubes, pineapple cubes, apple pieces and cranberries 2.
JUICES AND DRINKS (Cont’d) (See page 15 for machine set-up) Mellow Melon Punch ¼ ¼ CANTALOUPE (cut into cubes) HONEY DEW (cut into cubes) WATERMELON (cut into cubes) 2 Slices Juice all together and enjoy Snappy Apple 7 ½ ¼ 1 APPLES (FUJI, GRANNY SMITH, YELLOW DELICIOUS - Cut into 4 to 6 pieces) JALEPENO PEPPER LIME KIWI (Peeled and cut into 2 pieces) Method: 1. Juice Kiwi and Lime first 2. Next juice Jalepeno 3. Finish by juicing the Apples Dr. Walker’s Choice (#61) 10 oz. 6 oz.
JUICES AND DRINKS (Cont’d) (See page 15 for machine set-up) Green Tang 2 1 3 PINEAPPLE WEDGES (Cut into smaller pieces) MINT WHEAT GRASS LEMON GINGER FOR FLAVOR SPRIG HANDFULS ¼ 1 SLICE Method: 1. Juice wheat grass 2. Juice the mint 3. Juice lemon 4. Juice pineapple cubes Note: Pineapple wedge is a 1 〃round slice of whole pineapple cut into quarters (4 pieces).
BREAD STICKS AND MOCHI (RICE CAKE) MACHINE SET-UP: 1. Place the Twin Gears in position 2. Use the Rice Cake Blank (Total Blank) instead of Screens 3. Put the Pulp Discharge Casing into position 4. Tighten the Latching Arm Knobs snugly 5. Remove the Outlet Adjusting Knob from the Pulp Discharge Outlet and replace it with the Rice Cake Guide 6.
PASTA AND NOODLES MACHINE SET-UP: 1. Remove the Pulp Discharge Casing from the Twin Gear Housing 2. Remove the Twin Gears and insert the Pasta Screw onto the motor drive shaft (left side as you are looking into the body) 3. Place the Pasta Guide over the Pasta Screw, making sure the long side of the Pasta Guide faces to the left side 4. Select the pasta shape desired from the two shapes available on the Pasta Screen and fit it onto the Twin Gear Housing. (see diagram on page 16) 5.
PATE AND CROQUETTES MACHINE SET-UP: 1. Place the Twin Gears in position 2. Use the Homogenizing Blank 3. Put the Pulp Discharge Casing into position 4. Tighten the Latching Arm Knobs snugly 5. Tighten the Outlet Adjusting Knob 6. Place a bowl under the Juice Outlet Cashew-Curry Croquettes 2 1 CUPS CUP 3 1 TBSP TSP CASHEWS SPROUTED WHEAT (Soak for 12 hours and let small tips emerge by sprouting) CURRY PASTE (Available from Gourmet Food Shops) VEGE-SALT TO TASTE Method: 1.
SOUP MACHINE SET-UP: A. To Juice Carrots, Lemon, And Apple 1. Place the Twin Gears into position 2. Use the Fine Screen 3. Tighten the Latching Arm Knobs snugly B. To Grind Beets And Scallions 1. Place the Twin Gears into position 2. Use the Homogenizing Blank 3.
DESSERT MACHINE SET-UP: 1. Place the Twin Gears in position 2. Use the Homogenizing Blank 3. Put the Plup Discharge Casing into position 4. Tighten the Latching Arm Knobs snugly 5. Tighten the Outlet Adjusting Knob 6. Place a bowl under the Juice Outlet Cashew Poppy 1 CUP ¼ ¼ CUP CUP CUP TSP TBSP 1 ½ 4 SPROUTED WHEAT BERRIES - Soak for 12 hours and let small tips emerge by sprouting POPPY SEEDS SUNFLOWER SEEDS -SOAKED CASHEWS VANILLA HONEY Method: 1.
PRODUCT STANDARD ITEM VEGETABLE JUICER MODEL GREEN STAR® GOLD / GP-E1503 ELECTRICITY RATING USA Models : 120Vac, 60Hz, 180W EUROPE/ASIA : 230Vac, 50Hz, 120W SIZE 505mm x 195mm x 320mm WEIGHT 9.
V0911 GSGOLD UUpdated in September, 2011 This version supersendes all former manuals issued before this date.
