CONTENTS Warnings . Conservation Installation . Positioning Before using . The electrical connections . “Instructions for totally built:in appliances . Your appliance . Operation Freezer Controls Start your appliance . Temperature control Freezing fresh food Frozen food storage . Thawing lee making Health and safety guidelines . Defrosting. Maintenance and cleaning internal cleaning When the appliance is not in use , What happens if something goes wrong? . Guarantee conditions .
WARNINGS IT IS MOST IMPORTANT THAT THIS INSTRUCTION BOOK SHOULD BE RETAINED WITH THE APPLIANCE FOR FUTURE REFERENCE. SHOULD THE APPLIANCE BE SOLD OR TRANSFERRED TO ANOTHER OWNER, OR SHOULD YOU MOVE HOUSE AND LEAVE THE APPLIANCE, ALWAYS ENSURE THAT THE BOOK IS SUPPLIED WITH THE APPLIANCE IN ORDER THAT THE NEW OWNER CAN GET TO KNOW THE FUNCTIONING OF THE APPLIANCE AND THE RELEVANT WARNINGS, THESE WARNINGS ARE PROVIDED IN THE INTEREST OF SAFETY.
CONSERVATION In the interests of the Environment: When disposing of your old fridge, freezer or fridge/freezer. Help to keep your country tidy use authorized disposal sites for your old appliances. For maximum efficiency: Make sure that the appliance is cleaned properly, Make sure that the door is closed property. Do not position the appliance near to sources of heat. Do not overfill your appliance, air MUST be allowed to circulate.
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT 1S MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Positioning For this appliance to work efficiently, it should be located away from heat sources, e.g. cookers, radiators, boilers, direct sunlight etc.
The electrical connections WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed, I the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate pig fitted. _ Remove the fuse from the cut off plug. The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged into a amp socket in another part of your home.
Instructions for totally built-in appliances Dimensions of the recess Height of housing 8B0 mm Depth of housing 550 mm Width of housing 8§60 mm The appliance’s door has been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. For appropriate venting, follow indications in Fig. 2. Fig. 200 Debs, Push appliance into the housing until stop strip (A) touches the kitchen unit, Fig.
Apply covers (B} on joint cover lugs and into hinge holes. Fig.7 oo Position the runners (E) at the top and bottom of the inside of the kitchen unit as shown in Fig. 8 and mark the position of the external holes, After preparing the holes, screw the runners to the kitchen unit door using 3.5x16 mrm screws. \ Fig. 8 D283 Open both the appliance door and that of the kitchen unit to approx. 90°. Place the little plates over the runners. Hold the doors of the appliance and the unit together and mark the holes.
YOUR APPLIANCE A Freezer calendar {recommended storage times for frozen foods) B Freezer controls © -Frozen food storage D Freezing fresh foods
OPERATION Freezer Controls Fig. 11) Fig. 11 A Thermostat control B Fast freeze switch C Fast freeze light {yellow) Start your appliance Insert the plug into the wall socket. The pilot light {D-Fig. 11) will fight up to show that the appliance is on. Temperature control The temperature within the freezer is contrived by the thermostat situated at the top of the cabinet (A-Fig. 11). To operate the freezer proceed as folios: Turn the thermostat control beyond the «O» position.
Frozen food storage When you first start the freezer or if the freezer has been out of use for some time, we advise you to run your appliance for at least two hours in the «fast freeze» mode before storing frozen food. To obtain the best performance from this appliance, we strongly recommend that you ensure any commercially frozen foodstuffs were adequately stored by the retailer. It is also advisable not to exceed the storage period indicated by the manufacturer of the food.
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed farm many per-prepared food. This together with the changes in shopping habits to a once-a-week shop, mean that safe handing and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible. a Keep the time between buying chilled food and placing it in your freezer as short as possible.
Defrosting The freezer compartment will become progressively covered with frost. This should be removed with the special plastic scraper provided, whenever the thickness of the frost exceeds 1/4”. During this operation it is not necessary to switch off the power supply or to remove the foodstuffs. However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out and it is ad~ advisable to perform this operation when the appliance is empty.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (8mi to 0.5 liter of water). Rinse and dry thoroughly. "NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX POLISHES, TO CLEAN THE INTERIOR AS THESE WILL DAMAGE THE SURFACE AND LEAVE A STRONG SMELL.
WHAT HAPPENS IF SOMETHING GOES WRONG? Before contacting your local Trinity Bendix Service Force Center, check the following points: The appliance does not work... Check that: * There is power at the socket. ® Ensure that there is not a power cut by checking the household lights, = The fuse has not blown. ® The air circulation passages are not covered. Vibration or abnormal noises...
PEACE OF MIND FOR TWENTY FOUR MONTHS Guarantee conditions We, Trinity Bendix, undertake that if, within twenty four months of the date of the purchase, this Trinity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option, repair or replace the same FREE OF ANY CHARGE for labor, materials or carriage on con-~ edition that: ® The appliance has been correctly installed and used only on the electricity supply stated on the rating p
TRINITY BENDIX Better Products. Better Value. Trinity Bendix, 99 OAKLEY ROAD, Futon, Beds LU4 9QQ A DIVISION OF EMACS LIMITED Model No. REGISTERED IN ENGLAND NO. 176547 Part No.
