CONTENTS Warnings . Conservation Installation . Positioning Before using . The electrical connections . Location . Door reversibility Fitting a decorative door bane!. Your appliance . Operation .. Setting the temperature . Health and safety guidelines . Fresh food refrigeration . Defrosting, Maintenance and cleaning Internal cleaning ‘When the appliance is not in use . Changing the light bulb . ‘What happens if something goes wrong? . Guarantee conditions . Trinity Bendix Service Centers . .page .page .
WARNINGS IT 1S MOST IMPORTANT THAT THIS INSTRUCTION BOOK SHOULD BE RETAINED WITH THE APPLIANCE FOR FUTURE REFERENCE. SHOULD THE APPLIANCE BE SOLD OR TRANSFERRED TO ANOTHER OWNER, OR SHOULD YOU MOVE HOUSE AND LEAVE THE APPLIANCE, ALWAYS ENSURE THAT THE BOOK IS SUPPLIED WITH THE APPLIANCE IN ORDER THAT THE NEW OWNER CAN GET TO KNOW THE FUNCTIONING OF THE APPLIANCE AND THE RELEVANT WARNINGS.
CONSERVATION In the interests of the Environment: When disposing of your old fridge, freezer or fridge/freezer, Help to keep your country tidy ~ use authorized disposal sites for your oid appliances. For maximum efficiency: Make sure that the appliance is cleaned properly. Make sure that the door is closed properly. Do not position the appliance near to sources of heat. Do not over-fill your appliance, air MUST be allowed to circulate.
The electrical connections WARNING: THIS APPLIANCE MUST BE EARTHED, The manufacturer declines any liability should this satiety measure not be observed. if the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted. Remove the fuse from the cut off plug. The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged into a amp socket in another part of your home.
Door reversibility Remove the two screws which fix the upper hinge fo the door. Carefully lean the appliance on its back and remove the plastic insert (Fig. 4). Fig. 4 Remove the two screws which fix the lower hinge o the door. Remove the four screws which fix the lower hinge to the base of the appliance and remove the hinge itself; be very careful to recover all the screws. Remove the four screws that fix the upper hinge to the appliance and remove the hinge itself.
Fig. 9 Hook the decorative panel onto the top part of the door, inserting the pins {B) (on the door} into the elongated holes {1) {in the top bracket fitted to the panel} Fig. insert the securing screws holes (2) and fix the panel screws (Fig. 9). {C} through elongated without tightening the Fig. 10 Once the top of the panel has been correctly positioned, fix it through the holes in the bottom bracket, without tightening the screws {Fig. 10). Fig.
YOUR APPLIANCE D//A‘ A Dairy compartment B Shelf with egg tray & Bottle storage shelf D Salad drawers E Glass shelf (for storing meat) F Storage shelves G Thermostat control
OPERATION Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and one «OFF» (O) position.
Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if R has a strong flavor. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them. To help you use your refrigerator correctly, here are some more useful hints: Raw meat (beef, pork, lamb & game): wrap in polythene bags and place on top of the salad crisper.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply, internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda {5ml to 0.5 liter of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED GLEANING PRODUCTS OR WAX POLISHES, TO CLEAN THE INTERIOR AS THESE WILL DAMAGE THE SURFACE AND LEAVE A STRONG SMELL.
WHAT HAPPENS IF SOMETHING GOES WRONG? Before contacting your local Trinity Bendix Service Center, check the following points: The appliance does not work... Check that: » There is power at the socket. ® Ensure that there is not a power cut by checking the household lights. * The fuse has not blown. & The air circulation passages are not covered. * The thermostat dial is in the correct position. Vibration or abnormal noises...
PEACE OF MIND FOR TWELVE MONTHS Guarantee conditions We, Trinity Bendix, undertake that if, within twelve months of the date of the purchase, this Trinity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our optic, repair or replace the same FREE OF ANY CHARGE for marabou, materials or carriage on condition that: w The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
X T Better Products. TRINITY BEND Trinity Bendix, 99 OAKLEY ROAD, Futon, Beds LU4 9QQ A DIVISION OF EMACS LIMITED Model No. REGISTERED IN ENGLAND NO. 176547 Part No.
