35665-2703 Better Products. Better Value. BUILT -IN OVEN OPERATING AND INSTALLATION MANUAL MODEL NOS.
WARNINGS AND GUIDANCE It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owner can get to know the functions of the appliance and the relevant warnings. These warnings are provided in the interest of safety. You MUST read them carefully before installing or using the appliance.
CONTENTS Warnings and Guidance Technical Information Installation Electrical connection When the oven is first installed Use and Care How to set the programmer Controls Using the fan oven Grilling Thermal Grilling Helpful hints when buying and preparing food Cleaning the oven Care of catalytic liners Cleaning the hinged grill Something not Working Help us to help you Tricity Bendix Service Force Addresses Guarantee Conditions Page 2 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11-12 Page 13 Page
TECHNICAL INFORMATION Model Number: BS 690 - GR Recess dimensions Height Width Depth Oven Capacity Internal oven dimensions Height Width Depth Oven Ratings Oven Element Grill Element Double Grill Element Convection Fan Oven Light Cooling fan Total Rating Cable (for UK use) Cable cross-section Type of cable Fuse (min.) Cable (for Europe use) Cable cross-section Type of cable Fuse (min.) 4 580 mm 560-570 mm 550 mm 1.9 cu. ft. 320 mm 420 mm 390 mm 2.5 kW 1.8 kW 2.8 kW 30 W 15 W 25 W 2.
INSTALLATION It is mandatory that all operations required for the installation be carried out by a qualified or competent person - in accordance with existing rules and regulations. Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown.
ELECTRICAL CONNECTION We strongly recommend that all operations for the installation of your oven be carried out by QUALIFIED PERSONNEL to the relevant British Standards. The oven designed to be connected to 240V (50Hz) electricity supply.
WHEN THE OVEN IS FIRST INSTALLED Once the oven has been installed, it is important to remove the protective materials which were put on in the factory. Press button E for manual function. Switch the oven control knob to fan ducted cooking and then set the thermostat control knob to MAX and leave it to run, empty, for 30 minutes to remove any unpleasant new smells. During this period, an unpleasant odour may be emitted, it is therefore, advisable to open a window for ventilation.
USE AND CARE 1 2 PROGRAMMER A U T O SELECTOR TEMPERATURE 3 4 °C - + 5 6 7 8 1. 2. 3. 4. Electronic programmer Oven temperature light Oven function control knob Thermostat control knob 5. 6. 7. 8. Grill element Interior light (oven light) Fan Shelf support 9. Removable handle (2) 10. Grill trivet 11.
HOW TO SET THE PROGRAMMER CLOCK A KNOB - + B C D E MANUAL OPERATION TIMER COOKING TIME MANUAL OPERATION END OF COOKING SETTING THE TIME OF DAY 24 HOUR CLOCK SETTING THE AUTOMATIC TIMER - + - + - + To set oven for manual operation press button E. Press button B and C at the same time and while turning knob A enter the time of day. Press button C and while turning knob A enter the required cooking time.
CONTROLS Push-Pull Control Knob The knobs of this oven are of the push-pull type. They can be completely sunken inside the control panel when the oven is not working (see Fig. 4). Oven Function Control Knob (fan) Oven light - this will come on automatically when the oven is in use. Defrost setting (NB: this is NOT a cooking setting). This setting is intended to assist in thawing of frozen foods (see page 12).
USING THE FAN OVEN The Fan Oven HINTS AND TIPS The air inside the oven is heated by the element around the fan situated behind the back panel. The fan draws air from the oven, the element heats the air which is circulated into the oven via the top, base and sides of the back panel. The advantages of cooking with this function are: Runner positions are not critical, but make sure the shelves are evenly spread.
Only experience will enable you to determine the proper settings for your personal cooking needs. The temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. The effects of dishes on cooking results Dishes and tins vary in their thickness, conductivity, colour, etc.
GRILLING GRILLING - INNER GRILL ELEMENT Important All grilling must be carried out with the oven door closed and the grill pan handle removed from the pan. Important All grilling must be carried out with the oven door closed and the grill pan handle removed from the pan. Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the food out of the fats and juices.
The indicator windows for selector and oven temperature control will illuminate. selected. Be prepared to adjust temperature and shelf positions during cooking, if necessary. The oven fan and internal oven light will come on. Turn food over during cooking, as necessary. The control cooling fan will operate after a short time. It will run on after the controls are switched off until the appliance has cooled. Ensure that ready prepared or cooked chilled dishes, e.g. shepherds pie, moussaka, lasagne, etc.
HELPFUL HINTS WHEN BUYING AND PREPARING FOOD Care must be taken when handling foods in the home. Always follow the basic rules of food hygiene to prevent bacterial and microbial growth and cross contamination when preparing, reheating, cooking, cooling, defrosting and freezing foods: 1. Always ensure food you purchase is of good quality and in prime condition. Shop at a reliable source and buy the 'freshest' looking package avoid shopworn labels or produce covered in dust. 2.
CLEANING THE OVEN Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is recommended by the manufacturer. Replacing Components Prior to undertaking any maintenance work or replacing the oven light, be sure to disconnect appliance from the electricity supply.
CARE OF CATALYTIC LINERS Catalytic liners destroy splashes of food and fats when the oven temperature is raised to around 220°C. To aid this process it is a good idea to run the oven for an hour or two per week, without food, to ensure continued good performance from the Catalytic liners. Hints and tips • Manual cleaning of the Catalytic liner is not recommended. Damage will occur if soap impregnated steel wool pads, aerosol cleaners and any other abrasives are used.
SOMETHING NOT WORKING If the oven does not come on: * Check the oven is in manual operation * Check that it is plugged in properly * Check that the socket switch and/or the switch from the mains supply to the oven are ON Please note that it will be necessary to provide proof of purchase for any inguarantee service calls. In-guarantee customers should ensure that the above checks have been made as the engineer will make a charge if the fault is not a mechanical or electrical breakdown.
TRICITY BENDIX SERVICE FORCE POSTCODE TO SERVICE CENTRE CROSS REFERENCE Postcode Telephone AB AL B1-48, 62-79 B90-94 B49, 50, 60 61, 80, 95-98 BA BB BD BH BL BN1-18, 20-27 BR BS BT1-30, 36-57 BT63-67 BT31-35, 60-62 BT68-82, 92-94 CA CB CF CH CM CO CR CT CV CW DA DD DE DG DH 01224-696569 Aberdeen 0181-965 9699 Canvey DL DN1-7,10-12 DN8-9,15-20 DN21 Subcodes 3,4 DN31-40 DN14 DN21 Subcodes 1,2,5 DT Dundee Gas Only DY E EC EH EN EX1-17 EX18-23 EX31-39 FK FY G GL GU1-35 Guernsey Service Centre 0121-3587076
TRICITY BENDIX SERVICE FORCE ADDRESSES CENTRE ADDRESS ABERDEEN Tricity Bendix Service Force Northeast Appliance Service 8 Cornhill Arcade Cornhill Drive Aberdeen AB2 5UT ARGYLL Tricity Bendix Service Force T.D.C. Refrigeration Briar Hill 7 Hill Street, Dunoon Argyll PA23 7AL BARNSTAPLE BORDERS BRISTOL CANVEY CARDIFF CUMBRIA DUMFRIES & GALLOWAY Tricity Bendix Service Force Mc Bain Refrigeration P.O.
GUARANTEE FOR 12 MONTHS TRICITY BENDIX STANDARD GUARANTEE CONDITIONS EXCLUSIONS This guarantee is in addition to your statutory and other legal rights.
Better Products. Better Value. TRICITY BENDIX, 99 OAKLEY ROAD, LUTON, BEDFORDSHIRE, LU4 9QQ. A Division od Emaco Limited - Registered in England No. 176547 - Registered Office. 101 Oakley Road, Luton LU4 9RJ. 22 MODEL NO. PART NO.
